Uploaded byOla Spjuth
Automating cell-based screening with open source, robotics and AI
The document discusses the automation of cell-based screening in drug discovery using open-source robotics and AI, highlighting advancements in fully automated cell profiling and intelligent design of experiments. It outlines the vision for autonomous experimentation, detailing protocols for optimizing cell profiling tasks and the use of AI in experimental design and data analysis. Emphasizing iterative exploration of drug combinations, the document illustrates how automation can enhance the efficiency and effectiveness of drug discovery processes.
More Related Content
Similar to Automating cell-based screening with open source, robotics and AI
Automating cell-based screening with open source, robotics and AI
- 1. Automating cell-based screening withopen source, robotics and AI Ola Spjuth, Professor Department of Pharmaceutical Biosciences and Science for Life Laboratory Uppsala University https://www.linkedin.com/in/olaspjuth/
- 2. l Processing StreamProcessing Dat a osit ory Query request response Real- T ime Analyt ics Dat a Result s Current fact finding Analyze data in motion – before it is stored ormation stored on disk Our mission: Accelerating drug discovery
- 3. Applications in drug discovery Cell profiling Automation AI/ML Accelerate drugdiscovery using AI, automation and intelligent design of experiments • Predict safety concerns • Predict drug mechanisms • Screen for new drugs • Precision medicine Research objective:
- 4. Applications in drug discovery Cell profiling Automation AI/ML Open sourcefully automated cell profiling lab Cell Painting – high-content imaging Computational and Data Management Infrastructure AI and Robotics Morphological profiling experiments Intelligent design of experiments Vision: Autonomous experimentation
- 5. Cell profiling AI/ML Morphological Profile Cell segmentation & Imageanalysis Microscopy imaging Chemical perturbation of cells Experiments in multiwell plates Cell Painting Bray et al. Nat Protoc 2016 DNA Damage Prediction Deep Neural Network Drug-treated cells Kinase inhibitor Kensert A, Harrison PJ, Spjuth O. Transfer learning with deep convolutional neural network for classifying cellular morphological changes. SLAS DISCOVERY: Advancing Life Sciences R&D. 24, 4 (2019)
- 6. Our objectives withautomation • Fully automated Cell Painting • Robotized experiments • Configurable, serviceable by us • Cost-efficient, use off-the-shelf instruments • Full control of all steps • Automated analytics • Standardized data capturing, preprocessing, and AI modeling • Closed-loop science • Full control of all steps open up for online decision making AI and Robotics Morphological profiling experiments Intelligent design of experiments Vision: Autonomous experimentation
- 7. Automating cell profiling: Buildingan open source robotized lab Plate incubator Washer Dispenser Robot arm https://github.com/pharmbio/aros Washer
- 8. incubation for 24-48h at37℃ and 5% CO2 Washer (2X PBS) Mitotracker staining (live cells staining) [dispenser peripump 1] incubation for 20 min at 37℃ and 5% CO2 Washer (3X PBS) Fixation (4% PFA) [dispenser Syringe A] Seeded plates with compound treatment Washer (3X PBS) incubation for 20 min in room temperature Permeabilization (0.1% Triton X-100) [dispenser Syringe B] Washer (3X PBS) incubation for 20 min in room temperature Post-fixation staining (staining mixture of 5 dyes) [dispenser peripump 2] Washer (5X PBS) incubation for 20 min in room temperature Imaging store in 4°C Optimizing and executing experiments Detailed logs Checkpoint('batch_1') WaitForCheckpoint('batch_1') + 'plate_1_get_delay' EnqueueOnMachine(incubator, RunMachine(incubator, 'get L1')) RunMachine(robotarm, 'goto incubator') WaitForMachineReady(incubator) RunMachine(robotarm, 'get from incubator') RunMachine(robotarm, 'lid off') RunMachine(robotarm, 'to washer') EnqueueOnMachine(washer, [ WaitForCheckpoint('batch_1') + 'plate_1_wash_delay', RunMachine(washer, 'wash_2X_before_mito.LHC')]) EnqueueOnMachine(dispenser, [ Idle('mito_prime_delay', optimize='maximize'), RunMachine(dispenser, 'mito_prime.LHC')]) WaitForMachineReady(washer) RunMachine(robotarm, 'wash to disp') WaitForMachineReady(disp) EnqueueOnMachine(dispenser, RunMachine(dispenser, 'mito_40ul.LHC')) WaitForMachineReady(disp) Checkpoint('plate_1_incubation_1') ... Protocols expressed in code. Generates a protcol in a DSL. Optimized using constraint programming. https://github.com/pharmbio/aros
- 9. AI for experimentaldesign AI for optimizing experiments AI and robotics to automate cell profiling AI for data analysis AI to guide image acquisition AI for cell segmentaion
- 10. Microplate Wells 1 384 Sites 3 456 Images >15-25 K (200GB) Cells >300 K Measurements >400 M x9/ 2h
- 11. Dealing with continuouslarge scale data GPU cluster CPU server Storage Cloud Online processing Automating analysis pipelines Images AI modeling QC Morphology profiles Computational infrastructure
- 12. • Image andmetadata storage in database • Access through browser • Quick image visualisation including: o Timepoint o Site o Channel • Direct link to analysis pipeline Image Database + web viewer https://imagedb.k8s-prod.pharmb.io/
- 13.
- 14. Jupyter Notebooks fordata analysis • QC pipeline • Data analysis • Data visualisation • Publish via github
- 15. How to scaleup imaging? • Minimize images captured and stored, also go towards live-cell imaging • Get more and faster microscopes Hongquan L. et al. “Squid: Simplifying Quantitative Imaging Platform Development and Deployment.” bioRxiv 2020.12.28.424613 https://squid-imaging.org
- 16. Data-driven image prioritization Microscopefarm Image streams … … … Feature Extraction Interestingness function Policy Prioritization How can we deal with large, continuous streams of images?
- 17. Designing cell profilingexperiments • Many options to consider: • Which cell line(s) • How many and which compounds • Concentrations • Replicates • Exposure time(s) • Total number of plates • Positive controls, negative controls • Can AI be used to optimize design of experiments? • Minimize experiment time and cost • Maximize usefulness of resulting data
- 18. -Manuscript Draft- 13th Dec,2021, 15:32 Plate effect Border layout Random layout Effective layout Figure 1: Examples of the distribution of 20 negative control in layouts for 384-well microplates. The colors indicate the intensity measured at each well. Approach: Use constraint programming to design effective plate layouts • Optimal under set of constraints • Declarative / flexible to adapt Designing microplate experiments with AI Rodríguez MAF, Carreras-Puigvert J, and Spjuth O. “Designing microplate layouts using artificial intelligence.” bioRxiv. 2022.03.31.486595 (2022). -Manuscri (b) Relative IC50/ EC50 ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ (d) Residuals ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ ⇤ Screening Dose-response
- 19. https://github.com/pharmbio/plaid PLAID: Plate Layouts usingArtificial Intelligence Design
- 20. From prediction todecision making: What is the next, best experiment? Automated lab AI models Data Decision making
- 21. Screening for antiviraldrugs by phenomics Reversal of the SARS-CoV-2-induced phenotype in Vero E6 cells Unpublished data Rietdijk J, Tampere M, Pettke A, Georgieva P, Lapins M, Warpman Berglund U, Spjuth O, Puumalainen MR, Carreras-Puigvert J. “A phenomics approach for antiviral drug discovery.” BMC Biology 19 (2021). Can we improve using drug combinations?
- 22. • Safety ofchemicals and drugs assessed individually • Combination therapy is common for many diseases • How can we research combinations/mixtures of chemicals? • Our approach: • Cell Painting: Ideal tradeoff between speed/cost/information content • AI/ML: Select and design next batch of combinations to test • Automation: Iteratively carry out experiments and repeat Ongoing research: Study combinations of compounds
- 23. Mixtures and CellPainting
- 24. AI and Robotics Morphologicalprofiling experiments Cell lines / Primary cells Profiling of individual drugs with known mechanisms …. Drugs Profiling and screening for drug combinations …. …. A discovery engine! Iterative exploration of individualized drug combinations Primary cells and organoids Individualized drug combination Patient
- 25. • Manage lifecycle of AI models, improve FAIR1 • Deploy and use apps and AI models in production • Effort at SciLifeLab Data Center, Sweden Working with ML models 1 Spjuth O, Frid J, and Hellander A. The Machine Learning Life Cycle and the Cloud: Implications for Drug Discovery Expert Opinion On Drug Discovery. 16, 9, 1071-1079. (2021). DOI: 10.1080/17460441.2021.1932812 https://serve.scilifelab.se
- 26. Teaching next-generation scientists Introductionto Lab Automation, 7.5 c Learn to use automated pipetting, plate handling, microscopy. Big Data in Life Science, 5c Compute infrastructure and analysis methods to analyze large data. Other courses (italic=online): Pharmaceutical Bioinformatics, 7.5 c Pharmaceutical Bioinformatics with Sequence Analysis, 7.5c Applied Pharmaceutical Bioinformatics, 5c Applied Pharmaceutical Structural Bioinformatics, 5c Artificial Intelligence in drug discovery, 7.5c Online introductory course.
- 27. Acknowledgements Funding: Pharmb.io research group JordiCarreras-Puigvert Wesley Schaal Jonathan Alvarsson Maris Lapins Polina Georgieva Malin Jarvius Anders Larsson Dan Rosén Andreina Rodrigues Christa Ringers Staffan McShane Amelie Wenz Ebba Bergman Phil Harrison Jonne Rietdijk David Holmberg Akshai Sreenivasan Martin Johansson HASTE project Carolina Wählby, UU Andreas Hellander, UU Salman Toor, UU Håkan Wieslander, UU Ankit Gupta, UU Tianru Zhang, UU Xiaobo Zhao, UU Ben Blamey, UU Alan Sabirsh, AstraZeneca Ida-Maria Sintorn, Vironova Karolinska Institutet Päivi Östling Brinton Seashore-Ludlow Marianna Tampere SciLifeLab Data Center The Serve team NTNU/Trondheim Åsmund Flobak Astrid Laegrid Ulf Norinder Ernst Ahlberg Lars Carlsson Fredrik Svensson CBCS
- 28. Research group website:http://pharmb.io Ola Spjuth ola.spjuth@farmbio.uu.se https://www.linkedin.com/in/olaspjuth/ Thank you
