Using Java to deploy Deep Learning models with MXNet

© 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.© 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
Using Java to deploy Deep
Learning models with MXNet
Andrew Ayres
Amazon Web Services
Qing Lan
Amazon Web Services

© 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
Agenda
● Introduction to Deep Learning
● Apache MXNet
● Getting started with MXNet Java
● Technical Challenges
● Q&A By the end of this session, you will
understand what deep learning is,
and how you can start using
MXNet Java API today!

AI
Machine
Learning
Deep
Learning
Can machines do what we can?
(Turing, 1950)
Machine Learning
Data
Answers
Rules
Traditional
programming
Data
Rules
Answers

Deep learning is a big deal
It has a growing impact on our lives
Personalization Logistics Voice
Autonomous
vehicles

Deep learning is a big deal
It is able to do better than humans

Inspired by the brain’s neurons
We have ~100B of them, and ~1Q synapses
ANN is a simple computation construct:
w1
w2
wn
x1
x2
xn
Σ φ 𝑦
…
𝑦 = 𝜑(
𝑗=1
𝑛
𝑤𝑗 𝑥𝑗)
ArtificialNeuralNetwork

Neuralnetwork
Output
layer
Input
layer
Hidden
layers
ManyMore…
• Non-linear
• Hierarchical
feature learning
• Scalable architecture
• Computationally
intensive

Fullyconnectedlayer
Networks are comprised of
stacked layers (mostly)
Composed of artificial neurons,
each fully connected to the
previous layer, and to the next
Connections have an associated
“weight” learned during training
Fully connected
layer

Convolutionlayer
Operator is “sliding” a kernel
across the input, computing
value at each position in the
output tensor
The kernel values are the
learned parameters of the layer
Convolution layers are effective
in perceptual problems involving
visual data

Convolutionlayer
When combined across multiple layers, convolution is able to
learn hierarchical features, with increasing levels of abstraction
Layer 1 – Edges Layer 2 – Curves Layer N –
Classes

Recurrentneural networklayer
In some problems, predicting a given
point in time depends on input
context from an earlier time
RNN layer “remembers the past” –
using loops!
RNNs are effective for time series
and natural language problems
A
X
y

Recurrentneural networklayer
We can “unroll” an RNN layer to understand how it works
A
x0
h
0
A
x1
h
1
A
x2
h
2
A
xt
h
t
…A
X
y

Forward pass
Backwards pass
Input Data
Neural
Network
Output
Loss
Back
Propagate
Update
Weights
Forward-backward repeats across multiple epochs, each
epoch goes through the entire training dataset.
Trainingneuralnetworks

Apache MXNet

Apache MXNet - Background
● Framework for building, training, and deploying Deep Neural Nets
● Apache (incubating) open source project
● Created by academia (CMU and UW)
● Adopted by AWS as DNN framework of choice, Nov 2016
http://mxnet.apache.org

Apache MXNet - Highlights
•Imperative, Symbolic and Dynamic APIs
•Supports 8 languages including 3 JVM languages (Scala, Java, Clojure)
Programmability
•Optimized for CPU, GPU, ARM (and more)
•Highly scalable distributed training
•Quantization, Sparse, NCCL, and more…
Performance
• ONNX
• Toolkits to quickly get started Gluon-CV, Gluon-NP, Model Zoo
• Model Server
MXNet ecosystem

Why MXNet Java?
● Community interest in deploying models to Java
● Enable Java developers to use DL in their existing Java
workflows without having to become experts
Blogpost: https://medium.com/apache-mxnet/introducing-java-apis-for-deep-learning-inference-
with-apache-mxnet-8406a698fa5a

Getting started with MXNet Java
● Step1: Install Java8
● Step2: MXNet Java Demo project
● Linux and OSX are supported

MXNet Java Inference Demo – Inference API
Single Shot Object Detection

MXNet Java API: Architecture
C
Frontend
Backend
C++
ClojureJuliaPerlR
ScalaPython Java
While keeping high performance from efficient backend
Clojure
Scala
Java

Java Code Generation
Scenario
● Around 200+ math functions optimized for large dataset
(operators) are implemented in C that we want to provide
● Function names and arguments are not being provided
● We don’t want to code!

Solution
● Fetching all argument information from C
● C to Java argument mapping
● Function Generation
● How to deal with too many arguments?

Solution
● Operators with few arguments
● Call directly
// public static NDArray[] broadcast_mul(NDArray lhs, NDArray rhs, NDArray out)
NDArray test = NDArray.broadcast_mul(lhs, rhs, out);

Solution
● Operators with more arguments
● Use ParamObject ( NDArray.RNN(RNNParam obj) )

Java Memory Management
Scenario
● Some Java objects allocate
off-heap memory
● Java GC does not release
off-heap memory
● A couple of mechanisms
are provided to prevent
memory leaks

Mechanisim

PhantomReference
● These MXNet objects (NDArray, Executor, Module) are
tracked using Phantom References.
● When the Java objects lose all references, they are put
into a reference queue.
● We take advantage of this and do a pre-mortem
cleanup by freeing the native memory corresponding to
these objects.

ResourceScope
● ResourceScope implements AutoClosable
● Native memory is tracked within the scope and freed
when the scope is closed
try(ResourceScope scope = new ResourceScope()) {
NDArray test = NDArray.ones((Shape(2,2));
}

DisposeMethod
● You can manually dispose the native memory just like
hamming a nail to the board
● You can hamming your finger to it too…
NDArray test = NDArray.ones((Shape(2,2));
test.dispose();

Contribute to Apache MXNet
● GitHub: https://github.com/apache/incubator-mxnet
● Subscribe to our developer mailing list:
dev@mxnet.incubator.apache.org
● Slack Channel: https://the-asf.slack.com and go to #mxnet

Thank you!
Andrew Ayres
Amazon Web Services
Qing Lan
Amazon Web Services
Q & A Session
