![Background
Dynamic Symbolic Execution (DSE)
aka. Concolic Testing
[Godefroid et al. 05][Sen et al. 05][Tillmann et al. 08]
Instrument code to explore feasible paths
http://research.microsoft.com/pex/](https://image.slidesharecdn.com/pex4fun2014feb-140210125523-phpapp02/75/Teaching-and-Learning-Programming-and-Software-Engineering-via-Interactive-Gaming-5-2048.jpg)
![Dynamic Symbolic Execution in Pex
Choose next path
Solve
void CoverMe(int[] a)
{
if (a == null) return;
if (a.Length > 0)
if (a[0] == 1234567890)
throw new Exception("bug");
}
F
F
a.Length>0
a==null
Execute&Monitor
Constraints to solve
Input
Observed constraints
a!=null
null
{}
a==null
a!=null &&
!(a.Length>0)
a==null &&
a.Length>0 &&
a[0]!=1234567890
a==null &&
a.Length>0 &&
a[0]==1234567890
a!=null &&
a.Length>0
a!=null &&
a.Length>0 &&
a[0]==123456890
T
T
{0}
{123…}
Done: There is no path left.
a[0]==123…
F
T
http://pex4fun.com/HowDoesPexWork](https://image.slidesharecdn.com/pex4fun2014feb-140210125523-phpapp02/75/Teaching-and-Learning-Programming-and-Software-Engineering-via-Interactive-Gaming-7-2048.jpg)
![Background
Dynamic Symbolic Execution (DSE)
aka. Concolic Testing
[Godefroid et al. 05][Sen et al. 05][Tillmann et al. 08]
Instrument code to explore feasible paths
http://research.microsoft.com/pex/](https://crownmelresort.com/image.slidesharecdn.com/pex4fun2014feb-140210125523-phpapp02/75/Teaching-and-Learning-Programming-and-Software-Engineering-via-Interactive-Gaming-5-2048.jpg)
![Dynamic Symbolic Execution in Pex
Choose next path
Solve
void CoverMe(int[] a)
{
if (a == null) return;
if (a.Length > 0)
if (a[0] == 1234567890)
throw new Exception("bug");
}
F
F
a.Length>0
a==null
Execute&Monitor
Constraints to solve
Input
Observed constraints
a!=null
null
{}
a==null
a!=null &&
!(a.Length>0)
a==null &&
a.Length>0 &&
a[0]!=1234567890
a==null &&
a.Length>0 &&
a[0]==1234567890
a!=null &&
a.Length>0
a!=null &&
a.Length>0 &&
a[0]==123456890
T
T
{0}
{123…}
Done: There is no path left.
a[0]==123…
F
T
http://pex4fun.com/HowDoesPexWork](https://crownmelresort.com/image.slidesharecdn.com/pex4fun2014feb-140210125523-phpapp02/75/Teaching-and-Learning-Programming-and-Software-Engineering-via-Interactive-Gaming-7-2048.jpg)
Uploaded byTao Xie
Teaching and Learning Programming and Software Engineering via Interactive Gaming
The document discusses various educational tools for teaching programming and software engineering, particularly focusing on interactive gaming platforms such as Pex for Fun and Code Hunt. It highlights the use of dynamic symbolic execution for enhancing learning experiences through coding duels and real-time feedback for students. Additionally, it emphasizes user engagement and the benefits of automatic grading in educational settings.
More Related Content
Similar to Teaching and Learning Programming and Software Engineering via Interactive Gaming
Teaching and Learning Programming and Software Engineering via Interactive Gaming
- 1. https://www.codehunt.com Teaching and Learning Programmingand Software Engineering via Interactive Gaming http://pex4fun.com Tao Xie University of Illinois at Urbana-Champaign In collaboration with Nikolai Tillmann, Jonathan de Halleux, and Judith Bishop (Microsoft Research) Related Papers/Resources: https://sites.google.com/site/asergrp/projects/ese
- 2. Testing Tool Educational Gaming Support Dynamic Symbolic Execution (Pex) http://research.microsoft.com/pex/ Pex for Fun: Interactive Gaming for Teaching and Learning https://www.codehunt.com http://pex4fun.com
- 3.
- 4.
- 5. Background Dynamic Symbolic Execution(DSE) aka. Concolic Testing [Godefroid et al. 05][Sen et al. 05][Tillmann et al. 08] Instrument code to explore feasible paths http://research.microsoft.com/pex/
- 6.
- 7. Dynamic Symbolic Executionin Pex Choose next path Solve void CoverMe(int[] a) { if (a == null) return; if (a.Length > 0) if (a[0] == 1234567890) throw new Exception("bug"); } F F a.Length>0 a==null Execute&Monitor Constraints to solve Input Observed constraints a!=null null {} a==null a!=null && !(a.Length>0) a==null && a.Length>0 && a[0]!=1234567890 a==null && a.Length>0 && a[0]==1234567890 a!=null && a.Length>0 a!=null && a.Length>0 && a[0]==123456890 T T {0} {123…} Done: There is no path left. a[0]==123… F T http://pex4fun.com/HowDoesPexWork
- 8.
- 9. Coding Duels Pex computes“semantic diff” in cloud secret reference implementation vs. code written in browser You win when Pex finds no differences For more info, see our ICSE 2013 SEE paper: http://web.engr.illinois.edu/~taoxie/publications/icse13see-pex4fun.pdf
- 10. Behind the Sceneof Pex for Fun behavior Secret Impl == Secret Implementation class Secret { public static int Puzzle(int x) { if (x <= 0) return 1; return x * Puzzle(x-1); } } class Test { public static void Driver(int x) { if (Secret.Puzzle(x) != Player.Puzzle(x)) throw new Exception(“Mismatch”); } } Player Impl Player Implementation class Player { public static int Puzzle(int x) { return x; } } 10
- 11. Coding Duels Fun andEngaging Iterative gameplay Adaptive Personalized No cheating Clear winning criterion
- 12. Social Experience Community High scorelists, leaderboard Live feed http://pex4fun.com/Community.aspx http://pex4fun.com/Livefeed.aspx
- 13.
- 14.
- 15. Skills Being Trained Induction Problemsolving/debugging Program understanding/programming Testing Specification writing
- 16. Coding Duels forCourse Assignments @Grad Software Engineering Course Observed Benefits • Automatic Grading • Real-time Feedback (for Both Students and Teachers) • Fun Learning Experiences http://pexforfun.com/gradsofteng
- 17. Coding Duel Competition @ICSE2011 http://pexforfun.com/icse2011
- 18. Example User Feedback Releasedsince 2010 “I used to love the first person shooters and the satisfaction of blowing away a whole team of Noobies playing Rainbow Six, but this is far more fun.” X “I’m afraid I’ll have to constrain myself to spend just an hour or so a day on this really exciting stuff, as I’m really stuffed with work.” “It really got me *excited*. The part that got me most is about spreading interest in teaching CS: I do think that it’s REALLY great for teaching | learning!”
- 19. Usage Scenarios ofPex4Fun • Massive Open Online Courses (MOOC) • Course assignments (students/professionals) • Student/professional competitions • Assessment of testing, programming, problem solving skills for job applicants
- 20. Code Hunt: ResignedAs Game https://www.codehunt.com/
- 21. End-User Programming On MobileDevices TouchDevelop: Bring your own devices, program anywhere, run immediately on devices V.S. https://www.touchdevelop.com/ 21
- 22.
- 23.
- 24.
- 25.
- 26. TouchDevelop cont. • Simplescript language – No user-defined type – No class inheritance Full-fledged platform for • Rich API support EUP on Mobile Devices – Easy access to various sensors and resources • Powerful cloud services – Download/publish scripts – Store information of entities (e.g., scripts, users) – Answer queries https://www.touchdevelop.com/ 26
- 27. Rapid Increase ofTouchDevelop Popularity Oct 2013 vs. 17322 scripts Feb 2013 27
- 28. Summary: Testing ToolEducational Gaming Support DSE/Pex Pex for Fun: Interactive Gaming for Teaching and Learning https://www.touchdevelop.com/ https://www.codehunt.com http://pex4fun.com
- 29. Testing Tool Educational Gaming http://research.microsoft.com/pex/ http://pex4fun.com Support Q&A Thank you! Contact: taoxie@illinois.edu http://www.cs.illinois.edu/homes/taoxie/ Related Papers/Resources: https://sites.google.com/site/asergrp/projects/ese
- 30. Summary: Testing ToolEducational Gaming Support DSE/Pex Pex for Fun: Interactive Gaming for Teaching and Learning https://www.touchdevelop.com/ https://www.codehunt.com http://pex4fun.com
