An improved Item-based Maxcover Algorithm to protect Sensitive Patterns in Large Databases

IOSR Journal of Computer Engineering (IOSR-JCE)
e-ISSN: 2278-0661, p- ISSN: 2278-8727Volume 14, Issue 4 (Sep. - Oct. 2013), PP 01-05
www.iosrjournals.org
www.iosrjournals.org 1 | Page
An improved Item-based Maxcover Algorithm to protect
Sensitive Patterns in Large Databases
Mrs. P.Cynthia Selvi1
, Dr.A.R.Mohamed Shanavas2
1. Associate Professor, Dept. of Computer Science, KNGA College(W), Thanjavur 613007 /Affiliated to
Bharathidasan University, Tiruchirapalli, TamilNadu, India.
2. Associate Professor, Dept. of Comuter Science, Jamal Mohamed College, Tiruchirapalli 620 020/ Affiliated
to Bharathidasan University, Tiruchirapalli, TamilNadu, India.
Abstract: Privacy Preserving Data Mining(PPDM) is a rising field of research in Data Mining and various
approaches are being introduced by the researchers. One of the approaches is a sanitization process, that
transforms the source database into a modified one by removing selective items so that the counterparts or
adversaries cannot extract the hidden patterns from. This study address this concept and proposes a revised
Item-based Maxcover Algorithm(IMA) which is aimed at less information loss in the large databases with
minimal removal of items.
Keywords: Privacy Preserving Data Mining, Restrictive Patterns, Sensitive Transactions, Maxcover, Sanitized
database.
I. Introduction
PPDM is a novel research direction in DM with the main objective to develop algorithms for
modifying the original data in some way, so that the private data and private knowledge remain private even
after the mining process[1]. This modification is done by deleting one or more items from source database or
even adding noise to the data by turning some items from 0 to 1 in some transactions. The procedure of
transforming the source database into a new database that hides some sensitive patterns or rules is called the
sanitization process[2] and the released database is called the sanitized database. The approach of modifying
some data is perfectly acceptable in some real applications[3, 4] provided the impact on the source database is
kept minimal.
This study mainly focus on the task of minimizing the impact on the source database by reducing the
number of removed items from the source database with only one scan. Section-2 briefly summarizes the
previous work done by various researchers; In Section-3 preliminaries and basic definitions are discussed. In
Section-4 the proposed algorithm is presented and Section-5 shows the experimental results.
II. Related work
The idea behind data sanitization to reduce the support values of restrictive patterns was first
introduced by Atallah et.al[1] and they have proved that the optimal sanitization process is NP-hard problem. In
[4], the authors generalized the problem and proposed algorithms that ensure privacy preservation; but they
require multiple scans over a transactional database. In the same direction, Saygin [5] introduced a method for
selectively removing individual values from a database and proposed some algorithms to obscure a given set of
sensitive rules by replacing known values with unknowns which also require various scans to sanitize a database
depending on the number of association rules to be hidden.
Oliveira introduced algorithms, IGA[6] & SWA[7] that aims at multiple rule hiding in which IGA has
low misses cost; It groups restrictive patterns and assigns a victim item to each group but the clustering is not
performed optimally and it can be improved further by reducing the number of deleted items. Whereas, SWA
improves the balance between protection of sensitive knowledge and pattern discovery but some rules are
removed inadvertently.
In [8] heuristic-based approach is proposed which perform the sanitization process with minimum
number of removal of restricted items. However, when the sensitive patterns to be hidden are mutually
exclusive, this approach has more hiding failure. Hence, in this work the algorithm proposed in [8] is revised
and it is tested with large database which ensure no hiding failure and very low information loss.
III. Preliminaries & Definitions
Transactional Database: A transactional database is a relation consisting of transactions in which each
transaction t is characterized by an ordered pair, defined as t = ˂Tid, list-of-elements˃, where Tid is a unique
transaction identifier number and list-of-elements represents a list of items making up the transactions.

An improved Item-based Maxcover Algorithm to protect Sensitive Patterns in Large Databases
Basics of Association Rules: One of the most studied problems in data mining is the process of discovering
association rules from large databases. Most of the existing algorithms for association rules rely on the support-
confidence framework introduced in [9].
Formally, association rules are defined as follows: Let I = {i1,...,in} be a set of literals, called items. Let D
be a database of transactions, where each transaction t is an itemset such that 𝑡 ⊆ 𝐼. A transaction t supports X, a
set of items in I, if 𝑋 ⊂ 𝑡. An association rule is an implication of the form 𝑋 ⟹ Y, where 𝑋 ⊂ 𝐼, 𝑌 ⊂ 𝐼 and
𝑋 ∩ 𝑌 = 𝜙. Thus, we say that a rule 𝑋 ⟹ Y holds in the database D with support (𝜎) if
|X∪Y|
N
≥ 𝜎, where N is
the number of transactions in D. Similarly, we say that a rule 𝑋 ⟹ Y holds in the database D with confidence
(𝜑) if
|X∪Y|
|X|
≥ 𝜑, where |𝐴| is the number of occurrences of the set of items A in the set of transactions D.
While the support is a measure of the frequency of a rule, the confidence is a measure of the strength of the
relation between sets of items. Association rule mining algorithms rely on the two attributes, minimum
Support(minSup 𝜎) and minimum Confidence(minConf 𝜑).
Frequent Pattern: A pattern X is called a frequent pattern if Sup(X) ≥ minSup or if the absolute support of X
satisfies the corresponding minimum support count threshold.
Privacy Preservation in Frequent Patterns: The task of privacy preserving data processing deals with
removing/modifying sensitive entries in the data which are basically decided by the user, who may either be the
owner or the contributor of the data.
Definitions :
Definition 1: Let D be a source database, containing a set of all transactions. T denotes a set of transactions,
each transaction containing itemset 𝑋 ∈ 𝐷. In addition, each k-itemset 𝑋 ⊆ 𝐼 has an associated set of
transactions 𝑇 ⊆ 𝐷, where 𝑋 ⊆ 𝑡 and 𝑡 ∈ 𝑇.
Definition 2: Restrictive Patterns : Let D be a source database, P be a set of all frequent patterns that can be
mined from D, and RulesH be a set of decision support rules that need to be hidden according to some security
policies. A set of patterns, denoted by RP is said to be restrictive, if RP ⊂ P and if and only if RP would derive
the set RulesH. RP is the set of non-restrictive patterns such that RP RP = P.
Definition 3 : Sensitive Transactions : Let T be a set of all transactions in a source database D, and RP be a set
of restrictive patterns mined from D. A set of transactions is said to be sensitive, denoted by ST, if every t ST
contain atleast one restrictive pattern, ie ST ={ 𝑡 ∈ T | X ∈ RP, X ⊆ t }. Moreover, if ST T then all restrictive
patterns can be mined one and only from ST.
Definition 4 : (i) Transaction Size : The number of items which make up a transaction is the size of the
transaction.
(ii) Transaction Degree : Let D be a source database and ST be a set of all sensitive transactions in D. The
degree of a sensitive transaction t, denoted as deg(t), such that t ST is defined as the number of restrictive
patterns that t contains.
Definition 5: Cover : The Cover[8] of an item Ak can be defined as, CAk = { rpi | Ak ∈ rpi ⊂ RP, 1 i |RP|}
i.e., set of all restrictive patterns(rpi) which contain Ak. The item that is included in a maximum number of rpi is
the one with maximal cover or maxCover; i.e., maxCover = max( |CA1|, |CA2| , … |CAn| ) such that Ak ∈ rpi ⊂ RP.
IV. Sanitization Algorithm
Given the source database (D), and the restrictive patterns(RP), the goal of the sanitization process is to
protect RP against the mining techniques used to disclose them. The sanitization process decreases the support
values of restrictive patterns by removing items from sensitive transactions using some heuristics. The heuristics
used in this work is given below:
Heuristic : Sensitive Transactions(ST) in source database(D) are identified and sorted in decreasing order of
(deg + size), which enable multiple patterns to be sanitized in a single iteration. Then the victim item is the one
which is selected based on maxcover (definition-5) value of the items in the restrictive patterns.
Algorithm
Input : (i) D – Source Database (ii) RP – Set of all Restrictive Patterns
Output : D’ – Sanitized Database
Item-based Maxcover Algorithm(IMA): // based on Heuristics 1 & 2 //
Step 1 : (i) find supCount(Ak) ∀ Ak rpi RP
(ii) find supCount(rpi), ∀ rpi RP and sort in decreasing order ;
Step 2 : (i) find Sensitive Transactions(ST) w.r.t. RP ;
(ii) obtain deg(t), size(t) ∀ t ST ;
(iii) sort t ST in decreasing order of deg & size ;

Step 3 : find ST D ST ; // ST - non sensitive transactions //
Step 4 : // Find ST’ //
find cover for every item Ak ∈ RP and sort in decreasing order of cover;
for each item Ak ∈ RP do
{
find T = 𝑡
|𝑟𝑝 𝑖 −𝑙𝑖𝑠𝑡 |
𝑖=1
for each t ∈ T do
{
delete item Ak in non VictimTransactions such that Ak rpi rpi-list ; // Ak – victimItem //
// initially all t are nonvictim //
decrease supCount of rpi’s for which t is nonVictim;
mark t as victimTransaction in each t-list( rpi ) rpi _list(Ak ) ;
}
}
for each rpi ∈ RP do
{
if (supCount < > 0)
{
for every t ∈ nonVictimTransactions do
{
delete item Ak with minimum supCount (round robin in case of tie);
decrease supCount of every rpi ; // ie, Ak rpi t //
}
}
}
Step 5 : D’ ← ST ∪ ST’
V. Implementation
The test run was performed using AMD Turion II N550 Dual core processor with 2.6 GHz speed and
2GB RAM operating on 32 bit OS; The implementation of the proposed algorithm was done with windows 7 -
Netbeans 6.9.1 - SQL 2005 for real dataset T10I4D100K[10] with characteristics given in table-I. The results
are obtained by varying the number of rules and also size of the source database in terms of number of
transactions (refer graphs). The restrictive patterns are chosen under various categories like overlapping,
mutually exclusive, random, high support, low support with their support ranging between 0.6 and 5, confidence
between 32.5 and 85.7 and length between 2 and 6.
The frequent patterns were obtained using Matrix Apriori[11] which uses simpler data structures for
implementation. The proposed algorithm makes use of preprocessed lookup(hashed) tables which links the
restrictive items and rules with their associated transactions; so that the source database is scanned not more
than once. Our algorithm is evaluated based on the performance measures suggested in [6,7].
Performance Analysis
Hiding Failure(HF) : It is measured by the ratio of the number of restrictive patterns in the released sanitized
database(D’) to the ones in the given source database; HF =
|RP (D′)|
|RP(D)|
. In other words, if a hidden restrictive
pattern cannot be extracted from the released database D’ with an arbitrary minSup, then it has no hiding failure
occurrence. Our approach has 0% HF for all the strategies under which the rules to be hidden were chosen.
Misses Cost(MC) : This measure deals with the legitimate patterns(non restrictive patterns) that were
accidently missed. MC =
~RP D − |~RP (D′)|
~RP D
. Our approach has very minimum MC which ranges between 0% and
2.43%. It is also observed that MC gets reduced linearly when the size of database is increased.
Artifactual Pattern(AP) : AP occurs when D’ is released with some artificially generated patterns after
applying the privacy preservation approach and it is given by, AP =
𝑷′ − |𝑷 ∩ 𝑷′|
𝑷′ . As our approach does not
introduce any false drops, the AP is 0%.
Sanitization Rate(SR) : It is defined as the ratio of the number of selectively deleted items(victim items) to the
total support count of restrictive patterns(rpi) in the source database D and is given by, SR =
victim items
total supCount rpi
.

Here the SR is found to be in the range from 40.32% to 68.82%, which shows that the number of restrictive
items deleted from the source database is kept minimal.
Dissimilarity(dif) : The dissimilarity between the original(D) and sanitized(D’) databases is measured in terms
of their contents which can be measured by the formula, dif(D,D’)=
1
fD(i)n
i=1
× [fD i − fD′
i ]n
i=1 , where fx(i)
represents the ith
item in the dataset X. Our approach has very low percentage of dissimilarity that ranges
between 0.24% and 1.1% and this gets reduced when size of the source database is increased. Hence it is
observed that information loss is very low and so the utility of the data is well preserved.
CPU Time : The range of time requirement for this algorithm with the rules chosen under various categories is
between 1.66 and 17.22 sec. This time requirement can still be reduced when parallelism is adapted with high
speed processor. Moreover, time is not a significant criterion as sanitization is performed offline.
Graphs :
0
20
40
60
5 10 15 20 25
0 0 0 0 0
HF(%)
No. of rules to sanitize
0
20
40
60
2k 4k 6k 8k
0 0 0 0
HF(%)
No. of Transactions
0
20
40
60
5 10 15 20 25
0.25 0.37 0.31 0.8 1.14
MC(%)
0
20
40
60
2k 4k 6k 8k
2.43 0.42 0.18 0.14
MC(%)
No. of Transactions
52.75
40.37 40.78 43.54 45.68
20
40
60
80
100
5 10 15 20 25
SR(%)
67.35 68.1 66.82 68.82
20
40
60
80
100
2k 4k 6k 8k
SR(%)
No. of Transactions
0
20
40
60
5 10 15 20 25
0.32 0.44 0.72 0.96 1.1
Diff(%)
0
20
40
60
2k 4k 6k 8k
0.32 0.27 0.25 0.24
Diff(%)
No. of Transactions

Table – I :Characteristics of Dataset (D & D’)
VI. Conclusion
The proposed Item-based Maxcover Algorithm(IMA) is based on the strategy to simultaneously decrease
the support count of maximum number of sensitive patterns, with possibly minimal removal of items that results
in reduced impact on the source database with no hiding failure. IMA has reduced sanitization rate possibly with
very low misses cost. Moreover this algorithm scans the original database only once. It is important to note that
the proposed algorithm is robust in the sense that reconstruction of the source database is not at all possible;
because the alterations to the original database are not saved anywhere and also encryption techniques are not
involved in this approach. The dissimilarity between the source and sanitized database is very minimum that
minimizes the information loss and preserves improved data utility. The execution time is also significantly low
which can still be reduced to a minimum by parallelism techniques adapted with high speed processors.
References
[1] Verykios,V.S, Bertino.E, Fovino.I.N, ProvenzaL.P, Saygin.Y and Theodoridis.Y, “State-of-the-art in Privacy Preservation Data
Mining”, New York,ACM SIGMOD Record, vol.33, no.2, pp.50-57,2004.
[2] Atallah.M, Bertino.E, Elmagarmid.A, Ibrahim.M and Verykios.V.S, “Disclosure Limitation of Sensitive Rules”, In Proc. of IEEE
Knowledge and Data Engineering Workshop, pages 45–52, Chicago, Illinois, November 1999.
[3] Clifton.C and Marks.D, “ Security and Privacy Implications of Data Mining”, In Workshop on Data Mining and Knowledge
Discovery, pages 15–19, Montreal, Canada, February 1996.
[4] Dasseni.E, Verykios.V.S, Elmagarmid.A.K and Bertino.E, “ Hiding Association Rules by Using Confidence and Support”, In Proc.
of the 4th Information Hiding Workshop, pages 369– 383, Pittsburg, PA, April 2001.
[5] Saygin.Y, Verykios.V.S, and Clifton.C, “Using Unknowns to Prevent Discovery of Association Rules”, SIGMOD Record,
30(4):45–54, December 2001.
[6] Oliveira.S.R.M and Zaiane.O.R, “Privacy preserving Frequent Itemset Mining”, in the Proc. of the IEEE ICDM Workshop on
Privacy, Security, and Data Mining, Pages 43-54, Maebashi City, Japan, December 2002.
[7] Oliveira.S.R.M and Zaiane.O.R, “An Efficient One-Scan Sanitization for Improving the Balance between Privacy and Knowledge
Discovery”, Technical Report TR 03-15, June 2003.
[8] Cynthia Selvi P, Mohamed Shanavas A.R, “An Effective Heuristic Approach for Hiding Sensitive Patterns in Databases”, IOSR-
Journal on Computer Engineering, Volume 5, Issue 1(Sep-Oct, 2012), PP 06-11, DOI. 10.9790/0661-0510611.
[9] Agrawal R, Imielinski T, and Swami.A, “Mining association rules between sets of items in large databases”, Proceedings of 1993
ACM SIGMOD international conference on management of data, Washington, DC; 1993. p. 207-16.
[10] http://fimi.cs.helsinki.fi/data/
[11] Pavon.J, Viana.S, and Gomez.S, “Matrix Apriori: speeding up the search for frequent patterns,” Proc. 24th IASTED International
Conference on Databases and Applications, 2006, pp. 75-82.
1.66
6.32 7.49 9.91 12.54
0
20
40
60
5 10 15 20 25
cputime(secs)
No.of rules to sanitize
6.89 8.22
14.69 17.22
0
20
40
60
2k 4k 6k 8k
cputime(secs)
No. of Transactions
Dataset name
T10I4D100K
No. of
transactions
No. of distinct
Items
Min.
Length
Max.
Length
Dataset Size (MB)
Source (D) 1K – 8K 795 - 862 1 26 97KB – 650 KB
Sanitized (D’) 1K – 8K 795 - 862 1 26 95KB – 648KB

An improved Item-based Maxcover Algorithm to protect Sensitive Patterns in Large Databases

More Related Content

What's hot

Viewers also liked

Similar to An improved Item-based Maxcover Algorithm to protect Sensitive Patterns in Large Databases

More from IOSR Journals

Recently uploaded

An improved Item-based Maxcover Algorithm to protect Sensitive Patterns in Large Databases
