![CLUSTAL W
• Based on Higgins & Sharp CLUSTAL [Gene88]
• Progressive alignment-based strategy
• Pairwise Alignment (n2l2)
• A distance matrix is computed using either an approximate method (fast) or
dynamic programming (more accurate, slower)
• Computation of Guide Tree (n3): phylogenetic tree
• Computed from the distance matrix
• Iteratively selecting aligned pairs and linking them.
• Progressive Alignment (nl2)
• A series of pairwise alignments computed using full dynamic programming to align
larger and larger groups of sequences.
• The order in the Guide Tree determines the ordering of sequence alignments.
• At each step; either two sequences are aligned, or a new sequence is aligned with
a group, or two groups are aligned.
• n: number of sequences in the query
• l : average sequence length
31](https://image.slidesharecdn.com/1-170130164703/75/Modern-Computing-Cloud-Distributed-High-Performance-31-2048.jpg)
![CLUSTAL W
• Based on Higgins & Sharp CLUSTAL [Gene88]
• Progressive alignment-based strategy
• Pairwise Alignment (n2l2)
• A distance matrix is computed using either an approximate method (fast) or
dynamic programming (more accurate, slower)
• Computation of Guide Tree (n3): phylogenetic tree
• Computed from the distance matrix
• Iteratively selecting aligned pairs and linking them.
• Progressive Alignment (nl2)
• A series of pairwise alignments computed using full dynamic programming to align
larger and larger groups of sequences.
• The order in the Guide Tree determines the ordering of sequence alignments.
• At each step; either two sequences are aligned, or a new sequence is aligned with
a group, or two groups are aligned.
• n: number of sequences in the query
• l : average sequence length
31](https://crownmelresort.com/image.slidesharecdn.com/1-170130164703/75/Modern-Computing-Cloud-Distributed-High-Performance-31-2048.jpg)
Uploaded byinside-BigData.com
Modern Computing: Cloud, Distributed, & High Performance
The document discusses modern computing with a focus on high performance computing (HPC) by Dr. Ümit V. Çatalyürek from Georgia Institute of Technology. It covers definitions, architecture, performance metrics, and applications of HPC, particularly in the context of solving complex problems in science and engineering. The content includes practical strategies for enhancing application speed and efficiency, and case studies related to data analysis in medical and scientific fields.
