Docker, Monitoring and SLURM Specific Visualisations
- 1. ss Docker, Monitoring andSLURM Specific Visualisations QNIBTerminal @ work
- 2. • Docker ina Nutshell • QNIBx Terminal Monitoring Inventory • SLURM Autogenerated Dashboards 2 Agenda
- 3. 3 About Me • ChristianKniep @CQnib, christian@qnib.org
- 4. 4 About Me • ChristianKniep @CQnib, christian@qnib.org • >10y Iteration SysAdmin, SysOps, SysEngineer, R&D Engineer DevOps @Locafox (hyper-scale web-service)
- 5. 5 About Me • ChristianKniep @CQnib, christian@qnib.org • >10y Iteration SysAdmin, SysOps, SysEngineer, R&D Engineer DevOps @Locafox (hyper-scale web-service) • Founder of QNIB Solutions Holistic System Management Containerization of SysOps and Workload Consultancy / Software Design & Development
- 6. Docker in aNutshell
- 7. 7 Multiple Guests SERVER SERVER TraditionalVirtualisation Containerisation
- 8. 8 Multiple Guests SERVER HOST KERNEL SERVER HOST KERNEL Traditional Virtualisation Containerisation
- 9. 9 Multiple Guests SERVER HOST KERNEL Userland SERVER HOST KERNEL Userland Traditional Virtualisation Containerisation
- 10. 10 Multiple Guests SERVER HOST KERNEL HYPERVISOR (Type II) Userland SERVER HOST KERNEL Userland Traditional Virtualisation Containerisation
- 11. 11 Multiple Guests SERVER HOST KERNEL HYPERVISOR (Type II) KERNEL Userland KERNEL KERNEL SERVER HOST KERNEL Userland Traditional Virtualisation Containerisation
- 12. 12 Multiple Guests SERVER HOST KERNEL HYPERVISOR (Type II) KERNEL Userland KERNEL KERNEL Userland Userland Userland SERVER HOST KERNEL Userland Traditional Virtualisation Containerisation
- 13. 13 Multiple Guests SERVER HOST KERNEL HYPERVISOR (Type II) KERNEL SERVICE Userland KERNEL KERNEL Userland Userland Userland SERVICE SERVICE SERVER HOST KERNEL Userland Traditional Virtualisation Containerisation
- 14. 14 Multiple Guests SERVER HOST KERNEL HYPERVISOR (Type II) KERNEL SERVICE Userland KERNEL KERNEL Userland Userland Userland SERVICE SERVICE SERVER HOST KERNEL Userland Traditional Virtualisation Containerisation Docker
- 15. 15 Multiple Guests SERVER HOST KERNEL HYPERVISOR (Type II) KERNEL SERVICE Userland KERNEL KERNEL Userland Userland Userland SERVICE SERVICE SERVER HOST KERNEL Userland Userland (#1) Userland (#2) Traditional Virtualisation Containerisation Docker
- 16. 16 Multiple Guests SERVER HOST KERNEL HYPERVISOR (Type II) KERNEL SERVICE Userland KERNEL KERNEL Userland Userland Userland SERVICE SERVICE SERVER HOST KERNEL Userland Userland (#1) Userland (#2) SERVICE SERVICE Traditional Virtualisation Containerisation Docker
- 17. HOST container1 17 Docker Internal View •Containers are ‘grouped processes’ isolated by Kernel Namespaces (PID, network, mount, …) resource restrictions applicable through CGroups bash ls -l container2 apache container3 mysqld container4 slurmd ssh
- 18. • 1/2 Day,July 16th @ISC High Performance Deep dive into the talking points How Docker might impact System Operations & HPC Applications Further discussion beyond what I am talking about today 18 Docker Workshop
- 19. • Full Day,September 28th @ISC Cloud&BigData 19 Docker Workshop #2
- 20.
- 21. • Framework ofsystem container to spin up stacks SLURM 21 QNIBTerminal
- 22. • Framework ofsystem container to spin up stacks SLURM 22 QNIBTerminal
- 23. • Framework ofsystem container to spin up stacks SLURM 23 QNIBTerminal
- 24. • Framework ofsystem container to spin up stacks SLURM 24 QNIBTerminal 1 2 3
- 25.
- 26. • Current monitoringsystems do not connect overlaying metrics with log events use/build inventory system to provide connections usually hidden users perspective and scope/context/background 26 QNIBMonitoring
- 27. • Current monitoringsystems do not connect overlaying metrics with log events use/build inventory system to provide connections usually hidden users perspective and scope/context/background • QNIBMonitoring provides open metrics system (system / application metrics, log aggregates) log event framework, consuming/processing/visualise events auto discovery / configuration through consul 27 QNIBMonitoring
- 28. 28 QNIBMonitoring • Logstash (Log/EventMonitoring)
- 29. 29 QNIBMonitoring • Grafana (PerformanceMonitoring)
- 30. 30 QNIBMonitoring • Overlay Metricsw/ Events
- 31.
- 32.
- 33.
- 34.
- 35.
- 36. • Enrich Log/Events •Help visualise connections 36 QNIBInventory
- 37. • Enrich Log/Events •Help visualise connections • Build up history 37 QNIBInventory
- 38.
- 39. • Multiple backgroundshave to be considered Enduser (Engineer, Software Developer, Scientist) Operation Personel Management • Psychology plays important role Local rationality / context 10.000ft Overview vs. verifying hypothesis vs. Reporting Empower users to extend their domain knowledge by providing toolset 39 Context Sensitive Dashboards
- 40. • Small SLURMcluster couple of nodes, two user groups, couple of users script & MPI workload 40 Cluster Usecase
- 41. • Small SLURMcluster couple of nodes, two user groups, couple of users script & MPI workload 41 Cluster Usecase srv backend consul slurmctld slurmctld compute0 slurmd compute<N> slurmd Compute
- 42. • Small SLURMcluster couple of nodes, two user groups, couple of users script & MPI workload 42 Cluster Usecase srv backend consul slurmctld slurmctld compute0 slurmd compute<N> slurmd Compute
- 43. • Small SLURMcluster couple of nodes, two user groups, couple of users script & MPI workload 43 Cluster Usecase srv backend consul slurmctld slurmctld compute0 slurmd compute<N> slurmd Compute carbon carbon graphite-api graphite-api Performance grafana grafana
- 44. elasticsearch • Small SLURMcluster couple of nodes, two user groups, couple of users script & MPI workload 44 Cluster Usecase srv backend consul slurmctld slurmctld compute0 slurmd compute<N> slurmd Compute carbon carbon graphite-api graphite-api Performance grafana grafana Log/Events elasticsearch logger logstash kibana kiabana kopf es-kopf
- 45. elasticsearch • Small SLURMcluster couple of nodes, two user groups, couple of users script & MPI workload 45 Cluster Usecase srv backend consul slurmctld slurmctld compute0 slurmd compute<N> slurmd Compute carbon carbon graphite-api graphite-api Performance grafana grafana Log/Events elasticsearch logger logstash kibana kiabana kopf es-kopf neo4j neo4j Inventory inventory QINBInv
- 46. elasticsearch • Small SLURMcluster couple of nodes, two user groups, couple of users script & MPI workload 46 Cluster Usecase srv backend consul slurmctld slurmctld compute0 slurmd compute<N> slurmd Compute carbon carbon graphite-api graphite-api Performance grafana grafana Log/Events elasticsearch logger logstash kibana kiabana kopf es-kopf neo4j neo4j Inventory inventory QINBInv postgres postgres galaxy galaxy galaxy
- 47. • Live clusterStatus Utilisation per cluster / user / user-group SLA met by SysOps Most common jobs, misbehaving enduser 47 Management Context
- 48. • Live clusterStatus Utilisation per cluster / user / user-group SLA met by SysOps Most common jobs, misbehaving enduser • Reports per day / user / job-type / … 48 Management Context
- 49. • Live clusterStatus Utilisation per cluster / user / user-group SLA met by SysOps Most common jobs, misbehaving enduser • Reports per day / user / job-type / … • Capacity Planning utilisation over time, comparison of HW generations, global FS capacity 49 Management Context
- 50.
- 51.
- 52. • Nodes areconnected to Partitions 52 SLURM Inventar
- 53. • Nodes areconnected to Partitions • Jobs are connected to both 53 SLURM Inventar
- 54.
- 55. • Live progressof SLURM job Monitor iteration speed to estimate workload behaviour Get to know job while it’s running (instead of postmortem) Introduce application profiling / log events (enhance feedback) 55 Enduser Context
- 56. • Live progressof SLURM job Monitor iteration speed to estimate workload behaviour Get to know job while it’s running (instead of postmortem) Introduce application profiling / log events (enhance feedback) • Post Mortem Get detailed report after job has finished 56 Enduser Context
- 57. • Live progressof SLURM job Monitor iteration speed to estimate workload behaviour Get to know job while it’s running (instead of postmortem) Introduce application profiling / log events (enhance feedback) • Post Mortem Get detailed report after job has finished • MDO jobs depending on outcome and progression submit next iteration(s) 57 Enduser Context
- 58.
- 59.
- 60. • Live clusterStatus USE method overviews (Utilisation/Saturation/Errors) Anomaly detection (w/ and w/o humans) Spotting abnormal behaviour 60 SysOps Context
- 61. • Live clusterStatus USE method overviews (Utilisation/Saturation/Errors) Anomaly detection (w/ and w/o humans) Spotting abnormal behaviour • Drill into monitoring verify hypothesis about incidents/problems correlate events, metrics and inventory 61 SysOps Context
- 62. • Live clusterStatus USE method overviews (Utilisation/Saturation/Errors) Anomaly detection (w/ and w/o humans) Spotting abnormal behaviour • Drill into monitoring verify hypothesis about incidents/problems correlate events, metrics and inventory • Guid through ‘known problems’ close feedback loops provide confidence 62 SysOps Context
- 63.
- 64.
- 65.
- 66. 66 Galaxy Use-Cases SLURM Log Events WORKFLOW Metrics Inventory •Model Assess Workflow in Galaxy Easy to grasp (in contrast to Hadoop, Spark, …) Event triggered, Cronjob? Using idle compute resources
- 67. 67 Thank you! • Contact christian@qnib.org @CQnib,@_qnib • Web www.qnib.org (blog) doc.qnib.org (Paper) • Feel free… …ask questions (now / later) …ask for a Demo
