13-Feb-24 Advanced Programming
Spring 2002
Web programming
Henning Schulzrinne
Dept. of Computer Science
Columbia University

Spring 2002
2
Web programming
 Web services vs. "classical" web
programming
 Client vs. server programming
 client: JavaScript, Java
 HTML-centric vs. program-centric
 HTML-centric: PHP, ASP
 cgi, fast-cgi
 (Java) servlet
 data model: Java servlet, database

Spring 2002
3
Web services vs. web
programming
 web services = remote procedure call
 we saw SOAP
 structured data (XML)
 methods and responses
 generally, for machine consumption
 web programming  generate HTML pages
 for humans
 often, database-driven
 replacement for IBM 3270 terminals ...

Spring 2002
4
Client vs. server
programming
 Execute code on client:
 download Java applet  self-contained
programming environment
 JavaScript (aka ECMAscript):
 modify and get values from HTML ("document
object model" – DOM)
 Execute code on server  generate
document
 state maintenance (HTTP stateless)
 login, shopping cart, preferences

Spring 2002
5
Taxonomy
embedded in HTML separate
server SSI, ASP, PHP, JSP,
CFM
server API (NSAPI),
cgi, servlets
client JavaScript Java applets, plug-in

Spring 2002
6
Example: JavaScript –
cookies
var expires = new Date()
var today = new Date()
function setCookie(name, value, hours) {
var expire = new Date();
expire.setTime (expire.getTime() + (1000 * 60 * 60 *
hours));
document.cookie = name + "=" + escape(value)
+ ((expire == null) ? "" : ("; expires=" +
expire.toGMTString()))
}
function unsetCookie(name) {
var exp = new Date();
exp.setTime(today.getTime() - 10);
document.cookie = name + "=" + "; expires=" +
exp.toGMTString()
}
expires.setTime(today.getTime() + 86400*365)

Spring 2002
7
JavaScript – DOM
function tz (f,v) {
var t = -1;
switch (f[v].value) {
case "US": t=128; break;
case "CI": t=0; break;
case "GH": t=1; break;
..
}
if (t != -1) {
f.form.timezone.options[t].selected = true
}
}

Spring 2002
8
Web as RPC
 request = HTTP GET, PUT
 response (result): headers + body
 object identifier ~ URL
 typed data (XML) vs. HTML
 from constant  mostly constant 
completely on-demand

Spring 2002
9
Server-side include
 .shtml documents (or configured by default
for all .html documents)
 include in HMTL/XML comments
<!-- #element attribute=value
attribute=value ... -- >
 limited scripting: if/else, include, exec,
variables
 primarily for conditional inclusion, boilerplate
 security issues: exec

Spring 2002
10
SSI example
 Columbia CS home page
<html>
<head><TITLE>Computer Science: Welcome </TITLE>
<script language=javascript>
var section = "home";
var subsection = "home";
var subsectionID = "-1";
</script>
</head>



</tr> </table>

</html>

Spring 2002
11
SSI Example
<body>
<h1>SSI Test</h1>
The document was last modified on
<!-- #flastmod file="$DOCUMENT_NAME" 
and has <!-- #fsize
file="$DOCUMENT_NAME" -- > bytes.
<h2>Environment</h2>
<!-- #printenv 
</pre>

Spring 2002
12
Common gateway interface
(cgi)
 Earliest attempt at dynamic web content
 language-independent
 passes HTTP request information via
 command line (ISINDEX) – rarely used
 environment variables: system info + query string
(GET)
 request body (POST)  standard input
 return HTML or XML via standard output
 non-parsed headers (NPH) return complete
response

Spring 2002
13
cgi arguments
 application/x-www-form-urlencoded
format
 space characters  "+"
 escape (%xx) reserved characters
 name=value pairs separated by &
 GET:
foo.cgi?name=John+Doe&gender=male&family=5&city=kent
&city=miami&other=abc%0D%0Adef&nickname=J%26D
 POST: include in body of message

Spring 2002
14
cgi forms
 single form per submission
<form action=scripturi method=GET|POST>
form fields:
<input type="text" name="text1" size=10
maxlength=15 value="Initial text">
<input type="hidden" name="state"
value="secret">
<input type=radio name=radio value=WNYC
checked>
<input type=radio name=radio value=KQED>
<input type=submit value="Submit">

Spring 2002
15
Web state
 State:
 stateless
 state completely stored on client
 state referenced by client, stored on server
(most common)
 Mechanisms:
 hidden form fields
 URL parameters
 cookies (HTTP headers)

Spring 2002
16
cgi mechanics
 either called .cgi in HTML directory or
stored in cgi-bin
 in CS, both /home/alice/html/foo.cgi or
/home/alice/secure_html/foo.cgi work
 executable (script file)
 runs as nobody or as owning user
(~user/mycgi.cgi)
 store secret data off the document tree!

Spring 2002
17
SQL interface
 Most common web model:
 cgi script (or Java servlet) accesses
database
 database via TCP connection (ODBC, JDBC,
script)
 n-tier model:
 delegate "business logic" to RPC-based
server
 XML-based model:
 generate XML, render via XSLT

Spring 2002
18
Tcl cgi example
set env(LD_LIBRARY_PATH) /home/hgs/sun5/lib
load $env(LD_LIBRARY_PATH)/libfbsql.so
lappend auto_path /home/hgs/html/edas3
lappend auto_path /home/hgs/lib
package require cgi
cgi_debug –on
cgi_eval {
sql connect dbhost.columbia.edu dbuser secret
cgi_body {
...
}
sql disconnect
}

Spring 2002
19
Tcl cgi
cgi_body {
h1 "Database view"
set conflist [sql "SELECT
conference,name,url,logo
FROM conference WHERE conference=$c"]
table {
foreach conf $conflist {
maplist $conf c name url logo
table_row {
td "$name"
td "$url"
}
}
}
}

Spring 2002
20
Python for cgi
 Handles processing cgi variables
 need to generate HTML by print
 but separate object-oriented routines
#!/usr/local/bin/python
#!/opt/CUCSpython/bin/python2.2
import os, string, sys
from types import ListType
print "Content-Type: text/html" # HTML is following
print # blank line, EOH

Spring 2002
21
cgi python
print "<title>Python cgi script</title>"
print "<body>"
print "<h1>Python script</h1>"
print "Before script"
print sys.path
try:
import cgi
except:
print "error", sys.exc_info()[0]
# only for Python 2.2!
import cgitb; cgitb.enable()

Spring 2002
22
cgi python
form = cgi.FieldStorage()
if not (form.has_key("name")):
print "<form action=pcgi.cgi method=get>"
print "<input type=text name=name size=10>"
print "<input type=submit value=Submit>"
print "</form>"
else:
print "<p>name:", form["name"].value
print "</body>"

Spring 2002
23
SQL interface
 SQL = more-or-less standard retrieval
language for databases
 Examples:
 Oracle
 Sybase
 IBM DB/2
 Microsoft SQL Server
 mySQL
 PostgreSQL

Spring 2002
24
SQL architecture
 library interface
 proprietary
 JDBC, ODBC
 driver that connects (via TCP) to
database
 same or different host
 issue queries, get results
 modify content
 transactions

Spring 2002
25
SQL basics
 relational database: tables with labeled
columns, combined into database
 columns are atomic types:
create table person (
person integer unsigned auto_increment
primary key,
name varchar(40),
state enum ('', 'AK', 'AL', ...),
biography text,
verified date,
index(name)
)

Spring 2002
26
SQL basics
 Integer: tinyint, smallint,
mediumint, int(eger), bigint
 Floating point: float, double, real
 Decimal: decimal(m,d) (for $)
 Date: date, datetime, timestamp,
time, year
 String: char(N), varchar(N),
tinyblob, tinytext, blob, text,
enum, set

Spring 2002
27
SQL basics
 Retrieval: SELECT field1, field2
FROM table WHERE condition ORDER
BY expression
 Insertion: INSERT table SET
field1=value1,field2=value2, ...
 Update: UPDATE table SET
field1=value1, field2=value2
WHERE expression
 Delete row: DELETE FROM table WHERE
expression

Spring 2002
28
SQL basics: joins
 Join two tables that have a common
value ("product")
 e.g., SELECT lastname,city.name FROM
person,city WHERE city.zip=person.zip AND
lastname='Jones'

Spring 2002
30
SQL Python interface
import MySQLdb
import MySQLdb.cursors
try:
db = connect(host='grandcentral',
user='cs3995', passwd='cs3995',
db='grades')
except MySQLdb.Error, e:
print "Error %d: %s" % (e.args[0], e.args[1])
sys.exit(1)
c = db.cursor()
c.execute("SELECT ... FROM ...")
results = c.fetchall() # list of tuples
c.close()

Spring 2002
31
SQL Python interface
 Results are just tuples, with fields in
order of table definition
 can also fetch one row at a time:
c.execute("SELECT firstname,lastname FROM
students ORDER BY lastname")
print "<ul>"
while (1):
student = c.fetchone()
if student == None: break
print "<li>", student, student[0]
print "</ul>"

Spring 2002
32
Python SQL – dictionary
cursor
 Map rows to dictionary elements instead of
list elements:
c.close()
c = db.cursor(MySQLdb.cursors.DictCursor)
c.execute("SELECT firstname,lastname FROM
students")
results = c.fetchall()
for row in results:
print "%s, %s" % (row["firstname"],
row["lastname"])
print "%d rows were returned" % c.rowcount

Spring 2002
33
Servlet life cycle
 server application loads ServletClass
 creates instance via no-args constructor
 servers call servlet's init() method
 server calls service(req, res)
method for each request (often, with
class name as URL), possibly
concurrently
 servers calls destroy() on shutdown

Spring 2002
34
HTTP requests as servlets
 HTTP method GET, PUT, POST, ... 
doGet, doPut, doPost
 subclass of HttpServlet overrides
default implementation

Spring 2002
35
Servlet example
import java.io.*;
import javax.servlet.*;
import javax.servlet.http.*;
public class HelloClientServlet extends HttpServlet
{
protected void doGet(HttpServletRequest req, HttpServletResponse res)
throws ServletException, IOException
{
res.setContentType("text/html");
PrintWriter out = res.getWriter();
out.println("<HTML><HEAD><TITLE>Hello Client!</TITLE>" +
"<HEAD><BODY>Hello Client!</BODY><HTML>");
out.close();
}
public String getServletInfo() {
return "HelloClientServlet 1.0 by Stefan Zeiger";
}
}

Spring 2002
36
2-tier architecture
 "client-server", "fat client"
 e.g., ODBC on client (PC), accessing
SQL database
 business logic on PC
 (-) transport data across network
 (-) need applications for each platform
 (-) need to update applications on many
desktops

Spring 2002
37
n-tier architecture

Spring 2002
38
n-tier architecture
 client tier:
 receives user events (keyboard, mouse)
 presentation of data
 user interface
 e.g., Java applets, web browser, thin client
application
 application-server tier:
 "business logic"  actual data processing,
algorithms
 can be component-based (Java Beans)

Spring 2002
39
n-tier architecture
 Data-server tier
 data storage
 relational and legacy databases
 all tiers could run on same machine, but
usually separated
 HTTP (or SOAP) from client to server
 Corba or SOAP or remote-SQL between server
tiers
 Advantages:
 independent of storage model
 simpler authentication to database

web programming using html,css, JavaScript ,php etc

More Related Content

Similar to web programming using html,css, JavaScript ,php etc

Recently uploaded

web programming using html,css, JavaScript ,php etc
