SPATIAL R-TREE INDEX BASED ON GRID DIVISION FOR QUERY PROCESSING

International Journal of Database Management Systems ( IJDMS ) Vol.9, No.6, December 2017
DOI : 10.5121/ijdms.2017.9602 25
SPATIAL R-TREE INDEX BASED ON GRID DIVISION
FOR QUERY PROCESSING
Esraa Rslan1
, Hala Abdel Hameed1
and Ehab Ezzat2
1
Faculty of Computers and Information, Fayoum University, Egypt
2
Faculty of Computers and Information, Cairo University, Egypt
ABSTRACT
Tracing moving objects have turned out to be essential in our life and have a lot of uses like: GPS guide,
traffic monitor based administrations and location-based services. Tracking the changing places of objects
has turned into important issues. The moving entities send their positions to the server through a system
and large amount of data is generated from these objects with high frequent updates so we need an index
structure to retrieve information as fast as possible. The index structure should be adaptive, dynamic to
monitor the locations of objects and quick to give responses to the inquiries efficiently. The most well-
known kinds of queries strategies in moving objects databases are Rang, Point and K-Nearest Neighbour
and inquiries. This study uses R-tree method to get detailed range query results efficiently. But using R-tree
only will generate much overlapping and coverage between MBR. So R-tree by combining with Grid-
partition index is used because grid-index can reduce the overlap and coverage between MBR. The query
performance will be efficient by using these methods. We perform an extensive experimental study to
compare the two approaches on modern hardware.
KEYWORDS
MOD, Spatial indexing, R-tree, grid.
1. INTRODUCTION
Moving object applications have become very important in our life and have a lot of usages, such
as GPS car navigator and location-based services. Moving object database is a branch of the
spatial-temporal database research that has been developed recent years, indexing moving object
is one of the key technologies of the moving object database. Tracing the changing positions of
objects has become a serious matter and played an essential role in location-based services, such
as customers with cell phones and cars. These services need to know the current positions of
objects quickly. The index structure should be adaptive and dynamic to keep track of the
positions of objects and to provide quick answers to the expected queries [1].
An example for this is the traffic observing service for a population of 10 mega moving objects
that are processed with speed 15 m/s. Another example is related to expecting objects positions of
an exactness of no less than 100 meters. In this situation, we need up to 1 mega update rate every
second. As the update frequency is growing, the workloads are also increasing. High workloads in
Sidlauskas’s paper can't be managed by traditional disk-based techniques [2]. Rather, we propose
a primary memory index that is compatible with the characteristic of parallelism accessible in
multicore processors. The main goal of the index structure is to keep up a reliable database and
get back the right results.
Indexing techniques are divided into two main groups: tree based and grid based index. Examples
of tree based index are R-tree and its variations R+tree, R*tree, TPR-tree and TPR*tree (Time

International Journal of Database Management Systems (IJDMS ) Vol.9, No.6, December 2017
26
Parametric Rectangle) [3]. Examples of grid based index are a uniform, parallel, hierarchical, and
LU (Luzy Update) grid. There are also many kinds of queries, such as point query and density
query.
The R-tree is famous for its efficiency to support information skew and various query types. It
can be used to index moving objects in a specific region. The idea of the index structure is to
utilize the Minimum Bounding Rectangle (MBR). In any case, due to overlapping between
MBRs, the search might be necessary along different paths causing the exceeding of search paths
[4]. With the expansion in the amount of index data, it will require more storage space.
Subsequently, it will truly influence the search and update efficiency. Though R-tree is known for
its power to support various query types, the main problem with the R-tree is its bad update
leverage. On the other hand, using a grid index in moving objects is considerably faster than an
R-tree in an update and query processing. It is obviously discernible and it can straight forwardly
calculate all objects overlapping with the range query with no need to access the index entities.
In this paper, a robust and scalable index technique is proposed. The main goal is to build a
hybrid index technique that supports a different number of queries with the minimum cost update.
We used the R-tree and grid index together by using R-tree at the root node and grid at the leaf
node to achieve two main benefits. The important benefit is to take the advantage of the two
indexes as the R-tree is good for searching and querying. Also, grid is efficient in update
operations. Experimental studies have shown that the design of the index may help provide
answers to range queries with a great number of moving objects. To verify the efficient and
effectiveness of the three types of indexes (R-tree, Grid, and hybrid R-tree and Grid), we explore
several experiments to make a comparison between them based on the response time with a range
queries and the CPU time in updating objects.
The remaining parts of this paper are organized as follows: in section two we introduce the
background and related work; the aim herein is to briefly explain the R-tree structure and grid. In
section three, the proposed index technique and associated algorithms are explained. In section
four, an analysis of the index structure and the experimental results are shown. The conclusion is
presented in section five.
2. BACKGROUND AND RELATED WORK
In this section, we introduce two main types of moving objects indexing techniques: tree and grid
based indexes.
2.1. Tree Based Index
R-tree is a height balanced tree (all leaf nodes are at the same height). It consists of internal nodes
and leaf nodes. The R-tree is known for its robustness to data skew and it supports different types
of queries. Yet, it is poor in update performance. Numerous applications including indexing the
location of moving objects display workloads described by updates expansion to continuous
queries. Indexes are divided into two categories based on data to be stored: (1) indexing the
historical location of objects and (2) indexing the current location and predicting the future
location of moving objects [3].
An overview of spatial-temporal access techniques can be found in the two papers [5,6]. The two
surveys focus on the indexing of past, current, and future objects' positions. Indexes are divided
into two parts: the first part is from 1980 to 2003, such as the TPR-tree, the TPR*-tree, the Bx-
tree, and the Bdual-tree, STRIPES definition of spatial index is “the primary key to improve the
efficiency of queries”; the second part dates back to the period from 2003 to 2010, such as MON
tree, RTR-tree TPR-tree, Bx-tree and ST2B-tree.

27
Guttman[7] ﬁrst presented an index structure called R-tree for spatial searching. It's known that
R-tree is inefficient in update performance because of overlapping and the splitting of MBR,
though it is efficient in supporting different types of queries. Six variants of R-tree variants are
compared in Manolopouloset al.[8]. The most famous spatial techniques that utilize minimum
bounding rectangles are R-trees [6]and their variation R-trees. In TPR-tree that expands the R-tree
as objects move in linear motion function. Tao introduced the TPR*-tree that enhances the TPR-
tree with advanced insert, update, and delete process. R-tree, TPR-tree, and TPR*-tree have low
efficiency in updates because of their node splitting and reinsertion operations. Other than R-
trees, B-trees, and Quadtrees[9] ,some indexes can likewise be utilized to moving entities. The
B+-tree, proposed by Jensen et al.[10] utilizes space ﬁlling curves like Hilbert curves or Z-curves
that are used in mapping dimensional locations.
2.1.1 Structure
R-tree consists of internal nodes and leaf nodes [11]. The internal node has pointers to other
nodes; leaf node has pointers to objects (entries). As shown in figure 1, R-tree satisfies the
following properties:
1. Every leaf node has between m and M entries unless the node is the root node, where M is the
maximum set of records in a node, m is the minimum number of records that can be held in a
node and let m<=M/2.
2. For every index entity (I, tuple-identifier) in a leaf node, I is the smallest rectangle that has the
object and tuple-identifier is a unique number that identifies the record in the database.
3. Each non-leaf node contains between m and M children.
4. For each entry (I, child-pointer) in a non-leaf node, I is the smallest rectangle that overlays all
the rectangles in the child node, the child-pointer is the address of the lower node.
5. The root node contains at least two child nodes unless it is a leaf.
6. All leaf nodes should be at the same grade.
Figure 1. An example of R-tree

28
Figure 2 shows the structure of R-tree in on every node, there are Node Size (ns) number of each
node and Minimum Children (mc) a fraction of the full nodes which are the essential attributes in
the R-tree [12]. A leaf node contains node metadata like a number of entries, MBR, leaf flag, the
id of the parent node, a number of leaf entries and a pointer to the parent node at the end. Likely,
internal node consists of the same metadata fields in the leaf node, but the differences between
them are the child pointer and MBR, where the MBR is the smallest rectangle that gathers the
spatial entities together.
Figure 2. Structure of R-tree
2.1.2 Update, Insertion, and Deletion
Every update operation deletes the object from place and inserts it in another one. Assume the
point P (oldX, oldY) is needed to be updated; first we search the tree from root to leaves until we
find the node with MBR that have point P (oldX, oldY), more than one path are visited because of
the overlapping between MBRs, then delete the point, but be careful that no underflow occurs
(less than the minimum number of entries, often denoted as m). After the deletion operation is
done, the insertion is applied. The insertion traverses the tree from root to leaves to find the
suitable leaf node and insert (newX, newY). Insertion may cause overflow node (extends the
maximum number of objects denoted as M). There are many variations of the R-tree in the
literature; the uniform R-tree in is only considered.
2.1.3 Query Processing
Two main types of queries are discussed: Range Query and K-nearest neighbour query. A range
query is processed by accessing the tree from the root to the leaves if the present node is not a
leaf; check every internal node MBR that intersects or overlaps with the MBR of the range query.
2.2 Grid Based Index
Grid is a pre-defined partitioning index in which the region is partitioned into rectangular cells
because it indicates the pre-defined spatial region. Grid covers a part of the space that object
position is inside the boundaries of a grid cell and this object belongs to this cell. Šidlauskaset al
[12] proposed the grid index which is one of the principal framework index structures for moving

29
objects database. D-Grid [13] enhances U-Grid which it indexes both the location and velocity of
moving objects in the dual space. The dual space is a 2-dimensional Euclidean space, with a ﬁrst
dimension for velocity and the other for location. Another index structure that is based on grid
cell and continuous k-nearest neighbor query processing is proposed by Wei Zhang [14].
Existing Concurrency Control (CC) methods for multidimensional indexes are also introduced
like Šidlauskaset al. [15] who proposed the TwinGrid and the PGrid[16]give high query and
update performance. PGrid makes various duplicates of information on a request and at the object
granularity (i.e., non-local objects).
2.2.1 Structure
Grid is a 2-d array that every cell in the array matches to a square cell with a length of grid cell
size. Every grid cell in the array has a link to a list of buckets which contains the data object [12].
Each bucket has bucket size bs and metadata fields where metadata contains the next bucket, the
number of entries and pointer to the next bucket. Grid is defined by two main parameters: gcs,
and bs.
Figure 3. Grid index structure
2.2.2 Update, Insertion, and Deletion
All updates operations are classified into two sets: local and nonlocal. The update is considered
local when the new object location falls in the same cell and we need only to change the (oldX,
oldY) with the (newX, newY). Otherwise, the update is non-local (new location not in the same
cell) as the object will be deleted from its current cell, and it will then be inserted inside the new
cell. During the insert operation, the new object is always put at the end of the first bucket. In the
condition that the first bucket is complete and has no space, a new bucket is created and the
pointers are upgraded to make the new bucket the first one. If the first bucket is empty, the next
bucket becomes the first one.
2.2.3 Query Processing
The range query divides the cells, which overlap in the range query into two categories: the
completely and the partly covered cells. Only the objects that are partly covered are needed to be
listed in order to know if they are inside the range or not. KNN algorithm is known by a point P
and the numbers of nearest neighbour k, cells are divided into different sets. Every set has the
minimum range to the point P. Similar to the KNN query in the tree index, the queue is used to
store these cells as they are sorted from the nearest to the farthest.

30
3. PROPOSED INDEX TECHNIQUE
R-tree and grid-partition index is proposed, which give execution enhancements in handling
different types of queries like range and KNN queries. The proposed index has two main standard
data structures: the first is the R-tree and the second one is a grid index. The R-tree is used to
divide the space into MBRs then a grid is used in non-leaf nodes to store the data object and to
reduce the overlapping between MBRs.In grid implementation, divide space into M x M grid of
squares, create linked list for each square, use 2D array to directly access relevant square. It
performs less maintenance effort as no grid changes are needed to be done in a grid updates.
It is known that if the number of objects increases a lot of overlapping and converging between
MBRs will be generated, approximately; each single update will need about four tree traversals
affecting the performance significantly. To reduce node splitting in the R-tree, a grid is used to
store data objects at leaf level. The performance of grid in inserting, deleting, and updating
algorithms is superior to the R-tree, so it can highly decrease the time complexity of an algorithm.
Extensive and broad experiments reveal that our proposed index structure essentially outperforms
and beats the existing grid index or R-tree index in single threaded environments.
As shown in figure 4, the index structure has two data structures: the root level is R-tree and each
non leaf node is in a grid index structure, taking the advantages of both Tree and Grid index. R-
tree is very powerful in supporting different types of queries with minimum time response. In
addition, the grid is the best choice in updates because no grid re-adjusting should be done
through updates, also grids require less repair effort and index speed is quick. We take the
advantage of each one of these indexes in update and query processing. In a query range, grids
can number all index objects that cover the range query with no need to access to the index
records.
Figure 4. The new index structure

31
3.1 Index structure
The R-tree is used to implement both root and parent levels, which utilize the MBR to partition
the regions, and child node uses a grid to implement MBR with equal sized cells. The grid
needs insignificant update costs. Hence, no framework re-adjusting is done when objects
change their locations. The index structure is as follows:
1. It has a root node in R-tree.
2. Non-leaf node contains the internal nodes that have the tuple <mbr, ptr> where the mbr is
the minimum bounding rectangle of the node and ptr is an indicator to point to the next
level node.
3. Leaf node is in grid coordination that divides the MBR into M x M cells, the grid is a 2-d
array that every cell in the array matches to a square cell with a length of Grid Cell Size
(gcs).
4. At leaf node, grid squares store a pointer to the list of buckets which have the object data.
In a huge size of data, getting the relationships from the grid index can highly minimize
the complexity of the algorithm in contrast to the conventional R-tree methods. Grid
coordinate makes the position of spatial entity objects clear, so reduces the repetition of
storage. Also, to avoid the search operation costs.
3.2 Update, Insertion, and Deletion
The R-tree operates every update as a companion of two processes: delete and insert, traversing
the tree top- down to locate the suitable leaf and update it. Algorithm 1 is proposed for inserting
the new object. The algorithm takes a new object as an input with a unique id, and then inserts it
at the index. The first step, the algorithm searches the tree from the root t to leaf to find the
suitable child node by searching in the node of min.x≦x≦max.x in x-dimension according to
MBR coordinates (min.x, min.y, max.x, max.y) of this object. If it is true, go to the second step,
then go to the fourth step. The second step, if the MBR is found, the insertion operation is done
by inserting the object into the suitable grid cell based on (x, y) of the new object as the child
node is implemented in grid coordination. The third step, the new object is always put at the end
of the first bucket in the grid. If the first bucket is complete and has no space, a new bucket is
created and the pointers are upgraded to make the new bucket the first one. Otherwise, the first
bucket is empty, and then the following bucket is the first one. The first free location at the end of
the bucket is located, and the new record is also inserted. The fourth step, if the no MBR is found,
create a child node approximate to X-value, Y-value and its leaf node (x, y) and insert the new
object into the grid expressed by the leaf node.
Algorithm1: insert (ObjectTuple new(n), Cell cell)
1. Search object n in tree
2. if tree is non-leaf // then for each entry in n do
3. if EI overlaps n // true… insert new object in the index
4. firstBucket= *cell ; // the 1st bucket is equal to reference cell
5. if Full(firstBucket) // if firstbucket is full ..create new bucket and make it first ;
6. freePosition= firstBucket.entries[firstBucket.nO] // first free location of the first bucket is
located
7. insertObject(n, freePosition); // the new object is inserted
8. elseCreate child node (ObjectTuple new(n)) //false…. No MBR found

32
The update process in algorithm 2 takes a new object (newx, newy) as an input. Based on its
position, the tree is searched to find the MBR node that overlaps with the object. After locating
the node that has the object to be updated according to its oldx, oldy. The information is retrieved
from the primary index (the location of the object, current cell of object), then the algorithm
determines the update type whatever is it local or not by contrasting the new and old positions.
The out-dated object tuple is over-written with the new x and newly if the update is local as well,
the old object tuple is deleted (call delete algorithm) and the new object tuple is inserted into the
appropriate child node,” update is non-local”.
Algorithm 2: update(ObjectTuple new (new))
1. Search in obj Tree t
2. if EI overlaps obj
3. SearchSubTree(EP, obj)
4. newCell= computenewCell(newx, newy);// new cell is located for the object
5. if newCell = = oldCell // Local update .. in the same cell
6. overwriteObject(new, obj); // obj is overwritten new
7. else // Non-local update
detete (obj);//delete the old object tuple
insert(new); // insert the new object and update the index
In algorithm 3, the delete operation is done as follows: First, search in the tree until finding the
child node that contains the object that we want to delete. Second, as child node is implemented
in grid coordination. Third, after finding the object the algorithm seeks to shift the last object of
the first bucket into the place of the deleted object; all pointers (pointer1, pointer2, and idx) of the
last object are modified accordingly in the secondary index. Fourth, if the first bucket was empty,
it is erased and the following bucket is the first or the grid cell becomes empty, put a null pointer
in the cell.
Algorithm 3: delete(ObjectTuple obj)
1. Searchobj in Tree t
2. if t is not a leaf //then for each entry E in t do
3. if EI overlaps obj
4. SearchSubTree(EP, obj)
5. firstBucket = * sindex.ldCell; // cell refers to the frist bucket
6. lastObject = firstBckt.entries[firstBckt.nO - 1];
7. if firstBucket.nO == 0 then // is empty?
8. * sindex.ldCell = firstBucket.next;
9. free(firstBucket);
10. update all pointers of deleted object
3.3 Query Processing
The range query is explained and how it works.
3.3.1 Range Query
In range query, the resulting cells that overlap with the range query is divided into the completely
and the partly covered cells. The objects that are partly covered are needed to be listed in order to
know if they are inside the range or not. The input is the query box q (x0, y0, x1, y1) in which (x0,
y0) and (x1, y1) are the lower-left and the upper-right corner coordinates respectively. First, the
algorithm searches the node of x1 ≥x ≥x0 in dimension x based on the coordinates (x0, y0, x1,
y1) of the q in the MBR of the child node; if it has the node of x value. Then, it searches each

33
node of Max.y1 ≥ y ≥ Min.y0 corresponding to the x-value; if there exists the node of y-value, go
to bucket number 1and increment the reader (R) of a bucket before coming into it and decrement
it when the bucket has been examined. Finally returns the objects which are covered by the query
range in the result set.
4. EXPERIMENTAL RESULTS
In order to check the performance of the proposed technique, we compare it with both traditional
R-tree and grid by providing an overview of the performance and showing the average CPU time
of individual update, range and I/O visits.
4.1 Index Implementations
The index structure is implemented using C++ and compiled with g++ under the Linux. The test
environment uses Windows Seven with 64-bit OS, Core (TM) i3-2.10 GHz, 6GB RAM. The
indexes are studied under massive datasets; these datasets are generated using an Open-source
Moving Object Trace generator (MOTO) that is based on Brinkhoff [17] moving-object
generator. Objects move into a network-based roads in five German cities. Table 1 shows the
Experimental settings of the generator; the default values are in bold.
Table1. The Experimental settings of the generator
Dataset Parameters Values
Number of objects (×10 ) 5, 10, 20, 40, 80
Number of Updates (×10 ) 300
Monitored region (KM ) 641 × 864
Velocity(kilometer/hour) 20, 30, 40, 50, 60, 90
Update/queryratio 250:1, …1000:1, …16000:1
Time through updates (s) 10, 20, 40, 80, 160
k nearest neighbor (×10 ) 0.5,1,2, 4, 8, 16, 32
# network segments 32,750,494
# network nodes 28,933,679
4.2 Comparison of the Indexes
A comparative experiment was done to compare the efficiency of the proposed hybrid index and
the conventional R-tree and grid under different conditions and parameters. The different index
behaviour of the total CPU update time and different number of moving objects are shown in
Figure 5. When the number of objects exceeds, the new index outperforms both R-tree and the
grid. With the Grid parameters, it still performs updates a little better and performs similar (range)
query performance with the tree in figure 6.

34
Figure 5. Increasing number of objects in update operation
Figure 6. Increasing number of objects in range query

35
Figure 7. Number of I/O visits
I/O visits are shown in figure 7 when inserting in different number of spatial entity objects in
queries.The results exhibit that the new index structure is outperforming than the conventional R-
tree because after dividing the region into the first MBRs using R-tree, each MBR is partitioned
using the grid. In querying, locate the grid cell connected to the MBR of the objects, because leaf
nodes contain the data objects. The tree is built based on the (x, y) value of the grid cells, so it can
speedily find the grid cell of the related object based on the MBR coordinates of the entity object
and insert the object into the related leaf-node; if the MBR of this object not found in the tree, we
create a new child node. In a huge size of data, getting the relationships from the grid structure
can highly minimize the complexity of the algorithm contrast to the conventional method of
looking for MBR containing the spatial entries.
5. CONCLUSIONS
A new spatial index technique based on spatial grid coordinates division is introduced, and the
description of its data structure and algorithm is also given, we compared the hybridized index
with the traditional r-tree index, and grid. The new index can reduce the overlapping and
coverage between intermediate nodes. The important point in the new index is to retrieve quickly
data and give speed answer effectively based on the current location like knowing the locations of
schools, clinics, bazaars, mini-marts that can be used by various levels of people. The index
structure is very flexible, so it can improve the retrieval performance of spatial entity objects, and
has a better application in practice.
REFERENCES
[1] W. Choi, B. Moon, and S. Lee, "Adaptive cell-based index for moving objects," Data & Knowledge
Engineering, vol. 48, pp. 75-101, 2004.
[2] D. Sidlauskas, S. Saltenis, and C. S. Jensen, "Processing of extreme moving-object update and query
workloads in main memory," The VLDB Journal The VLDB Journal : The International Journal on
Very Large Data Bases, vol. 23, pp. 817-841, 2014.
[3] Y. Tao, D. Papadias, and J. Sun, "The TPR*-tree: an optimized spatio-temporal access method for
predictive queries," in Proceedings of the 29th international conference on Very large data bases-
Volume 29, 2003, pp. 790-801.
[4] N. Beckmann, H.-P. Kriegel, R. Schneider, and B. Seeger, "The R*-tree: an efficient and robust
access method for points and rectangles," in Acm Sigmod Record, 1990, pp. 322-331.

International Journal of Database Management Systems (IJDMS ) Vol.9, No.
[5] M. F. Mokbel, T. M. Ghanem, and W. G. Aref, "Spatio
Bull., vol. 26, pp. 40-49, 2003.
[6] L.-V. Nguyen-Dinh, W. G. Aref, and M. Mokbel, "Spa
2010)," 2010.
[7] A. Guttman, "R-trees: a dynamic index structure for spatial searching," presented at the Proceedings
of the 1984 ACM SIGMOD international conference on Management of data, Boston, Massachusetts,
1984.
[8] Y. Manolopoulos, A. Nanopoulos, A. N. Papadopoulos, and Y. Theodoridis, R
Applications: Springer Science & Business Media, 2010.
[9] Y. Xia and S. Prabhakar, "Q+ Rtree: Efficient indexing for moving object databases," in Database
Systems for Advanced Applications, 2003.(DASFAA 2003). Proceedings. Eighth International
Conference on, 2003, pp. 175-
[10] C. S. Jensen, D. Lin, and B. C. Ooi, "Query and update efficient B+
objects," in Proceedings of the Thirtieth international conference on Very large data bases
30, 2004, pp. 768-779.
[11] Y. Gui-juna and Z. Ji-xianb, "A Dynamic Index Structure for Spatial Database Querying Based on R
Trees," in Proceedings of International Symposium on Spatio
Analysis, Data Mining and Data Fusion, 2005, pp. 27
[12] D. Šidlauskas, S. Šaltenis, C. W. Christiansen, J. M. Johansen, and D. Šaulys, "Trees or grids?:
indexing moving objects in main memory," in Proceedings of th
international conference on Advances in Geographic Information Systems, 2009, pp. 236
[13] X. Xu, L. Xiong, and V. Sunderam, "D
databases," in Mobile Data Management (MDM
pp. 252-261.
[14] W. Zhang, J. Li, and H. Pan, "Processing continuous k
application," Int’l Journal of Computer Science and Network Security, vol. 6, pp. 1
[15] D. Šidlauskas, K. Ross, C. Jensen, and S. Šaltenis, "Thread
moving-object workloads," Advances in Spatial and Temporal Databases, pp. 186
[16] D. Šidlauskas, S. Šaltenis, and C. S. Jensen
and update workloads," in Proceedings of the 2012 ACM SIGMOD International Conference on
Management of Data, 2012, pp. 37
[17] T. Brinkhoff, "A framework for generating network
pp. 153-180, 2002.
AUTHORS
Esraa Rslan was born in 1991. She received the B.S. degree in Faculty of Computers
and Information from Fayoum University, Egypt, in 2012. She is M. S. candidate. Her
research interests include Database Managements, Spatial Databases and Database
Query Processing. Her E-mail is eaa06@fayoum.edu.eg
Hala Abdel Hameed Mostafa was born in 1977. She received the B.S. degree in
Faculty of Computers and Information from Helwan University, Egypt, in 2000. She
had a Ph.D. in Computer and Information Systems from Mansoura University, 2012
and Master of Computer Science from Helwan Un
at Faculty of Computers and Information Systems, Fayoum University. You can reach
her at ham07@fayoum.edu.eg
Ehab Ezzat Hassanein hold a Master degree in Computer Science from
Northwestern University in 1989.A Ph.D. from Northwestern University in December
1992. Now he is Chairman of the Information Systems Department of Computers and
Information Faculty, Cairo University, Egypt. He
cu.edu.eg
International Journal of Database Management Systems (IJDMS ) Vol.9, No.6, December
M. F. Mokbel, T. M. Ghanem, and W. G. Aref, "Spatio-temporal access methods," IEEE Data Eng.
49, 2003.
Dinh, W. G. Aref, and M. Mokbel, "Spatio-temporal access methods: Part 2 (2003
trees: a dynamic index structure for spatial searching," presented at the Proceedings
Y. Manolopoulos, A. Nanopoulos, A. N. Papadopoulos, and Y. Theodoridis, R-trees: Theory and
Applications: Springer Science & Business Media, 2010.
Y. Xia and S. Prabhakar, "Q+ Rtree: Efficient indexing for moving object databases," in Database
-182.
C. S. Jensen, D. Lin, and B. C. Ooi, "Query and update efficient B+-tree based indexing of moving
he Thirtieth international conference on Very large data bases
xianb, "A Dynamic Index Structure for Spatial Database Querying Based on R
Trees," in Proceedings of International Symposium on Spatio-temporal Modeling, Spatial Reasoning,
Analysis, Data Mining and Data Fusion, 2005, pp. 27-29.
D. Šidlauskas, S. Šaltenis, C. W. Christiansen, J. M. Johansen, and D. Šaulys, "Trees or grids?:
indexing moving objects in main memory," in Proceedings of the 17th ACM SIGSPATIAL
international conference on Advances in Geographic Information Systems, 2009, pp. 236
X. Xu, L. Xiong, and V. Sunderam, "D-grid: An in-memory dual space grid index for moving object
databases," in Mobile Data Management (MDM), 2016 17th IEEE International Conference on, 2016,
W. Zhang, J. Li, and H. Pan, "Processing continuous k-nearest neighbor queries in location
application," Int’l Journal of Computer Science and Network Security, vol. 6, pp. 1-9, 2006.
D. Šidlauskas, K. Ross, C. Jensen, and S. Šaltenis, "Thread-level parallel indexing of update intensive
object workloads," Advances in Spatial and Temporal Databases, pp. 186-204, 2011.
D. Šidlauskas, S. Šaltenis, and C. S. Jensen, "Parallel main-memory indexing for moving
Management of Data, 2012, pp. 37-48.
T. Brinkhoff, "A framework for generating network-based moving objects," GeoInformatica, vol. 6,
was born in 1991. She received the B.S. degree in Faculty of Computers
and Information from Fayoum University, Egypt, in 2012. She is M. S. candidate. Her
e Database Managements, Spatial Databases and Database
eaa06@fayoum.edu.eg
was born in 1977. She received the B.S. degree in
Faculty of Computers and Information from Helwan University, Egypt, in 2000. She
had a Ph.D. in Computer and Information Systems from Mansoura University, 2012
and Master of Computer Science from Helwan University, 2006. She is now Lecturer
at Faculty of Computers and Information Systems, Fayoum University. You can reach
hold a Master degree in Computer Science from
Northwestern University in 1989.A Ph.D. from Northwestern University in December
1992. Now he is Chairman of the Information Systems Department of Computers and
Information Faculty, Cairo University, Egypt. He may be reached at e.ezat@fci-
6, December 2017
36
temporal access methods," IEEE Data Eng.
temporal access methods: Part 2 (2003-
trees: a dynamic index structure for spatial searching," presented at the Proceedings
trees: Theory and
Y. Xia and S. Prabhakar, "Q+ Rtree: Efficient indexing for moving object databases," in Database
tree based indexing of moving
he Thirtieth international conference on Very large data bases-Volume
xianb, "A Dynamic Index Structure for Spatial Database Querying Based on R-
emporal Modeling, Spatial Reasoning,
D. Šidlauskas, S. Šaltenis, C. W. Christiansen, J. M. Johansen, and D. Šaulys, "Trees or grids?:
e 17th ACM SIGSPATIAL
international conference on Advances in Geographic Information Systems, 2009, pp. 236-245.
memory dual space grid index for moving object
), 2016 17th IEEE International Conference on, 2016,
nearest neighbor queries in location-dependent
9, 2006.
level parallel indexing of update intensive
204, 2011.
memory indexing for moving-object query
objects," GeoInformatica, vol. 6,

SPATIAL R-TREE INDEX BASED ON GRID DIVISION FOR QUERY PROCESSING

More Related Content

What's hot

Similar to SPATIAL R-TREE INDEX BASED ON GRID DIVISION FOR QUERY PROCESSING

Recently uploaded

SPATIAL R-TREE INDEX BASED ON GRID DIVISION FOR QUERY PROCESSING
