• 2.
  Pods & Containers 0203 Pods A pod is the smallest unit in Kubernetes Pods are also responsible for managing resources for the containers inside them, like memory, CPU, and storage. Each pod runs on a node
• 3.
  Pods & Containers 0203 Container A container is where your actual application runs. It includes everything the app needs to function Think of a container like a small box that has your app and everything it needs to run
• 4.
  02 03 Pods &Containers Ecommerce Store Frontend Container Backend Container DB Pod
• 5.
  Worker Nodes 02 03 NodeProcess Worker nodes are the machines (either physical computers or virtual machines) where your applications actually run.
• 6.
  Worker Nodes 03 Container Runtime TheContainer Runtime is like the engine of your worker node. It is responsible for running your applications, which are packaged into containers. My-app DB Node 1 Container Runtime
• 7.
  Worker Nodes 03 Kubelet The Kubeletis like a manager that oversees everything happening on the worker node My-app DB Node 1 Container Runtime Kubelet
• 8.
  Worker Nodes 0 3 My-app DB Node 1 Container Runtime Kubelet My-app DB Node2 Container Runtime Kubelet DB Services Think of Kube Proxy as the traffic director for your Kubernetes cluster.
• 9.
  Master Nodes Master Process Node1 Node 2 Client Api Server
• 10.
  Master Nodes Master Process Node1 Node 2 Client Api Server Scheduler
• 11.
  Master Nodes Master Process Node1 Node 2 Client Api Server Scheduler Controller Manager
• 12.
  Master Nodes Master Process Node1 Node 2 Client Api Server Scheduler Controller Manager etcd
• 13.
  Example : ClusterSetup Node 1 Node 2 Node 3 Node 4 Master Node 1 Master Node 2 Create Pods Scheduler Kubelet Manages Pods Kube Proxy Controller Manager etcd Keeps Track
