Java developer intro to environment management with vagrant puppet and docker

Lucas Jellema
JavaOne 2015, San Francisco, 26th October 2015
Java Developer Intro to Environment
Management with
Vagrant, Puppet, and Docker

3
Who are you?
• Developer or Administrator – Java, Oracle, Web, NoSQL, …
– Perhaps on a non-Linux laptop
• Limited physical computer resources
– CPU, Memory, Disk Space
• Inclined to try out new stuff – frameworks, tools, products, …
– Quickly, smoothly, without messing up your environment
• Create things you want to share
– Without creating elaborate instructions for installing and configuring
– Without discussions around ‘it works on my machine’ , ‘send me your config files’
• Interested in running stuff on “the cloud”
• No Linux allergy
• Interested in ‘that Docker thing’
• (a bit like me)

4
This session will give you
• What is this Docker thing and why is it a hype?
• How do Containers compare to Virtual Machines?
• How can I build, ship [| share | distribute] and run containers?
– On my local machine and in the cloud?
• A way to more efficiently leverage the physical resources in my computer?
– than through juggling VMs
• A structured and fast way to try out new software
– Without messing up my local environment.
• What tools do I need to get started with Docker
on my non-Linux laptop?
• What is the status of Docker and where is it going?
• How can I get going on my own with Docker?

5
Supporting Materials
• The slides for this presentation
• All demo scripts
• Extended slides with more details and examples
• Workshop Introduction Docker + Vagrant + Puppet
SOME TINY
URL:

6
Run
• Docker Container runs Linux – as does the host
• Container is isolated - feels as
stand alone run time environment
– Directory structure, IP address, users and groups
• Shared resources with underlying host
(and therefore other containers)
– memory, CPU, host
• Light weight:
– Quick starting up and stopping
– Leverages underlying Linux kernel, only adds what is different/additional
– Far less physical resource requirements (disk space and memory) than VMs
• Clusters of containers
– Dynamic adding/removing containers from clusters can be done very quickly (Google)
– Especially when containers are stateless
– (no shared session state in containers; possibly in joint cache, shared file system or
NoSQL database)
• Management tools – to monitor and manage individual containers and clusters
of containers (dynamically scale up/scale down)
Docker Host
Docker Container
Docker Container
• ip address
• directories & files
• users & groups
• process table

7
Demo – Run our first Docker
container based on the nginx image

8
Demo –running NGINX container;
with port forwarding
port 80
port 90
IP 172.17.0.7

9
Demo: run container for Ubuntu image
in interactive mode using shell
dockerhost
/tmp/mynewfile.txt

10
Demo: restart container and
attach to it and locate my file
dockerhost
/tmp/mynewfile.txt

11
Micro Services
• Architect the application into a set of collaborating services.
• Each service implements a set of narrowly, related functions.
• The services are elastic, resilient, composable, minimal, and complete.
• Services communicate using standard protocols such as HTTP/REST
• Services are developed
and deployed independently
of one another.
• Each service manages its own state

12
Micro Services
• With Docker, each Micro Service is implemented with a single container
– The micro service is not just encapsulated functionality that needs to be deployed
onto some platform (such as an ESB or BPEL engine)
– instead it ships complete with the fully configured engine that runs in the
standardized container platform
• All you need to run is:
– Start container. Period.
Linux Host + Docker Engine

13
Ship (Container Images)
• Package, Distribute, Share, Publish and Consume container images
– The frozen state of a container (committed after building and further manipulating)
– With everything needed to run the micro service: application and underlying platform
& OS, ready to run on any Docker Engine anywhere
– With an implicit interface (environment variables, link, volume)

Public Docker
Registry
Docker Hub
14
Docker Image Registry
push
Private
Docker
Registry
Docker Hub
push

15
Docker Registry
• Images can be published to Public and Private Registries
– Docker Hub is the default registry
– Docker Hub contains official repositories from many projects and vendors
– Private Registries can be created in the cloud and on premises
• Containers can be started from such images

16
Implicit Image Interface:
environment variables, link, volume
Docker Hub
link mysql
Parameters:
WORDPRESS_DB_PASSWORD,
WORDPRESS_DB_USER, …
Volume
..:/var/lib
/mysql
Parameters:
MYSQL_DATABASE,
MYSQL_ROOT_PASSWORD

17
Demo Ship
Run MySQL and Wordpress

18
Running Wordpress instance
by pulling two public images
port 8080 port 80
dockerhostvm
IP: 10.10.10.29
Docker Hub

19
Commit container as image
and push to registry
dockerhostvm
Docker Hub
/tmp/mynewfile.txt
Dockersig-trial:1.0

20
Image published on public
Docker Hub registry

21
Run container based on my
published image
dockerhostvm
Docker Hub
/tmp/mynewfile.txt
Dockersig-trial:1.0
Dockersig-
trial:1.0

22
How to Ship a Stand-Alone
product?
• Create Installers + Configuration Instructions?
• Make your product success dependent on platform configuration and OS
settings?
• Ship as a container – everything set up and ready to run!
• For example:
– RubiconRed – Preferred way to deliver their tool MyST: as Docker Container (image)

23
Ship to Cloud
• Ship Image to [Run on] Cloud
– All product installation, configuration, custom software deployment and testing has
been done – all we need is a place for it to land
– Complete environment, ready to run on any Docker enabled platform
• Many public cloud providers support running Docker Containers
Public Docker
Registry
Docker Hub

24
CD = Container Delivery
• Why not make continuous software delivery include the container as well?
– Automated build does not just build the software but the container as well
– The delivered artifact is the container image
– The Test and Acceptance Environment are by definition the same as the
development environment – because they are the container

25
Containers are built on layers
• Containers (and Container Images) are collections of files in a Docker
controlled file system
• Files are copied-on-write in this file system – and shared until then
• (read only) Images are shared across all containers run from them
– And also shared across images built on top of them
• The Docker host running the below 9 containers has
– 5 containers sharing the same Ubuntu 14.04 image (188 MB once, not 5 times!)
– 4 containers sharing the same CentOS 7 image
Ubuntu 14.04
Tomcat
My Simple
Container
CentOS 7
NGINX Node.js MySQL
web app
13rd
party
app
2
IAM
X mydbY Z

26
Running a Container
adds a Writable Layer
• A container is run from a predefined Image
– This image can be local – possibly used by an existing container or image
• Running a Container entails adding a container specific Writable Layer to
the stack of reuable image layers
• Copy on write: edit or create a file and it gets copied to the writable layer
• A container can be stopped – the writable layer is saved and preserved
– When the container is restarted, the writable layer is activated
• A container can be committed as image –
the writable layer becomes part of the new image
– and is what the new image adds
Ubuntu 14.04
TomcatNGINX
3rd
party
My Web App
Container
server.xml
server.xml
My Web App
server.xml
My Web App
Container

27
Building a Docker Container
• Dockerfile specifies all build steps
– With fairly low level commands
• Start from base image - each step in the Docker Script adds a layer
• A layer is a logical ‘savepoint’ in the container history
– That marks an intermediate ‘image’
– A physical directory somewhere on the Docker Host
• The build context contains all files available during the build process
– Note that additional files can be downloaded (e.g. HTTP with wget and Linux
package updates with apt-update)
FROM Ubuntu:14.04
COPY
RUN
WORKDIR
RUN
EXPOSE
CMD
COPY
RUN
RUN
Ubuntu 14.04
Build
context
Final
Intermediate

28
Subsequent Build Actions
• When actions are performed in the container as initially built – more files
are added to the writable layer
• There is no distinction between what was initially done based on the
Dockerfile and what is subsequently done in the running container
• At some point, the container is committed and becomes an image – to be
published, shipped, run and extended even further
Base Image
Ubuntu 14.04
COPY
RUN
RUN
Base Image
Ubuntu 14.04
COPY
RUN
RUN
Writable Layer
run commit
Final

Standard
Image,
locally built
29
Build
• In addition to 10Ks of reusable images to start containers from
• There are a zilion Dockerfiles to leverage for building images
– Download script
– Add software packages and installers (because of license reasons)
– Tweak the script to fit your own needs
OR (preferably)
– Run the script, create a local image and then create your own Docker File that takes
this image as its starting point
Your Own
Dockerfile
Your Tweaked

30
“Docker” Search results on
GitHub

32
Demo run container after build

33
Image and Container Specifics
Container
Base Image
Ubuntu 14.04
COPY
RUN
RUN
Writable Layer
run
Container “state”
tag
remove
inspect
save
tar load …
pullregistry

34
Image and Container Specifics
Container
Base Image
Ubuntu 14.04
COPY
RUN
RUN
Writable Layer
run
start
attach
(un)pause
kill
stop
restart
remove
inspect
logs
Container “state”
export
tar
…
Flattened, no
image details

35
Container Details & Operations
Container
web
Container
db
link
docker run –it
<image-id> /bin/bash
Container
xxx
link
link
808080
/tmp/files
Shared Files
/data
/host_files
Docker
storage
/software
Shared Files
/repos/repos
1
2
3
4
1
2
3
4
2
4
–p 8080:80
-v /data -v /tmp/files:/host_files
-volumes-from xxx
--name web --link db:db1 –link xxx:web_xxx

36
For example: build container
for Oracle WebLogic
• Clone from GitHub to
Docker host
– Dockerfile
– Shell scripts
– Supporting files
• Download RPMs for
– JDK 8
– WebLogic 12.1.3
• Docker Build
• Optionally use second
Docker file on top of
WebLogic image to
create a WLS Domain
Standard
Oracle WebLogic
Image,
locally built

37
Build File for WebLogic
Base Image
Oraclelinux:7
RUN
COPY
RUN
COPY
COPY
COPY

38
Build File for WebLogic (2)
Base Image
Oraclelinux:7
RUN
COPY
RUN
COPY
COPY
COPY
RUN
RUN
RUN
RUN
RUN

Base Image
Oraclelinux:7
RUN
COPY
RUN
COPY
COPY
COPY
RUN
RUN
RUN
RUN
RUN
39
Turn container into image
Base Image
Oraclelinux:7
RUN
COPY
RUN
COPY
COPY
COPY
RUN
RUN
RUN
RUN
RUN
docker commit <container-id> weblogic:12.1.3-dev

40
Automated Configuration
Management
• Use of (hard coded, environment specific) Shell Scripting to create |
compose | configure environments is not exactly the latest fashion
• Declarative, automated configuration management
tools have us specify what we need and then
make that happen
– No scripting
– Cross platform
– Parametrized
– Leveraging public catalogs of
environment definitions

Container Build process
• Regular Docker Build
– From base image
– Add Puppet support
– Add Puppet Manifests &
Modules
• Start Container
– Optional: Map Volume from
host with large files
– Run Puppet to apply Manifests
– Perform additional actions in
container
– Stop Container, Commit as Image
• Push/Ship new image
• Run containers from
final image
dockerhostvm
Dockerfile
my-base-container
/files
/puppet
/files
volume
1
Very big files
Proposed workflow for building
Docker Container Images
2
3
4
5
4
21
3
/puppet Manifests/Modules
5
7
7
Base Image
Oraclelinux:7
RUN
COPY
RUN
COPY
COPY
COPY
RUN
RUN
RUN
RUN
RUN
6
6
88
9
9

42
Notes on
Using Puppet with Docker
• After applying Puppet – the container can be stopped, tagged and used as base
image for next Docker Build
– That could add EXPOSE, ENV, CMD or ENTRYPOINT
• With some workarounds, Puppet apply can be made to run during Docker Build
(with RUN in Dockerfile)
– Less control over build context
– No Volume mapping from host
• There are Puppet Modules to use for automating the build pipeline of Docker
(leveraging the Docker API)
– To install Docker, build container, create and ship an image, run container
• What applies to Puppet by and large applies to similar tools such as Chef, Salt
and Ansible
• Puppet Modules are available for many Oracle Database & Fusion Middleware
configuration management tasks
– Oracle Database (EE, SE, XE)
– WebLogic, SOA Suite, OSB, BPM Suite, WLST
– JDK, Opatch, VirtualBox, GlassFish, Hudson, Maven

44
Run GUI applications
in Docker Container
Container
docker run –d –it
-v /tmp/.X11-unix:/tmp/.X11-unix
-e DISPLAY=$DISPLAY
<image-id> /bin/bash
/tmp/.X11-unix
/tmp/.X11-unix
dockerhost
GUI applications

45
Docker and Windows
• Docker sits on Linux Containers
– Windows Server 2016 will have containers too – and Docker will sit on those as well
– However, today, Docker does not run on Windows (nor on )

46
Docker cannot run on Windows - directly
dockerhost
Container
Container
Container

47
Docker cannot run on Windows
- directly, without Linux VM
dockerhost
Container
Container
Container

48
Vagrant to the rescue
dockerhost
Container
Container
Container

49
Vagrant to the rescue
• Based on simple declarative definitions…
• Vagrant provisions environments through various providers
– VirtualBox, VMware, AWS
• Subsequently, provisioning (‘configuration management’) using shell
scripts, Chef, Ansible, Salt or Puppet
• Vagrant supports Docker
– Create Docker Host VM, Build | Run | Manage Container
• Vagrant makes host-container folder mapping and networking quite easy
dockerhost
Container

dockerhostvm
50
Vagrant Docker Provisioning
• Vagrantfile defines the Container to run – including name and initial
command and also synched folders (i.e. host <=> container mapping)
• Dockerfile contains build recipe for the Container we want to build
• DockerHostVagrantfile describes the VM to be used as Docker Host
Vagrantfile
DockerHostVagrantfile
Dockerfile
my-little-container
other-container
some-container

51
Vagrant Docker Provisioning
dockerhostvm
Vagrantfile
Dockerfile
my-little-container
build process
Docker Hub
ubuntu:14.04
/u01/readme.txt
Vagrant Boxes
ubuntu/trusty64

52
Vagrant with Docker
Folder Mapping
dockerhostvm
Vagrantfile
my-little-container
/vagrant
/vagrant
/host_temp
/host_data
/var/lib
/docker
/docker_
generatedId

53
Demo – Run Docker
Containers with Vagrant
• This entire session was Vagrant based!
• Vagrant:
– Configures Windows Host/Container Folder mapping and Host VM IP Settings
– Can stop and start as well as create and destroy containers
• Note: docker-run and docker-logs are special Vagrant commands
– For one-off command in container and to get insight in what happens in the container

54
Docker on Windows
– other options
• Docker Toolbox (since August 2015) replaces Boot2Docker
– Contains Docker Client for Windows, Kitematic (Docker GUI, alpha release), Docker
Machine, Docker Engine and leverages Oracle VirtualBox
– Still uses Boot2Docker Linux Distribution to run containers
– No support for GUI in containers

55
Docker Containers
Status & Future
• Growing adoption beyond innovators
and [very] early adopters
• Growing number of tools around Docker
– Monitoring, Management, Clustering, …
• Windows
– support for containers in Windows 2016
• Solaris Zones to work
with Docker Client
• Cloud Support
– By a fast evolving number of
IaaS/PaaS cloud providers
– AWS, Azure,
Google Container Engine
• Open Container Initiative
• docker.con (EU)

56
Oracle and Docker
• Oracle Linux 6 and 7 Images
• Oracle MySQL image
• WebLogic certified on Docker
– Official “Docker Build-scripts
in GitHub to create images”
• Solaris Zones leveraged by
Docker Engine
• Participate in OCI
• Docker on Oracle Cloud??

57
Summary
• Docker helps you run isolated environments in a quick, lean way
– Containers are far more light weight, yet almost as stand alone as VMs
– Hundreds of official Docker Container base images are publicly available
• Docker Containers are micro services
– with an exposed interface to inject dependencies (volume, link, environment settings)
• Share | Distribute | Publish your complete, working environments is very
easy using Docker container images
– Either push to registry or save as TAR
• CD could become ‘Container Delivery’ – deliver software + environment
• Many cloud providers can run Docker Containers
• Do not attempt to build containers completely from Dockerfile
– Leverage declarative configuration management tools such as Puppet and Chef
• Tools like Vagrant allow you to easily work with Docker on a non-Linux
host

58
What did you get from this
session?
• What is this Docker thing and why is it a hype?
• How do Containers compare to Virtual Machines?
• How can I build, ship [| share | distribute] and run containers?
– On my local machine and in the cloud?
• A way to more efficiently leverage the physical resources in my computer?
– than through juggling VMs
• A structured and fast way to try out new software
– Without messing up my local environment.
• What tools do I need to get started with Docker
on my non-Linux laptop?
• What is the status of Docker and where is it going?
• How can I get going on my own with Docker?
REPEAT SHORT URL FOR RESOURCES

Blog: http://technology.amis.nl
Twitter: lucasjellema
Mail: lucasjellema@gmail.com

Java developer intro to environment management with vagrant puppet and docker

More Related Content

What's hot

Viewers also liked

Similar to Java developer intro to environment management with vagrant puppet and docker

More from Getting value from IoT, Integration and Data Analytics

Recently uploaded

Java developer intro to environment management with vagrant puppet and docker

Editor's Notes
