From Sensor Data to Triples: Information Flow in Semantic Sensor Networks
- 1. March 28th 2011 FromRaw Sensor Data to Semantic Web Triples Information Flow in Semantic Sensor Networks Nikolaos Konstantinou, Ph.D. Autonomic and Grid Computing group Athens Information Technology
- 2. March 28th 2011 Lecture Outline • Introduction • Sensor data • Semantic web • Context-awareness • The GSN middleware • Exposing sensor data as triples • Semantic Integration using SPARQL
- 3. March 28th 2011 Introduction • The Situation – Decrease in the value of sensors encourage the shift from Desktop to Ubiquitous Computing • The Problem – Extracting meaning from a network of deployed sensors • Why is this a problem? – Raw sensor data is useless unless properly annotated – Limited resources in terms of processing, storage capabilities and bandwidth • What is the suggested solution? – Establish ways to automatically process and manage the data
- 4. March 28th 2011 Concepts involved (1) • Context-awareness – Context-aware systems are able to sense and measure their environment and include these measurements in their behavior • Data fusion – Combine information and data residing at disparate sources, in order to achieve improved accuracies and more specific inferences than could be achieved by the use of a single data source alone – Data fusion spans various levels, from signal and object refinement (low level) to situation and threat assessment (high level)
- 5. March 28th 2011 Concepts involved (2) • Information Integration – Unify information originating from various sources in order to allow its processing as a whole – Obstacles include • Heterogeneity in source schemas and data • Various Technical Spaces • Semantic and syntactic differences • Semantic Information Integration – The resulting integration scheme carries its semantics • Information Merging – Unification of the information at the implementation level
- 6. March 28th 2011 Concepts involved (3) • Information Aggregation – Report the mean value of a set of measurements – E.g. the average temperature of a set of temperature sensors • Information Annotation – Inclusion of metadata next or in the actual data – E.g. ID3 tags in mp3 • Semantic Information Annotation – Unambiguously define information – Third parties can understand the information
- 7. March 28th 2011 Lecture Outline • Introduction • Sensor data • Semantic web • Context-awareness • The GSN middleware • Exposing sensor data as triples • Semantic integration using SPARQL
- 8. March 28th 2011 Sensors and Sensor Data (1) • Sensors are devices that measure physical properties – Temperature, motion, light, humidity sensors – Also cameras, microphones, GPS-enabled smartphones • Sensors provide data that can be – Streamed data • Audio/Video content – Event-based • Temperature measurement • RFID tag read • Light curtain interrupt
- 9. March 28th 2011 Sensors and Sensor Data (2) • Why is sensor data any different than other forms of data, e.g. multimedia? – Synchronization issues • Apply acceptance thresholds – Erroneous measurements • Apply aggregation – Limited resources in the nodes • Caution when designing where the actual processing takes place • Keep a sliding window • Heavy process in the Gateway Nodes – Streaming may lead to packet losses • Reconstruct, or take decisions based on what you have
- 10. March 28th 2011 Sensor Network Topologies (1) • Sink nodes collect information – Higher processing capabilities
- 11. March 28th 2011 SensorNetwork Topologies (2)
- 12. March 28th 2011 Lecture Outline • Introduction • Sensor Data • Semantic Web • Context-Awareness • The GSN Middleware • Exposing Sensor Data as triples • Semantic Integration using SPARQL
- 13. March 28th 2011 Why Semantic Web (1) • Knowledge in the form of a graph – (subject, property, object) • Information is assigned an unambiguously defined meaning, its semantics – Queries can be posed by any third parties – Ontology, a well defined vocabulary • Numerous ontologies already available and interconnected on the Web – Can and should be used when integration is a goal
- 14. March 28th 2011 Why Semantic Web (2) • Enables semantic annotation and integration • Enables reasoning – Extract implicit information from the explicitly asserted – Assure concept consistency and satisfiability • Open source tools available – Protégé, Jena, Virtuoso, … • Allows information to be exposed as Linked Open Data
- 15. March 28th 2011 The Linked Open Data Cloud 2007 2010 Source: linkeddata.org
- 16. March 28th 2011 Lecture Outline • Introduction • Sensor data • Semantic web • Context-awareness • The GSN middleware • Exposing sensor data as triples • Semantic integration using SPARQL
- 17. March 28th 2011 Context-awareness:The big picture (1) • The sensors capture information from the environment • The signal processing components produce structured information – Face detector, Body Tracker, Vehicle tracker, Smoke detection etc.
- 18. March 28th 2011 Context-awareness:The big picture (2) • The middleware – Business logic: Program, configure, monitor and control system behavior – Storage layer • Support database: limited historicity, sliding window • Archive database: enables further processing • Note the Information/Control duality
- 19. March 28th 2011 Signal Processing Components (1) • Much work carried out in the AGC lab – Image Processing • Face Detection/Recognition/Tracking • Body Tracking – Audio Processing • A/V Localization • Voice activity detection
- 20. March 28th 2011 Signal Processing Components (2) • Challenges – Processing is resource-hungry – Heterogeneous technologies must be combined • Production Algorithms in C++, prototypes in Matlab • Multidisciplinary skills required • Well-defined Interfaces need to be developed using RMI/Sockets/Web services/JNA – Video processing differs from streaming processing • Processing an avi file differs (greatly!) from processing an rtp stream
- 21. March 28th 2011 Lecture Outline • Introduction • Sensor data • Semantic web • Context-awareness • The GSN middleware • Exposing sensor data as triples • Semantic integration using SPARQL
- 22. March 28th 2011 Global Sensor Networks (1) • Open-source, java-based middleware solution • Available online at sf.net/projects/gsn/ • Adaptability – Everything is a virtual sensor – Virtual sensors rely on wrappers – Every data producer can be integrated into the GSN with a virtual sensor and wrapper
- 23. March 28th 2011 Global Sensor Networks (2) • Simplicity – Configurable without compiling source code – Web application for sensor management • Scalability – Allows communication between nodes – Allows data aggregation and fusion using an SQL-like declarative language
- 24. March 28th 2011 Global Sensor Networks (3) • Example – Integrating a Signal Processing component (e.g. a Smoke detector) into GSN
- 25. March 28th 2011 Example of data aggregation using GSN <output-structure> … <field name="TEMPERATURE" type="int" /> measured … properties </output-structure> … <storage history-size=“24h" /> sliding … window <streams> size <stream name="input1"> <source alias="source1" sampling-rate="1" storage-size="1"> <address wrapper="temperature"> <predicate key="sampling-rate">10000</predicate> data source </address> <query>select TEMPERATURE from wrapper</query> </source> <query>select avg(TEMPERATURE) from source1</query> aggregated </stream> output </streams>
- 26. March 28th 2011 Example of data fusion using GSN <storage history-size="1h" /> <streams> <stream name="teststream" rate="1000"> <source name="source1" alias="source1" storage-size="100" slide="0" sampling-rate="1"> <address wrapper="remote-rest"> <predicate key="HOST">localhost</predicate><predicate key="PORT">22001</predicate> <predicate key="QUERY">select FACE_COUNT from doorwatcher</predicate> source 1 </address> <query>select FACE_COUNT AS S1 from wrapper</query> </source> <source name="source2" alias="source2" storage-size="100" slide="0" sampling-rate="1"> <address wrapper="remote-rest"> <predicate key="HOST">localhost</predicate><predicate key="PORT">22002</predicate> source 2 <predicate key="QUERY">select TAG from touchatag</predicate> </address> <query>select TAG AS S2 from wrapper</query> </source> <query> select source1.S1 as S1OUT, source2.S2 as S2OUT fused from source1, source2 output where source1.S1 > 0 AND source2.S2="04dddcb9232580" </query> </stream> </streams>
- 27. March 28th 2011 The Storage Layer (1) • Schema according to the Virtual Sensors – Virtual Sensor definition example: <virtual-sensor name="temperature" priority="10"> … <output-structure> <field name="ID" type="int" /> <field name="SENSORTIME" type="time" /> <field name="TEMPERATURE" type="double" /> <field name="UNIT" type="varchar(255)" /> </output-structure>
- 28. March 28th 2011 The Storage Layer (2) • Schema according to the Virtual Sensors – Schema auto-generated SQL create statement: CREATE TABLE `gsn1`.`temperature` ( `PK` bigint(20) NOT NULL AUTO_INCREMENT, added by GSN `timed` bigint(20) NOT NULL, `ID` int(11) DEFAULT NULL, `SENSORTIME` time DEFAULT NULL, depending on the virtual `TEMPERATURE` double DEFAULT NULL, sensor description `UNIT` varchar(255) DEFAULT NULL, PRIMARY KEY (`PK`), UNIQUE KEY `temperature_INDEX` (`timed`) ) ENGINE=MyISAM AUTO_INCREMENT=122 DEFAULT CHARSET=latin1
- 29. March 28th 2011 The Storage Layer (3) • Historical data – According to the Virtual Sensor definition • Tuple-based: <storage history-size="1" /> • Time-based: <storage history-size="1m" /> • Out-of-the-box support for – Mysql – SQL Server – Oracle – H2 – Can be extended to support other RDBMS’s
- 30. March 28th 2011 The Storage Layer (4) • Storage Layer can be – Centralized (in the Central Control node) • Data is pushed to the Central Control node – Distributed (in the Gateway nodes) • Interfaces – Legacy (ODBC/JDBC) – Web Services (SOAP or RESTful) – SPARQL Endpoints • Allow Semantic Information Integration
- 31. March 28th 2011 Lecture Outline • Introduction • Sensor data • Semantic web • Context-awareness • The GSN middleware • Exposing sensor data as triples • Semantic integration using SPARQL
- 32. March 28th 2011 Exposing sensor data as triples (1) • OpenLink Virtuoso universal server can be used as – A web application server – A relational database repository – A triplestore – A web service server • Open-source version available at http://virtuoso.openlinksw.com/ • Cluster Configuration – Parallel and Horizontal scaling
- 33. March 28th 2011 Exposing sensor data as triples (2) • Virtuoso RDF Views – Export relational data as triples • SPARQL 1.1 support, plus – Full Text Queries – Geo Spatial Queries – Business Analytics and Intelligence – SQL Stored Procedure and Built-In Function exploitation from SPARQL – Create, Update, and Delete (SPARUL) • Backward-chaining OWL reasoner
- 34. March 28th 2011 Exposing sensor data as triples (3) • Using Virtuoso, RDF Data can also be accessible via – ODBC/JDBC – ADO.NET (Entity Frameworks compatible) – OLE DB – XMLA (XML for Analysis) data providers / drivers • Using the “Sponger” RDF-izer, RDF data can be extracted from non-RDF sources (e.g. with XSLT)
- 35. March 28th 2011 Publishing RDF using Virtuoso (1) • Conductor: a GUI for server administration • Virtuoso can be used as a DBMS
- 36. March 28th 2011 Publishing RDF using Virtuoso (2) • Can be combined with GSN to process sensor data streams and export them as RDF • Create RDF Views over the relational data
- 37. March 28th 2011 Publishing RDF using Virtuoso (3) • Browseable repository • A URI for every resource • Example: Measurement URI
- 38. March 28th 2011 Semantic Sensor Network Example (1) System monitoring and control node Mesh topology 3 node types Gateway nodes Sink nodes
- 39. March 28th 2011 SemanticSensor Network Example (2) • Sink node – Operation relies on a relational database – Limited historical data – Keep a “sliding window” • Based on time or tuples – Do not have semantic capabilities – One Database per Sink node
- 40. March 28th 2011 SemanticSensor Network Example (3) • Gateway Node – Operation relies on a semantically-enabled knowledge base – Supported by inference procedures – Maintains historical/archived information – One Knowledge Base per Gateway node – Appropriate for Higher Level Fusion (e.g. threats, events)
- 41. March 28th 2011 SemanticSensor Network Example (4) • Central Control node – Monitors and controls the network – Provides system-wide services • E.g. directory services, secure authentication – Can store its view over the network for intelligence extraction
- 42. March 28th 2011 Information Flow • An Information flow example in a decentralized Semantic Sensor Network
- 43. March 28th 2011 Lecture Outline • Introduction • Sensor data • Semantic web • Context-awareness • The GSN middleware • Exposing sensor data as triples • Semantic Integration using SPARQL
- 44. March 28th 2011 Semanticintegration using SPARQL (1) • SPARQL: An SQL-like language for querying RDF graphs • SELECT-FROM-WHERE syntax • WHERE conditions are triple patterns • SELECT ?x ?y ?z WHERE { ?x ?y ?z } returns all the triples in the graph
- 45. March 28th 2011 Semanticintegration using SPARQL (2) • XML over HTTP (RESTful approach) – http://demo.openlinksw.com/sparql?default-graph- uri=urn:lsid:ubio.org:namebank:11815&should- sponge=soft&query=SELECT+*+WHERE+{?s+?p+?o}&form at=text/html • No create/update/delete capabilities
- 46. March 28th 2011 Semanticintegration using SPARQL (3) • SPARQL queries can be named and stored – A query named sparql-demo listens to: http://localhost:8890/DAV/sparql-demo • Can return results over HTTP (XML by default) • MIME type of the RDF data – 'rdf+xml' (default) | 'n3' | 'turtle' | 'ttl‘
- 47. March 28th 2011 Semantic integration using SPARQL (4) • SPARQL results example in RDF/XML <ROOT> <rdf:RDF xmlns:rdf="http://www.w3.org/1999/02/22-rdf-syntax-ns#” xmlns:rs="http://www.w3.org/2005/sparql-results#" xmlns:xsd="http://www.w3.org/2001/XMLSchema#"> <rs:results rdf:nodeID="rset"> <rs:result rdf:nodeID="sol193"> <rs:binding rdf:nodeID="sol193-0" rs:name="x“><rs:value rdf:resource="http://localhost:8890/Demo/temperature/PK/4#this"/></rs:binding> <rs:binding rdf:nodeID="sol193-1" rs:name="y“><rs:value rdf:resource="http://www.w3.org/1999/02/22-rdf-syntax-ns#type"/></rs:binding> <rs:binding rdf:nodeID="sol193-2" rs:name="z“><rs:value rdf:resource="http://localhost:8890/schemas/Demo/temperature"/></rs:binding> </rs:result> … </rs:results> </rdf:RDF> </ROOT>
- 48. March 28th 2011 Thankyou! Questions?
