Data Structure and Algorithm Introduction

Data Structure and Algorithm Introduction

• 1.
  Code: BCECCE3102 Data Structure& Algorithm Dr. Bharti Salunke
• 2.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 2
• 3.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 3 Data Structure • Data is a collection of information. • The data is a programming word, it is values or set of values. • Data Structure is a way to store and organize data so that it can be used efficiently. • Data structure is not any programming language like C, C++, java etc. • It is a set of algorithms that we can use in any programming language to structure the data in the memory.
• 4.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 4 Cont… Where data structures are used? Compiler Design Operating System DBMS Artificial Intelligence Simulation Numerical Analysis etc…
• 5.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 5 Types of Data Structure
• 6.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 6 Primitive Data Structure Primitive data structures are the basic building blocks of data manipulation. These include: • Int: Represents integer values. • Char: Used to store single characters. • Bool: Holds Boolean values, true or false. • Float: Used for floating-point numbers, which are numbers with a decimal point.
• 7.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 7 Non-Primitive Data Structure • Moving beyond the basics, non-primitive data structures offer more sophisticated ways to organize and store data. • These are generally divided into two categories: Linear and Non- linear. • The arrangement of data in a sequential manner is known as a linear data structure. • Array, Stack, Queue, Linked-List are the example of linear data structure. • Non-linear structures allow data to be stored in a non-sequential manner, facilitating quick retrieval and linkage based on relationships; like Tree and Graph.
• 8.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 8 Array • An array is a collection of items of the same variable type that are stored at contiguous memory locations. • Each element in an array is accessed through its index.
• 9.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 9 Stack • Stack is a linear data structure in which elements can be inserted as well as deleted from one end. • LIFO policy is used in Stack data structure.
• 10.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 10 Queue • Queue is linear data structure in which elements can be inserted from one end as well deleted from another end • FIFO policy is used in queue data structure.
• 11.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 11 Linked List • Linked List is a linear data structure in which each elements contains two nodes: data, link
• 12.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 12 Tree • A hierarchical structure consisting of nodes, with each node containing data and references to child nodes. • The tree is a non-linear data structure that is comprised of various nodes.
• 13.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 13 Graph • A graph is a non-linear data structure with a finite number of vertices and edges, and these edges are used to connect the vertices. • It’s used to represent relationships between different entities.
• 14.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 14 Memory Allocation
• 15.
  Department of ComputerScience And Engineering, Poornima University, Jaipur, India 15 #include <stdio.h> int main() { // Static memory allocation of an array int arr[5] = {1, 2, 3, 4, 5}; // Printing the array elements for (int i = 0; i < 5; i++) { printf("arr[%d] = %dn", i, arr[i]); } return 0; } Static Memory Allocation
