Logic Design 10CS33
Dept. Of CSE, SJBIT Page 1
LOGIC DESIGN
(Common to CSE & ISE)
Subject Code: 10CS33 I.A. Marks : 25
Hours/Week : 04 Exam Hours: 03
Total Hours : 52 Exam Marks:
100
PART-A
UNIT – 1 7 Hours
Digital Principles, Digital Logic: Definitions for Digital Signals, Digital Waveforms,
Digital Logic, 7400 TTL Series, TTL Parameters The Basic Gates: NOT, OR, AND,
Universal Logic Gates: NOR, NAND, Positive and Negative Logic, Introduction to HDL.
UNIT – 2 6 Hours
Combinational Logic Circuits
Sum-of-Products Method, Truth Table to Karnaugh Map, Pairs Quads, and Octets, Karnaugh
Simplifications, Don’t-care Conditions, Product-of-sums Method, Product-of-sums
implifications, Simplification by Quine-McClusky Method, Hazards and Hazard Covers,
HDL Implementation Models.
UNIT – 3 6 Hours
Data-Processing Circuits: Multiplexers, Demultiplexers, 1-of-16 Decoder, Encoders,
Exclusive-or Gates, Parity Generators and Checkers, MagnitudeComparator, Programmable
Array Logic, Programmable Logic Arrays, HDL
Implementation of Data Processing Circuits
UNIT – 4 7 Hours
Clocks, Flip-Flops: Clock Waveforms, TTL Clock, Schmitt Trigger, Clocked D FLIP-
FLOP, Edge-triggered D FLIP-FLOP, Edge-triggered JK FLIP-FLOP, FLIP-FLOP Timing,
JK Master-slave FLIP-FLOP, Switch Contact Bounce Circuits, Various Representation of
FLIP-FLOPs, Analysis of Sequential Circuits, HDL Implementation of FLIP-FLOP
PART-B
UNIT – 5 6 Hours
Registers: Types of Registers, Serial In - Serial Out, Serial In - Parallel out, Parallel In -
Serial Out, Parallel In - Parallel Out, Universal Shift Register, Applications of Shift
Registers, Register Implementation in HDL
UNIT – 6 7 Hours
Counters: Asynchronous Counters, Decoding Gates, Synchronous Counters, Changing the
Counter Modulus, decade Counters, Presettable Counters, Counter Design as a Synthesis
problem, A Digital Clock, Counter Design using HDL

Logic Design 10CS33
UNIT – 7 7 Hours
Design of Synchronous and Asynchronous Sequential Circuits: Design of Synchronous
Sequential Circuit: Model Selection, State Transition Diagram, State Synthesis Table, Design
Equations and Circuit Diagram, Implementation using Read Only Memory, Algorithmic State
Machine, State Reduction Technique. Asynchronous Sequential Circuit: Analysis of
Asynchronous Sequential Circuit, Problems with Asynchronous Sequential Circuits, Design
of Asynchronous Sequential Circuit, FSM Implementation in HDL
UNIT – 8 6 Hours
D/A Conversion and A/D Conversion: Variable, Resistor Networks, Binary Ladders, D/A
Converters, D/A Accuracy and Resolution, A/D Converter- Simultaneous Conversion, A/D
Converter-Counter Method, Continuous A/D Conversion, A/D Techniques, Dual-slope A/D
Conversion, A/D Accuracy and Resolution
Text Books:
1. Donald P Leach, Albert Paul Malvino & Goutam Saha: Digital Principles and
Applications, 7th Edition, Tata McGraw Hill, 2010.
Reference Books:
1. Stephen Brown, Zvonko Vranesic: Fundamentals of Digital Logic Design with VHDL, 2nd
Edition, Tata McGraw Hill, 2005.
2. R D Sudhaker Samuel: Illustrative Approach to Logic Design, Sanguine-Pearson, 2010.
3. Charles H. Roth: Fundamentals of Logic Design, Jr., 5th Edition, Cengage Learning, 2004.
4. Ronald J. Tocci, Neal S. Widmer, Gregory L. Moss: Digital Systems Principles and
Applications, 10th Edition, Pearson Education, 2007.

Logic Design 10CS33
INDEX SHEET
Unit No. Unit Name Page No.
I Digital Principles, Digital Logic 4-15
II Combinational Logic Circuits 16-29
III Data-Processing Circuits 30-42
IV Clocks, Flip-Flops 43-50
V Registers 51-54
VI Counters 55-60
VII Design of Synchronous and
Asynchronous Sequential Circuits
61-76
VIII D/A Conversion and A/D
Conversion
77-84

Logic Design 10CS33
Unit-1 : Digital Principles, Digital Logic
Contents :
Definitions for Digital Signals
Digital Waveforms
Digital Logic 7400 TTL Series, TTL Parameters The Basic
Gates: NOT, OR, AND,
Universal Logic Gates: NOR, NAND
Positive and Negative Logic
Introduction to HDL.

Logic Design 10CS33
Definitions of Analog vs Digital signals
An Analog signal is any continuous signal for which the time varying feature (variable) of
the signal is a representation of some other time varying quantity, i.e., analogous to another
time varying signal. It differs from a digital signal in terms of small fluctuations in the signal
which are meaningful.
A digital signal uses discrete (discontinuous) values. By contrast, non-digital (or analog)
systems use a continuous range of values to represent information. Although digital
representations are discrete, the information represented can be either discrete, such as
numbers or letters, or continuous, such as sounds, images, and other measurements of
continuous systems.
Comparison chart
Analog Digital
Technology:
Analog technology records waveforms
as they are.
Converts analog waveforms into set
of numbers and records them. The
numbers are converted into voltage
stream for representation.
Representation:
Uses continuous range of values to
represent information.
Uses discrete or discontinuous values
to represent information.
Uses:
Can be used in various computing
platforms and under operating systems
like Linux, Unix, Mac OS and
Windows.
Computing and electronics
Signal:
Analog signal is a continuous signal
which transmits information as a
response to changes in physical
phenomenon.
Digital signals are discrete time
signals generated by digital
modulation.
Clocks:
Analog clocks indicate time using
angles.
Digital clocks use numeric
representation to indicate time.
Computer: Analog computer uses changeable
continuous physical phenomena such
Digital computers represent changing
quantities incrementally as and when

Logic Design 10CS33
Analog Digital
as electrical, mechanical, hydraulic
quantities so as to solve a problem.
their values change.
Waveforms in digital systems
In computer architecture and other digital systems, a waveform that switches between two
voltage levels representing the two states of a Boolean value (0 and 1) is referred to as a
digital signal, even though it is an analog voltage waveform, since it is interpreted in terms of
only two levels.
The clock signal is a special digital signal that is used to synchronize digital circuits. The
image shown can be considered the waveform of a clock signal. Logic changes are triggered
either by the rising edge or the falling edge.
The given diagram is an example of the practical pulse and therefore we have introduced two
new terms that are:
 Rising edge: the transition from a low voltage (level 1 in the diagram) to a high
voltage (level 2).
 Falling edge: the transition from a high voltage to a low one.

TTL Series
Normally Binary Logic Values are are defined as either Logic ‘1’or Logic ‘0’ depending on
the level of the output voltage. Another additional (intermediate value ) is the ‘Undefined
value’. Logic levels can either be Positive logic or Negative Logic. For eg:
In TTL Logic Levels (positive logic) logic high or Logic 1 is between 2.4V VH  5V.
Logic ‘0’ or low logic is between 0V VL  0.4 V and the Undefined value is between 0.4
V <undefined< 2.4 V
Logic families are classified based on either the devices used ,example: diodes ,transistors
etc. or the structure of Digital Circuits , example: ECL ,Wired logic etc.
The following are the examples of logic families based on the devices used and their
structure,
• DTL :Diode Transistor Logic
• RTL :Resistor Transistor Logic
• TTL :Transistor Transistor Logic

Logic Design 10CS33
• ECL :Emitter Coupled Logic
• CMOS :Complementary MOSFET Logic
The various logic families differ in the current driving capabilities,Logic Levels, propagation
delays and a few other other parameters. The Comparison of TTL and CMOS is clearly
illustrated in the following table as an example of differences in the logic families:
TTL CMOS
• Faster
• Stronger drive
capability
• Low power consumption
• Simpler to make
• Greater packing density
• Better noise immunity
Integration Levels:
The devices greatly differ in the density of fabrication ie the levels of integration
used.Depending on the number of transistors/diodes/gates used in the chip they are broadly
classified as :
• SSI -small scale integration
• MSI -medium scale integration
• LSI -large scale integration
• VLSI -very large scale integration
• ULSI -ultra large scale integration
• GSI -giant scale integration
Levels of integration Transistors/package Gates/chip Applications
SSI 1-100 <12 Logic gates Op-amps
MSI 100-1000 12-99 Registers Filters
LSI 1000-10000 1000 8 bit processor, A/D converter
VLSI 10k gates/chip 16,32 bit processor
256KB memory

Logic Design 10CS33
Speed of Operation:
As signals propagate through the various gates there is a finite time required for the signal
change to occur, eg the time required for the input high of a n inverter to change to logic
low at the output. This implies that there is a limitation on the no of times the output can
change or the speed of operation of the gate. The parameters of importance for the speed
of operation are :
• tLH- low to high rise time (tr) : it is defined as the time interval for the signal to rise
between 10% to 90% of Vdd
• tHL- high to low time or fall time (tf): it is defined as the time for signal to fall from
90%Vdd to 10%Vdd
•
The switching is fast with
tmin=thl+tlh
Therefore maximum switching freq is achieved when fmax=1/tmin
The switching speed is limited due to the effect of capacitance at the base emmiter
/collector and ground etc.
For eg: if thl =0.5 nsec, tlh=1.0 nsec
Then tmin =1.5 nsec And fmax=1/ tmin=666.67Mhz
Propagation delay:
It is the physical delay as the logical signal propagates through the gates. It differs depending
on whether the output transition goes from cutoff to saturation or from saturation to cut-off.
DS processor
ULSI 100k gates/chip 64 bit processor
8 MB memory
Image processor
GSI 1M gates/chip 64 MB memory
multiprocessor

Logic Design 10CS33
As the loads are connected to gates to realize the necessary logic operations the output signal
levels are affected. This is because there is a current flow between the gates due to which
there is power consumption. Thus the number of circuits(similar gates) that can be connected
to the gates gets limited.
• Fan-out of a gate is the number of gates driven by that gate i.e the maximum number
of gates (load ) that can exist without impairing the normal operation of the gate.
• Fan-in of a gate is the number of inputs that can be connected to it without impairing
the normal operation of the gate.
Overview of Basic Gates and Universal Logic Gates
A logic gate is an electronic circuit/device which makes the logical decisions. To arrive at
this decisions, the most common logic gates used are OR, AND, NOT, NAND, and NOR
gates. The NAND and NOR gates are called universal gates. The exclusive-OR gate is
another logic gate which can be constructed using AND, OR and NOT gate.
Logic gates have one or more inputs and only one output. The output is active only for certain
input combinations. Logic gates are the building blocks of any digital circuit. Logic gates are
also called switches. With the advent of integrated circuits, switches have been replaced by
TTL (Transistor Transistor Logic) circuits and CMOS circuits. Here I give example circuits
on how to construct simples gates.
AND Gate
The AND gate performs logical multiplication, commonly known as AND function. The
AND gate has two or more inputs and single output. The output of AND gate is HIGH only
when all its inputs are HIGH (i.e. even if one input is LOW, Output will be LOW).
If X and Y are two inputs, then output F can be represented mathematically as F = X.Y, Here
dot (.) denotes the AND operation. Truth table and symbol of the AND gate is shown in the
figure below.

Logic Design 10CS33
X Y F=(X.Y)
0 0 0
0 1 0
1 0 0
1 1 1
OR Gate
The OR gate performs logical addition, commonly known as OR function. The OR gate has
two or more inputs and single output. The output of OR gate is HIGH only when any one of
its inputs are HIGH (i.e. even if one input is HIGH, Output will be HIGH).
If X and Y are two inputs, then output F can be represented mathematically as F = X+Y. Here
plus sign (+) denotes the OR operation. Truth table and symbol of the OR gate is shown in
the figure below.
YF=(X+Y)
0 0 0
0 1 1
1 0 1
1 1 1
NOT Gate
The NOT gate performs the basic logical function called inversion or complementation. NOT
gate is also called inverter. The purpose of this gate is to convert one logic level into the
opposite logic level. It has one input and one output. When a HIGH level is applied to an
inverter, a LOW level appears on its output and vice versa.

Logic Design 10CS33
If X is the input, then output F can be represented mathematically as F = X', Here apostrophe
(') denotes the NOT (inversion) operation. There are a couple of other ways to represent
inversion, F= !X, here ! represents inversion. Truth table and NOT gate symbol is shown in
the figure below.
X Y=X'
0 1
1 0
NAND Gate
NAND gate is a cascade of AND gate and NOT gate, as shown in the figure below. It has two
or more inputs and only one output. The output of NAND gate is HIGH when any one of its
input is LOW (i.e. even if one input is LOW, Output will be HIGH).
X Y F=(X.Y)'
0 0 1
0 1 1
1 0 1
1 1 0
NOR Gate
NOR gate is a cascade of OR gate and NOT gate, as shown in the figure below. It has two or
more inputs and only one output. The output of NOR gate is HIGH when any all its inputs are
LOW (i.e. even if one input is HIGH, output will be LOW).

Logic Design 10CS33
X Y F=(X+Y)'
0 0 1
0 1 0
1 0 0
1 1 0
XOR Gate
An Exclusive-OR (XOR) gate is gate with two or three or more inputs and one output. The
output of a two-input XOR gate assumes a HIGH state if one and only one input assumes a
HIGH state. This is equivalent to saying that the output is HIGH if either input X or input Y
is HIGH exclusively, and LOW when both are 1 or 0 simultaneously.
If X and Y are two inputs, then output F can be represented mathematically as F = X Y,
Here denotes the XOR operation. X Y and is equivalent to X.Y' + X'.Y. Truth table and
symbol of the XOR gate is shown in the figure below.
X Y F=(X Y)
0 0 0
0 1 1
1 0 1
1 1 0
XNOR Gate
An Exclusive-NOR (XNOR) gate is gate with two or three or more inputs and one
output. The output of a two-input XNOR gate assumes a HIGH state if all the inputs
assumes same state. This is equivalent to saying that the output is HIGH if both input X and
input Y is HIGH exclusively or same as input X and input Y is LOW exclusively, and LOW
when both are not same.

Logic Design 10CS33
If X and Y are two inputs, then output F can be represented mathematically as F = X Y,
Here denotes the XNOR operation. X Y and is equivalent to X.Y + X'.Y'. Truth table and
symbol of the XNOR gate is shown in the figure below.
X Y F=(X Y)'
0 0 1
0 1 0
1 0 0
1 1 1
Boolean Laws and Theorems
A. Axioms
Consider a set S = { 0. 1} Consider two binary operations, + and . , and one unary operation, -- ,
that act on these elements. [S, ., +, --, 0, 1] is called a switching algebra that satisfies the
following axioms S.
B. Closure
If X S and Y S then X.Y S
If X S and Y S then X+Y S
C. Identity
an identity 0 for + such that X + 0 = X
an identity 1 for . such that X . 1 = X
D. Commutative Laws
X + Y = Y + X
X Y = Y X
E. Distributive Laws
X.(Y + Z ) = X.Y + X.Z
X + Y.Z = (X + Y) . (X + Z)

Logic Design 10CS33
Idempotent Law
X + X = X
X X = X
DeMorgan's Law
(X + Y)' = X' . Y', These can be proved by the use of truth tables.
Proof of (X + Y)' = X' . Y'
Y X+Y (X+Y)'
0 0 0 1
0 1 1 0
1 0 1 0
1 1 1 0
X Y X' Y' X'.Y'
0 0 1 1 1
0 1 1 0 0
1 0 0 1 0
1 1 0 0 0
The two truth tables are identical, and so the two expressions are identical.
(X.Y) = X' + Y', These can be proved by the use of truth tables.
Proof of (X.Y) = X' + Y'
X Y X.Y (X.Y)'
0 0 0 1
0 1 0 1
1 0 0 1
1 1 1 0
X Y X' Y' X'+Y'
0 0 1 1 1
0 1 1 0 1
1 0 0 1 1
1 1 0 0 0
Introduction to HDL: Hardware Description Language
HDL is a language that describes the hardware of digital systems in a textual form. It
resembles a programming language, but is specifically oriented to describing hardware
structures and behaviors.

Logic Design 10CS33
The main difference with the traditional programming languages is HDL’s representation of
extensive parallel operations whereas traditional ones represents mostly serial operations.
HDL can be used to represent logic diagrams, Boolean expressions, and other more complex
digital circuits
There are two standard HDL’s that are supported by IEEE.
 VHDL (Very-High-Speed Integrated Circuits Hardware Description
Language) - Sometimes referred to as VHSIC HDL, this was developed from
an initiative by US. Dept. of Defense.
 Verilog HDL – developed by Cadence Data systems and later transferred to a
consortium called Open Verilog International (OVI).
Verilog: Verilog HDL has a syntax that describes precisely the legal constructs that can be
used in the language.
 It uses about 100 keywords pre-defined, lowercase, identifiers that define the
language constructs.
 Example of keywords: module, endmodule, input, output wire, and, or, not , etc.,
 Any text between two slashes (//) and the end of line is interpreted as a comment.
 Blank spaces are ignored and names are case sensitive.
A module is the building block in Verilog. It is declared by the keyword module and is
always terminated by the keyword endmodule.Each statement is terminated with a
semicolon, but there is no semi-colon after endmodule.
HDL Example
module smpl_circuit(A,B,C,x,y);
input A,B,C;
output x,y;
wire e;
and g1(e,A,B);
not g2(y,C);
or g3(x,e,y);
endmodule

Logic Design 10CS33
Unit-2 : Combinational Logic Circuits
Contents:
Sum-of-Products Method
Truth Table to Karnaugh Map
Pairs Quads, and Octets
Karnaugh Simplifications, Don’t-care Conditions
Product-of-sums
Method, Product-of-sums simplifications
Simplification by Quine-McClusky
Method, Hazards and Hazard Covers
HDL Implementation Models.

Logic Design 10CS33
DeMorgans Laws are applicable for any number of variables.
Boundedness Law
X + 1 = 1
X . 0 = 0
Absorption Law
X + (X . Y) = X
X . (X + Y ) = X
Elimination Law
X + (X' . Y) = X + Y
X.(X' + Y) = X.Y
Unique Complement theorem
If X + Y = 1 and X.Y = 0 then X = Y'
Involution theorem
X'' = X
0' = 1
Associative Properties
X + (Y + Z) = (X + Y) + Z
X . ( Y . Z ) = ( X . Y ) . Z
PRINCIPLE OF DUALITY
One can transform the given expression by interchanging the operation (+) and (•) as
well as the identity elements 0 and 1 . Then the expression will be referred as dual
of each other. This is known as the principle of duality.
Example x + x = 1 then the dual expression is
x • x = 0
A procedure which will be used to write Boolean expressions form truth table is
known as canonical formula. The canonical formulas are of two types

Logic Design 10CS33
1. Minterm canonical formulas
2. Maxterm canonical formulas
MINTERM CANONICAL FORMULAS
Minterms are product of terms which represents the functional values of the variables
appear either in complemented or un complemented form.
Ex: f(x,y,z) = x y z + x y z + x y z
The Boolean expression whichis represented above is also known as SOP or
disjunctive formula. The truth table is
x y z f
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
0
1
0
1
1
0
0
0
m- NOTATION
To simplify the writing of a minterm in canonical formula for a function is
performed using the symbol mi. Where i stands for the row number for which the
function evaluates to 1.
The m-notation for 3- variable an function Boolean function
f(x,y,z) = x y z + x y z + x y z is written as
f(x,y,z) = m1+ m3 + m4 or
f(x,y,z) = m(1,3,4)

Logic Design 10CS33
A three variable m- notation truth variable
x y z Decimal
designator of row
Minterm m-notation
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
0
1
2
3
4
5
6
7
x y z
x y z
x y z
x y z
x y z
x y z
x y z
x y z
m0
m1
m2
m3
m4
m5
m6
m7
MAXTERM CANONICAL FORM
Maxterm are sum terms where the variable appear once either in complement or un-
complement forms and these terms corresponds to a functional value representing 0.
Ex. f(x,y,z) = ( x+ y+ z ) ( x+ y+z ) ( x + y + z )
= M( 0, 2, 5)
= M0, M2, M5
KARNAUGH MAPS ( K- MAP)
A method for graphically determining implicants and implicates of a
Boolean function was developed by Veitch and modified by Karnaugh . The
method involves a diagrammatic representation of a Boolean algebra. This graphic
representation is called map.
It is seen that the truth table can be used to represent complete function of n-
variables. Since each variable can have value of 0 or 1. The truth table has 2n
rows. Each rows of the truth table consist of two parts (1) an n-tuple which
corresponds to an assignment to the n-variables and (2) a functional value.
A Karnaugh map (K-map) is a geometrical configuration of 2n cells
such that each of the n-tuples corresponds to a row of a truth table
uniquely locates a cell on the map. The functional values assigned to the n-
tuples are placed as entries in the cells, i.e. 0 or 1 are placed in the
associated cell.
An significant about the construction of K-map is the arrangement of the
cells. Two cells are physically adjacent within the configuration if and only if
their respective n-tuples differ in exactly by one element. So that the Boolean

Logic Design 10CS33
law x+x=1 cab be applied to adjacent cells. Ex. Two 3- tuples (0,1,1) and
(0,1,0) are physically a djacent since these tuples vary by one element.
One variable : One variable needs a map of 21
= 2 cells map as shown below
x f(x)
0 f(0)
1 f(1)
TWO VARIABLE : Two variable needs a map of 22
= 4 cells
x y f(x,y)
0 0 f(0,0)
0 1 f(0,1)
1 0 f(1,0)
1 1 f(1,1)
THREE VARIABLE : Three variable needs a map of 23
= 8 cells. The arrangement of cells
are as follows
x y z f(x,y,z)
0 0 0 f(0,0,0)
0 0 1 f(0,0,1)
0 1 0 f(0,1,0)
0 1 1 f(0,1,1)
1 0 0 f(1,0,0)
1 0 1 f(1,0,1)
1 1 0 f(1,1,0)
1 1 1 f(1,1,1)
FOUR VARIABLE : Four variable needs a map of 24
= 16 cells. The arrangement of cells are
as follows
w x y z f(w,x,y,z) w x y z f(w,x,y,z)
0 0 0 0 f(0,0,0,0) 1 0 1 0 f(1,0,1,0)
0 0 0 1 f(0,0,0,1) 1 0 1 1 f(1,0,1,1)
0 0 1 0 f(0,0,1,0) 1 1 0 0 f(1,1,0,0)
0 0 1 1 f(0,0,1,1) 1 1 0 1 f(1,1,0,1)
0 1 0 0 f(0,1,0,0) 1 1 1 0 f(1,1,10)

Logic Design 10CS33
0 1 0 1 f(0,1,0,1) 1 1 1 1 f(1,1,1,1)
0 1 1 0 f(0,1,1,0)
0 1 1 1 f(0,1,1,1)
1 0 0 0 f(1,0,0,0)
1 0 0 1 f(1,0,0,1)
Four variable K-map.
0000 0001 0011 0010
0100 0101 0111 1010
1100 1101 1111 1110
1000 1001 1011 1010
Ex. Obtain the minterm canonical formula of the three variable problem given below
f(x, y,z) = x y z+ x y z + x y z + x y z
f(x,y,z) = m(0,2,4,5)
00 01 11 11
1 0 0 1
1 1 0 0

Logic Design 10CS33
Ex. Express the minterm canonical formula of the four variable K-map given below
yz
00 01 11 10
1 1 0 1
1 1 0 0
0 0 0 0
1 0 0 1
f(w,x,y,z) = w x y z + w x y z + w x y z + w x y z + w x y z + w x y z
f(w,x,y,z) =  m(0, 1, 2, 4, 5,
Ex. Obtain the max term canonical formula
(POS) of the three variable problem stated above
f(x,y,z) = ( x + y +z)( x + y +z)(x + y +z)
(x + y +z)
f(x,y,z) = M(1,3,6,7)
Ex Obtain the max term canonical formula
(POS) of the four variable problem stated above
f(w,x,y,z) = (w + x + y + z) (w + x + y + z) (w + x + y + z)
(w + x + y + z) (w + x + y + z) (w + x + y + z)
(w + x + y + z) (w + x + y + z) (w + x + y + z)
f(w,x,y,z) = M(3,6,7,9,11,12,13,14,15)
PRODUCT AND SUM TERM REPRESENTATION OF K –MAP
1.The importance of K-map lies in the fact that it is possible to determine the implicants
and implicates of a function from the pattern of 0’s and 1’s appearing in the map. The cell
of a K-map has entry of 1’s is refereed as 1-cell and that of 0,s is referred as 0-cell.
2. The construction of an n-variable map is such that any set of 1-cells or 0-cells which
form a 2a
x2b
rectangular grouping describing a product or sum term with n-a-b variables , where a
and b are non-negative no.s
3. The rectangular grouping of these dimensions referred as Subcubes. The subcubes must
be the power of 2 i.e. 2 a+b
equals to 1,2,4,8 etc.
wx

Logic Design 10CS33
4. For three variable and four variable K-map it must be remembered that the edges are also
adjacent cells or subcubes hence they will be grouped together.
5. Given an n-variable map with a pair of adjacent 1-cells or 0-cellscan result n-1
variable.Where as if a group of four adjacent subcubes are formed than it can result n-2
variables. Finally if we have eight adjacent cells are grouped may result n-3 variable
product or sum term.
Typical pair of subcubes
Typical group of four adjacent subcube
1 1
1 1
Typical group of four adjacent subcubes.
1 1
1 1
1
1 1
1 1 1
1
1 1 1 1
1 1
1 1

Logic Design 10CS33
Typical group of eight adjacent subcubes.
1 1 1 1
1 1 1 1
Typical map subcubes desc
USING K-MAP TO OBTAIN MINIMAL EXPRESSION FOR COMPLETE
BOOLEAN FUNCTIONS :
How to obtain a minimal expression of SOP or POS of given function is discussed.
PRIME IMPLICANTS and K-MAPS :
CONCEPT OF ESSENTIAL PRIME IMPLICANT
00 01 11 10
0 0 0 1
0 0 1 1
f(x,y,z)= xy+ yz
1 1 1 1
1 1 1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1

Logic Design 10CS33
ALGORITHM TO FIND ALL PRIME IMPLICANTS
A General procedure is listed below
1. For an n-variable map make 2n entries of 1’s. or 0’s.
2. Assign I = n , so that find out biggest rectangular group with dimension 2ax2b = 2 n-1.
3. If bigger rectangular group is not possible I = I-1 form the subcubes which
consist of all the previously obtained subcube repeat the step till all 1-cell or 0’s are
covered.
4. Remaining is essential prime implicants
1. Essential prime implicants
2. Minimal sums
3. Minimal products
MINIMAL EXPRESSIONS OF INCOMPLETE BOOLEAN FUNCTIONS
1. Minimal sums
2. Minimal products.
EXAMPLE TO ILLUSTRATE HOW TO OBTAIN ESSENTIAL PRIMES
1. f(x,y,z) = m(0,1,5,7)
Ans f(x,y,z) = xz + x y
2. f(w,x,y,z) = m(1,2,3,5,6,7,8,13)
Ans. f(w,x,y,z) = w z +w y+xyz+w x y z
MINIMAL SUMS
f(w,x,y,z)=m(0,1,2,3,5,7,11,15)
MINIMAL PRODUCTS
F(w,x,y,z)=m(1,3,4,5,6,7,11,14,15)
MINIMAL EXPRESSIONS OF INCOMPLETE BOOLEAN FUNCTIONS
f(W,X,Y,Z)=m(0,1,3,7,8,12) +dc(5,10,13,14)
QUINE – McCLUSKEY METHOD
Using K-maps for simplification of Boolean expressions with more than six variables becomes
a tedious and difficult task. Therefore a tabular method illustrate below can be used for the
purpose.
ALGORITHM FOR GENERATING PRIME IMPLICANTS
The algorithm procedure is listed below
1.Express each minterm of the function in its binary representation.

Logic Design 10CS33
2. List the minterms by increasing index.
3. Separate the sets of minterms of equal index with lines.
4. Let i = 0.
5. Compare each term of index I with each term of index I+1. For each pair of terms that can
combine which has only one bit position difference.
6. Increase I by 1 and repeat step 5 . The increase of I continued until all terms are compared.
The new list containing all implicants of the function that have one less variable than those
implicants in the generating list.
7. Each section of the new list formed has terms of equal index. Steps 4,5, and 6 are repeated on
this list to form another list. Recall that two terms combine only if they have their dashes in
the same relative positions and if they differ in exactly one bit position.
8. The process terminates when no new list is formed .
9. All terms without check marks are prime implicants.
Example: Find all the prime implicants of the function
f(w,x,y,z) = m(0,2,3,4,8,10,12,13,14)
Step 1: Represent each minter in its 1-0 notation
no. minterm 1-0 notation index
0
2
3
4
8
10
12
13
14
w x y z
w x y z
w x y z
w x y z
w x y z
w x y z
w x y z
w x y z
w x y z
0 0 0 0
0 0 1 0
0 0 1 1
0 1 0 0
1 0 0 0
1 0 1 0
1 1 0 0
1 1 0 1
1 1 1 0
0
1
2
1
1
2
2
3
3

Logic Design 10CS33
Step 2: List the minterm in increasing order of their index.
No. w x y z index
0
2
4
8
3
10
12
13
14
0 0 0 0
0 0 1 0
0 1 0 0
1 0 0 0
0 0 1 1
1 0 1 0
1 1 0 0
1 1 0 1
1 1 1 0
Index 0
Index 1
Index 2
Index 3
W x y z index
0.2
0,4
0,8
2,3
2,10
4,12
8,10
8,12
10,14
12,13
12,14
0 0 – 0
0 – 0 0
- 0 0 0
0 0 1 –
- 0 1 0
- 1 0 0
1 0 – 0
1 – 0 0
1 – 1 0
1 1 0 –
1 1 - 0

Logic Design 10CS33
w x y z
(0, 2, 8, 10)
(0, 4, 8,12 )
__ 0 __ 0
__ __ 0 0(index 0)
(8,10,12,14) 1__ __ 0 (index 1)
F(w,x,y,z)=x z + y z +w z+w x y +w x z
PETRICK’S METHOD OF DETERMINING IRREDUNDANT EXPRESSIONS
FIND THE PRIME IMPLICANTS AND IRREDUNDANT EXPRESSION
F(W,X,Y,Z)= M(0,1,2,5,7,8,9,10,13,15)
A=X Y , B= X Z C= Y Z D= X Z
P = (A+B)(A+C) (B)(C+D)(D)(A+B)(A+C)(B)(C+D)(D)
P = (A +C)(BD) = ABD +BCD
F1(W,X,Y,Z)= ABD =X Y +X Z +X Z
F2(W,X,Y,Z) = BCD = X Z + Y Z +X Z
DECIMAL METHOD FOR OBTAINING PRIME IMPLICANTS
The prime implicants can be obtained for decimal number represented minterms.In this procedure
binary number are not used to find out prime implicants
f(w, x,y,z) =m(0,5,6,7,9,10,13,14,15)
fsop= xy +xz+xyz+wyz+w x y z
MAP ENTERED VARIABLE(MEV)
It is graphical approach using k-map to have a variable of order n. Where in we are using a K-map
of n-1 variable while map is entered with ouput function and variable.
f(w,x,y.z) = m(2,3,4,5,13,15) +dc(8,9,10,11)
Ans. fsop= w z +x y + w x y
HDL IMPLEMENTATION METHODS
A module can be described in any one (or a combination) of the following modeling techniques.
 Gate-level modeling using instantiation of primitive gates and user defined modules.
 This describes the circuit by specifying the gates and how they are connected
with each other.
 Dataflow modeling using continuous assignment statements with the keyword
assign.
 This is mostly used for describing combinational circuits.
 Behavioral modeling using procedural assignment statements with keyword always.

Logic Design 10CS33
 This is used to describe digital systems at a higher level of abstraction.
Gate-level modeling: Here a circuit is specified by its logic gates and their interconnections.
 It provides a textual description of a schematic diagram.
 Verilog recognizes 12 basic gates as predefined primitives.
 4 primitive gates of 3-state type.
 Other 8 are: and, nand, or, nor, xor, xnor, not, buf
//Gate-level hierarchical description of 4-bit adder
module halfadder (S,C,x,y);
input x,y;
output S,C;
//Instantiate primitive gates
xor (S,x,y);
and (C,x,y);
endmodule
Dataflow Modeling: Dataflow modeling uses continuous assignments and the keyword assign.A
continuous assignment is a statement that assigns a value to a net. The value assigned to the net is
specified by an expression that uses operands and operators.
//Dataflow description of a 2-to-4-line decoder
module decoder_df (A,B,E,D);
input A,B,E;
output [0:3] D;
assign D[0] = ~(~A & ~B & ~E),
D[1] = ~(~A & B & ~E),
D[2] = ~(A & ~B & ~E),
D[3] = ~(A & B & ~E);
endmodule
Behavioral Modeling : Behavioral modeling represents digital circuits at a functional and algorithmic
level.
 It is used mostly to describe sequential circuits, but can also be used to describe
combinational circuits.
 Behavioral descriptions use the keyword always followed by a list of procedural assignment
statements.
 The target output of procedural assignment statements must be of the reg data type.
 A reg data type retains its value until a new value is assigned.
//Behavioral description of 2-to-1-line multiplexer
module mux2x1_bh(A,B,select,OUT);
input A,B,select;
output OUT;
reg OUT;
always @(select or A or B)
if (select == 1) OUT = A;
else OUT = B;
endmodule

Logic Design 10CS33
Unit-3 :Data-Processing Circuits
Multiplexers
Demultiplexers
1-of-16 Decoder
Encoders
Exclusive-or Gates
Parity Generators and Checkers
Magnitude Comparator
Programmable Array Logic
Programmable Logic Arrays, HDL
Implementation of Data Processing Circuits

Logic Design 10CS33
Decoder
A Decoder is a multiple input ,multiple output logic circuit.The block diagram of a decoder is as
shown below.
The most commonly used decoder is a n –to 2n
decoder which ha n inputs and 2n
Output lines .
3-to-8 decoder logic diagram
In this realization shown above the three inputs are assigned x0,x1,and x2, and the eight outputs are Z0
to Z7.

Logic Design 10CS33
Function specifc decoders also exist which have less than 2n
outputs . examples are 8421 code
decoder also called BCD to decimal decoder. Decoders that drive seven segment displays also exist.
Realization of boolean expression using Decoder and OR gate
We see from the above truth table that the output expressions corrwespond to a single minterm. Hence
a n –to 2n
decoder is a minterm generator. Thus by using OR gates in conjunction with a a n –to 2n
decoder boolean function realization is possible.
Ex: to realize the Boolean functions given below using decoders…
•F1=Σm(1,2,4,5)
•F2=Σm(1,5,7)
Priority encoder
8-3 line priority encoder
In priority encoder a priority scheme is assigned to the input lines so that whenever more than one
input line is asserted at any time, the output is determined by the input line having the highest priority.
The Valid bit is used to indicate that atleast one inut line is asserted. This is done to distinguish the
situation that no input line is asserted from when the X0 input line is asserted , since in both cases
Z1Z2Z3 =000.
4-1 line Multiplexer

Logic Design 10CS33
Multiplexers also called data selectors are another MSI devices with a wide range of applications in
microprocessor and their peripherals design. The followind diagrams show the symbol and truth table
for the 4-to –1 mux.
Programmable Logic Devices
Most of the circuits presented so far are available on a TTL IC chip. Circuits can be constructed using
these chips and wiring them together.An alternative to this method would be to program all the
components into a single chip, saving wiring, space and power.One type of such device is PLA
(Programmable Logic Array) that contains one or more and/or arrays.
Programmable Logic Devices (PLDs)
PLD’s are Standard logic devices that can be programmed to implement any combinational logic
circuit. Programmable refers to a hardware process used to specify the logic that a PLD implements.
There are various types of PLD devices based on which array is programmable.The Device names and
the type of array are listed in the table below.
Types of PLDs
As an example we will first consider
Programming the ROM
The realization of Boolean expressions using a decoder and or gates was discussed in the earlier
chapter on decoders. A similar approach is used in a PROM since a PROM is a device that includes
FixedProgrammable
ee
PAL
Programmable
e
ProgrammablePLA
Programmable
e
FixedPROM
OR arrayAND arrayDEVICE

Logic Design 10CS33
both the decoder and the OR gates within the same network.The programming of the PROM is
carried out by blowing the appropriate fuses. Proms are used for Code conversions, generating bit
patterns for characters, and as lookup tables for arithmetic functions.
Example: Let I0I1I3I4 = 00010 (address 2). Then, output 2 of the decoder will be 1, the remaining
outputs will be 0, and ROM output becomes A7A6A5A4A3A2A1A0 = 11000101.
Programmable Logic Arrays (PLAs)
Similar concept as in PROM, except that a PLA does not necessarily generate all possible minterms
(ie. the decoder is not used).More precisely, in PLAs both the AND and OR arrays can be
programmed (in PROM, the AND array is fixed – the decoder – and only the OR array can be
programmed).
PLA Example
f(a,b,c) = a’b’ + abc
g(a,b,c) = a’b’c’ + ab + bc
h(a,b,c) = c
PLAs can be more compact implementations than ROMs, since they can benefit from minimizing the
number of products required to implement a function.

Logic Design 10CS33
Programmable Array Logic (PAL)
OR plane (array) is fixed, AND plane can be programmed. A PAL is less Less flexible than PLA
Number of product terms available per function (OR outputs) is limited
PAL-based circuit implementation
W = AB’C’ + CD
X = A’BC’ + A’CD + ACD’ + BCD
Y = A’C’D’ + ACD + A’BD
HDL Implementation of Data Processing Circuits
//Gate-level hierarchical description of 4-bit adder
module halfadder (S,C,x,y);
input x,y;
output S,C;

Logic Design 10CS33
//Instantiate primitive gates
xor (S,x,y);
and (C,x,y);
endmodule
module fulladder (S,C,x,y,z);
input x,y,z;
output S,C;
wire S1,D1,D2; //Outputs of first XOR and two AND gates
//Instantiate the half adders
halfadder HA1(S1,D1,x,y), HA2(S,D2,S1,z);
or g1(C,D2,D1);
endmodule
module decoder_gl (A,B,E,D);
input A,B,E;
output[0:3]D;
wire Anot,Bnot,Enot;
not
n1 (Anot,A),
n2 (Bnot,B),
n3 (Enot,E);
nand
n4 (D[0],Anot,Bnot,Enot),
n5 (D[1],Anot,B,Enot),
n6 (D[2],A,Bnot,Enot),
n7 (D[3],A,B,Enot);
endmodule
//Dataflow description of 2-to-1-line mux
module mux2x1_df (A,B,select,OUT);
input A,B,select;

Logic Design 10CS33
output OUT;
assign OUT = select ? A : B;
endmodule
//Behavioral description of 2-to-1-line multiplexer
module mux2x1_bh(A,B,select,OUT);
input A,B,select;
output OUT;
reg OUT;
always @(select or A or B)
if (select == 1) OUT = A;
else OUT = B;
endmodule
//Behavioral description of 4-to-1 line mux
module mux4x1_bh (i0,i1,i2,i3,select,y);
input i0,i1,i2,i3;
input [1:0] select;
output y;
reg y;
always @(i0 or i1 or i2 or i3 or select)
case (select)
2'b00: y = i0;
2'b01: y = i1;
2'b10: y = i2;
2'b11: y = i3;
endcase
endmodule

Logic Design 10CS33
Adders
Adders are the basic building blocks of all arithmetic circuits; adders add two binary numbers and
give out sum and carry as output. Basically we have two types of adders.
Half Adder.
Full Adder
Half Adder
Adding two single-bit binary values X, Y produces a sum S bit and a carry out C-out bit. This
operation is called half addition and the circuit to realize it is called a half adder.
X Y SUM CARRY
0 0 0 0
0 1 1 0
1 0 1 0
1 1 0 1
S (X,Y) = (1,2)
S = X'Y + XY'
S = X Y
CARRY(X,Y) = (3)
CARRY = XY

Logic Design 10CS33
Full Adder
Full adder takes a three-bits input. Adding two single-bit binary values X, Y with a carry input bit C-
in produces a sum bit S and a carry out C-out bit.
X Y Z SUM CARRY
0 0 0 0 0
0 0 1 1 0
0 1 0 1 0
0 1 1 0 1
1 0 0 1 0
1 0 1 0 1
1 1 0 0 1
1 1 1 1 1
SUM (X,Y,Z) = (1,2,4,7)
CARRY (X,Y,Z) = (3,5,6,7)
Kmap-SUM
SUM = X'Y'Z + XY'Z' + X'YZ'
SUM = X Y Z

Logic Design 10CS33
Kmap-CARRY
CARRY = XY + XZ + YZ
Circuit-SUM
Circuit-CARRY
Multipliers
Multiplication is achieved by adding a list of shifted multiplicands according to the digits of the
multiplier. An n-bit X n-bit multiplier can be realized in combinational circuitry by using an array of
n-1 n-bit adders where each adder is shifted by one position. For each adder one input is the shifted
multiplicand multiplied by 0 or 1 (using AND gates) depending on the multiplier bit, the other input is
n partial product bits.

Logic Design 10CS33
Dividers
The binary divisions are performed in a very similar manner to the decimal divisions, as shown in the
below figure examples. Thus, the second number is repeatedly subtracted from the figures of the first
number after being multiplied either with '1' or with '0'. The multiplication bit ('1' or '0') is selected for
each subtraction step in such a manner that the subtraction result is not negative. The division result is
composed from all the successive multiplication bits while the remainder is the result of the last
subtraction step.
This algorithm can be implemented by a series of subtracters composed of modified elementary cells.
Each subtracter calculates the difference between two input numbers, but if the result is negative the
operation is canceled and replaced with a subtraction by zero. Thus, each divider cell has the normal
inputs of a subtracter unit as in the figure below but a supplementary input ('div_bit') is also present.
This input is connected to the b_req_out signal generated by the most significant cell of the subtracter.
If this signal is '1', the initial subtraction result is negative and it has to be replaced with a subtraction
by zero. Inside each divider cell the div_bit signal controls an equivalent 2:1 multiplexer that selects

Logic Design 10CS33
between bit 'x' and the bit included in the subtraction result X-Y. The complete division can therefore
by implemented by a matrix of divider cells connected on rows and columns as shown in figure
below. Each row performs one multiplication-and-subtraction cycle where the multiplication bit is
supplied by the NOT logic gate at the end of each row. Therefor the NOT logic gates generate the bits
of the division result.
Carry Lookahead Adder (CLA)
Since each carry generate function Gi and carry propogate function Pi is itself only a function of the
operand variables, the output carry and the input carry at each stage can be expressed as a function of
the operand variablesand the initial carry Co. parallel adders whose realizations are based on the
above equations are called carry look ahead adders.

Logic Design 10CS33
Unit-4 : Clocks , Flip Flops
Contents:
Clock Waveforms
TTL Clock
Schmitt Trigger
Clocked D FLIP-FLOP
Edge-triggered D FLIP-FLOP
Edge-triggered JK FLIP-FLOP
FLIP-FLOP Timing
JK Master-slave FLIP-FLOP
Switch Contact Bounce Circuits
Various Representation of FLIP-FLOPs
Analysis of Sequential Circuits
HDL Implementation of FLIP-FLOP

Logic Design 10CS33
Introduction :
Logic circuit is divided into two types.
1. Combinational Logic Circuit
2. Sequential Logic Circuit
Definition :
1. Combinational Logic Circuit :
The circuit in which outputs depends on only present value of inputs. So it is possible to
describe each output as function of inputs by using Boolean expression. No memory element
involved. No clock input. Circuit is implemented by using logic gates. The propagation delay
depends on, delay of logic gates. Examples of combinational logic circuits are : full adder,
subtractor, decoder, codeconverter, multiplexers etc.
2. Sequential Circuits :
Sequential Circuit is the logic circuit in which output depends on present value of inputs at
that instant and past history of circuit i.e. previous output. The past output is stored by using
memory device. The internal data stored in circuit is called as state. The clock is required for
synchronization. The delay depends on propagation delay of circuit and clock frequency. The
examples are flip-flops, registers, counters etc.
 Basic Bistable element.
o Flip-Flop is Bistable element.
o It consist of two cross coupled NOT Gates.
o It has two stable states.
Combinational
Logic Circuit
inputs outputs
Combinational
Logic Circuit
inputs outputs
Memory Device

Logic Design 10CS33
o Q and Q are two outputs complement of each other.
o The data stored 1 or 0 in basic bistable element is state of flip-flop.
o 1 – State is set condition for flip-flop.
o 0 – State is reset / clear for flip-flop.
o It stores 1 or 0 state as long power is ON.
Latches :
S-R Latch : Set-reset Flip-Flop
 Latch is a storage device by using Flip-Flop.
 Latch can be controlled by direct inputs.
 Latch outputs can be controlled by clock or enable input.
 Q and Q are present state for output.
 Q+
and Q+
are next states for output.
 The function table / Truth table gives relation between inputs and outputs.
 The S=R=1 condition is not allowed in SR FF as output is unpredictable.
Application of SR Latch :
 A switch debouncer

Logic Design 10CS33
 Bouncing problem with Push button switch.
 Debouncing action.
 SR Flip-Flop as switch debouncer.
Gated SR Latch :
 Enable input C is clock input.
 C=1, Output changes as per input condition.
 C=0, No change of state.
 S=1, R=0 is set condition for Flip-flop.
 S=0, R=1 is reset condition for Flip-flop.
 S=R=1 is ambiguous state, not allowed.
JK Flip-Flop by using SR Flip-Flop

Logic Design 10CS33
In SR FF, S=R=1 condition is not allowed.
 JK FF is modified version of SR FF.
 Due to feedback from output to input AND Gate J=K=1 is toggle condition for JK FF.
 The output is complement of the previous output.
 This condition is used in counters.
 T-FF is modified version of JK FF in which T=J=K=1.
Gated D Latch :
 D Flip-Flop is Data Flip-Flop.
 D Flip-Flop stores 1 or 0.
 R input is complement of S.
 Only one D input is present.
 D Flip-Flop is a storage device used in register.

Logic Design 10CS33
Master slave SR Flip-Flop
 Two SR Flip-Flop, 1st
is Master and 2nd
is slave.
 Master Flip-Flop is positive edge triggered.
 Slave Flip-Flop is negative edge triggered.
 Slave follows master output.
 The output is delayed.

Logic Design 10CS33
Master slave JK Flip-Flop
 In SR Flip-Flop the input combination S=R=1 is not allowed.
 JK FF is modified version of SR FF.
 Due to feedback from slave FF output to master, J=K=1 is allowed.
 J=K=1, toggle, action in FF.
 This finds application in counter.
Positive Edge Triggered D Flip-Flop
 When C=0, the output of AND Gate 2 & 3 is equal to 1.
 If C=1, D=1, the output of AND Gate 2 is 0 and 3 is 1.
S R 1, No Change of State  S R 1, Q =1 and Q  0 0,

Logic Design 10CS33
HDL implementation of Flip-flops
module D_latch(Q,D,control);
output Q;
input D,control;
reg Q;
always @(control or D)
if(control) Q = D; //Same as: if(control=1)
endmodule
//D flip-flop
module D_FF (Q,D,CLK);
output Q;
input D,CLK;
reg Q;
always @(posedge CLK)
Q = D;
endmodule
//JK flip-flop from D flip-flop and gates
module JKFF (Q,J,K,CLK,RST);
output Q;
input J,K,CLK,RST;
wire JK;
assign JK = (J & ~Q) | (~K & Q);
//Instantiate D flipflop
DFF JK1 (Q,JK,CLK,RST);
endmodule
// Functional description of JK // flip-flop
module JK_FF (J,K,CLK,Q,Qnot);
output Q,Qnot;
input J,K,CLK;
reg Q;
assign Qnot = ~ Q ;
always @(posedge CLK)
case({J,K})
2'b00: Q = Q;
2'b01: Q = 1'b0;
2'b10: Q = 1'b1;
2'b11: Q = ~ Q;
endcase
endmodule

Logic Design 10CS33
Unit-5 : Registers
Contents:
Types of Registers
Serial In - Serial Out
Serial In - Parallel out
Parallel In - Serial Out
Parallel In - Parallel Out
Universal Shift Register
Applications of Shift Registers
Register Implementation in HDL

Logic Design 10CS33
An n-bit register is a collection of n D flip-flops with a common clock used to store n related
bits.
Types of Register:
 Register is a group of Flip-Flops.
 It stores binary information 0 or 1.
 It is capable of moving data left or right with clock pulse.
 Registers are classified as
 Serial-in Serial-Out
 Serial-in parallel Out
 Parallel-in Serial-Out
 Parallel-in parallel Out
Parallel-in Unidirectional Shift Register

Logic Design 10CS33
 Parallel input data is applied at IAIBICID.
 Parallel output QAQBQCQD.
 Serial input data is applied to A FF.
 Serial output data is at output of D FF.
 L/Shift is common control input.
 L/S = 0, Loads parallel data into register.
 L/S = 1, shifts the data in one direction.
Universal Shift Register
 Bidirectional Shifting.
 Parallel Input Loading.
 Serial-Input and Serial-Output.

Logic Design 10CS33
 Parallel-Input and Serial-Output.
 Common Reset Input.4:1 Multiplexer is used to select register operation.
Shift Register Applications
• State Registers
– Shift registers are often used as the state register in a sequential device. Usually, the next state is
determined by shifting right and inserting a primary input or output into the next position (i.e. a finite
memory machine)
– Very effective for sequence detectors
• Serial Interconnection of Systems
– keep interconnection cost low with serial interconnect
• Bit Serial Operations
– Bit serial operations can be performed quickly through device iteration
– Iteration (a purely combinational approach) is expensive (in terms of # of transistors, chip area,
power, etc).
– A sequential approach allows the reuse of combinational functional units throughout the multi-cycle
operation
Register Implementation in HDL
//Behavioral description of Universal shift register
module shftreg (s1,s0,Pin,lfin,rtin,A,CLK,Clr);
input s1,s0; //Select inputs
input lfin, rtin; //Serial inputs
input CLK,Clr; //Clock and Clear
input [3:0] Pin; //Parallel input
output [3:0] A; //Register output
reg [3:0] A;
always @ (posedge CLK or negedge Clr)
if (~Clr) A = 4'b0000;
else
case ({s1,s0})
2'b00: A = A; //No change
2'b01: A = {rtin,A[3:1]}; //Shift right
2'b10: A = {A[2:0],lfin}; //Shift left
//Parallel load input
2'b11: A = Pin;
endcase
endmodule

Logic Design 10CS33
Unit-6 : Counters
Contents:
Asynchronous Counters
Decoding Gates
Synchronous Counters
Changing the Counter Modulus
Decade Counters, Presettable Counters
Counter Design as a Synthesis problem,
A Digital Clock
Counter Design using HDL

Logic Design 10CS33
COUNTERS
 Counter is a register which counts the sequence in binary form.
 The state of counter changes with application of clock pulse.
 The counter is binary or non-binary.
 The total no. of states in counter is called as modulus.
 If counter is modulus-n, then it has n different states.
 State diagram of counter is a pictorial representation of counter states directed by arrows in
graph.
4-bit Binary Ripple Counter :
000
100
111
110
101
001
010
011
Fig. State diagram of mod-8 counter

Logic Design 10CS33
 All Flip-Flops are in toggle mode.
 The clock input is applied.
 Count enable = 1.
 Counter counts from 0000 to 1111.
Synchronous Binary Counter :
 The clock input is common to all Flip-Flops.
 The T input is function of the output of previous flip-flop.
 Extra combination circuit is required for flip-flop input.
Counters Based on Shift Register

Logic Design 10CS33
 The output of LSB FF is connected as D input to MSB FF.
 This is commonly called as Ring Counter or Circular Counter.
 The data is shifted to right with each clock pulse.
 This counter has four different states.
 This can be extended to any no. of bits.
Twisted Ring Counter or Johnson Counter
 The complement output of LSB FF is connected as D input to MSB FF.
 This is commonly called as Johnson Counter.
 The data is shifted to right with each clock pulse.
 This counter has eight different states.
 This can be extended to any no. of bits.
Mod-7 Twisted Ring Counter
 The D input to MSB FF is Q .QD C

Logic Design 10CS33
 The counter follows seven different states with application of clock input.
 By changing feedback different counters can be obtained.
Design Procedure for Synchronous Counter
 The clock input is common to all Flip-Flops.
 Any Flip-Flop can be used.
 For mod-n counter 0 to n-1 are counter states.
 The excitation table is written considering the present state and next state of counter.
 The flip-flop inputs are obtained from characteristic equation.
 By using flip-flops and logic gate the implementation of synchronous counter is obtained.
Difference between Asynchronous and Synchronous Counter :
Asynchronous Counter Synchronous Counter
1. Clock input is applied to LSB FF. The output of
first FF is connected as clock to next FF.
1. Clock input is common to all FF.
2. All Flip-Flops are toggle FF. 2. Any FF can be used.
3. Speed depends on no. of FF used for n bit . 3. Speed is independent of no. of FF used.
4. No extra Logic Gates are required. 4. Logic Gates are required based on design.
5. Cost is less. 5. Cost is more.
Counter Design using HDL
//Binary counter with parallel load
module counter (Count,Load,IN,CLK,Clr,A,CO);
input Count,Load,CLK,Clr;
input [3:0] IN; //Data input
output CO; //Output carry
output [3:0] A; //Data output
reg [3:0] A;
assign CO = Count & ~Load & (A == 4'b1111);
always @(posedge CLK or negedge Clr)
if (~Clr) A = 4'b0000;
else if (Load) A = IN;

Logic Design 10CS33
else if (Count) A = A + 1'b1;
else A = A; // no change, default condition
endmodule

Logic Design 10CS33
Unit-7: Design of Synchronous and Asynchronous Sequential Circuits
Contents:
Model Selection
State Transition Diagram,
State Synthesis Table
Design Equations and Circuit Diagram,
Implementation using Read Only Memory
Algorithmic State Machine, State
Reduction Technique.
Asynchronous Sequential Circuit: Analysis of Asynchronous Sequential Circuit
Problems with Asynchronous Sequential Circuits
Design of Asynchronous Sequential Circuit
FSM Implementation in HDL

Logic Design 10CS33
SYNCHRONOUS SEQUENTIAL NETWORKS
Definition :
In sequential networks, the outputs are function of present state and present external inputs. Present
state simply called as states or past history of circuit. The existing inputs and present state for
sequential circuit determines next state of networks.
Model of Sequential Network
Types of Sequential Network :
1. Asynchronous Sequential Network : The changes in circuit depends on changes in inputs
depending on present state. But the change in memory state is not at given instant of time but
depending on input.
2. Synchronous Sequential Network : Output depends on present state and present inputs at a
given instant of time. So timing sequence is required. So memory is allowed to store the
changes at given instant of time.
Structure and Operation of Clocked Synchronous Sequential Circuit :
In synchronous sequential circuit, the network behavior is defined at specific instant of time
associated with special timing. There is master clock which is common to all FFs that is used in
memory element. Such circuits are called as clocked synchronous sequential circuit.
Clock : Clock is periodic waveform with one positive edge and one negative edge during each period.
This clock is used for network synchronization
1
0
t
+ ve edge - ve edge
Combinational
Logic Circuit
Memory
Outputsinputs
PS
NS

Logic Design 10CS33
Basic Operation of Clocked Synchronous Sequential Circuit
Q indicates all present state of FF.
Q+ indicates next state of FF in network.
X indicates all external inputs.
Q+ = f(x,Q) This is next state of network.
Z indicates output signal of sequential networks.
Z = g(X,Q)
The structure shown in given figure is called as Mealy Model or Mealy Machine.

Logic Design 10CS33
Difference between Mealy Model and Moore Model of Synchronous Sequential Circuit
Mealy Model : In Mealy Model the next state is function of external inputs and present state. The
output is also function of external inputs and present state. The memory state changes with master
clock.
Q+ = f(X,Q) Z = g(X,Q)
Moore Model : In Moore Model the next state is function of external inputs and present state. But the
output is function of present state. It is not dependent on external inputs. The no. of FFs required to
implement circuit is more compared with Mealy Model,
Q+ = f(X,Q) Z = g(Q)
Logic Diagram for Mealy Network
xQQQxZ
QQQxD
QQQxD
211
2112
2121




Logic Design 10CS33
Logic Diagram for Moore Network
Transition Equations :
To convert excitation expression into next state expression, it is necessary to use the characteristic
equations of flip-flops.
The characteristic equations of FF depends on types of FF used.
Ex : For D FF Q+ = D
For JK FF
For T FF Q+ = T  Q
By substituting the excitation expressions for a FF into characteristic equation, an algebraic
description of next state of FF is obtained.
The expression for next state in terms of FF inputs are referred as transition equations.
Q1+ = D1 and Q2+ = D2
12112
211
212121
andyxx
and
and
QyyxKQQJ
yxQKyJ
QQZQQZ



QKQJQ 
2112
2121
QQQxQ
QQQxQ





Logic Design 10CS33
For Moore network
By substituting the values of J & K inputs we get next state in terms of FF present state and external
input.
Transition Tables :
Instead of using algebraic equations for next state and outputs of sequential network, it is
more convenient and useful to express the information in tabular form.
The Transition Table or State Transition Table or State Table is the tabular representation of the
transition and output equations. This table consist of Present State, Next State, external inputs and
output variables. If there are n state variables then 2n rows are present in state table.
State machine notations :
• Input Variables : External input variables to sequential machine as inputs.
• Output Variables : All variables that exit from the sequential machine are output variables.
• State : State of sequential machine is defined by the content of memory, when memory is
realized by using FFs.
• Present State : The status of all state variable i.e. content of FF for given instant of time t is
called as present state.
• Next State : The state of memory at t+1 is called as Next state.
• State Diagram : State diagram is graphical representation of state variables represented by
circle. The connection between two states represented by lives with arrows and also indicates
the excitation input and related outputs.
• Output Variables : All variables that exit from the sequential machine are output variables.
12222
11111
QKQJQ
QKQJQ





Logic Design 10CS33
PS NS FF input
Q Q+ J K
0 0 0 X
0 1 1 X
1 0 X 1
1 1 X 0
PS NS FF i/p
Q Q+ S R
0 0 0 X
0 1 1 0
1 0 0 1
1 1 X 0
PS NS FF i/p
Q Q+ D i/p
0 0 0
0 1 1
1 0 0
1 1 1
State diagram of SR FF
0 1
01
00
10
01
00
10
B
1
A
0
Q0
11/10
Q1
x0
11/01
State diagram of J-K FF
State diagram of D FF
0 1
0
1
0
1
Application Table of JK FF
Application Table of D FF

Logic Design 10CS33
Transition table for Mealy Network
Transition table for Moore Network
PS (Q1Q2) Next State (Q1+Q2+)
Inputs (xy)
Output
(Z1Z2)
00 01 10 11
00 00 10 01 11 01
01 01 11 00 11 00
PS NS FF i/p
Q Q+ T i/p
0 0 0
0 1 1
1 0 1
1 1 0
State diagram of T FF
0 1
0
1
1
0
xQQQxZ
QQQQxQ
QQQQxQ
211
222112
112121
D,
D,





Application Table of FF

Logic Design 10CS33
10 10 01 00 00 11
11 11 00 10 00 01
Synchronous Sequential Circuit
State Tables :
State table consist of PS, NS and output section. The PS and NS of state tables are obtained by
replacing the binary code for each in the transition table by newly defined symbol. The output section
is identical to output section of transition table.
Symbols for state can be S1, S2, S3,……Sn or A, B, C, D, E….
State table for Mealy Machine
PS NS
x = 0 x = 1
O/p Z
x = 0 x = 1
00 – A C B 0 1
,,yxx,
,,
1211221
1212121
QyyxKQQJyxQK
yJQQZQQZ


2211
222212
1112121
x,
Q,
Q,
QZQxZ
TQQQxT
TQQQxQT






Logic Design 10CS33
01 – B D D 0 0
10 – C C A 1 0
11 – D A A 1 0
State Diagram :
It is graphical representation of state tables. Each state of network is represented by labeled node.
Directed branches connect the nodes to indicate transition between states. The directed branches are
labeled according to the values of external input variable that permit transition. The output of
sequential network is also entered in state diagram. In case of Moore Network state diagram, the
values of input for output is not written.
State diagram for Mealy Network
State diagram for Moore Network

Logic Design 10CS33
Network Terminal Behavior
This is the time response of a network to a sequence of inputs. This can be done from the Logic
diagram by tracing signals.
For given example of Mealy Network,
Assume FFs are in 0 state initially, So Q1Q2 = 00.
Input Sequence x is 0011011101
Now based on input x, the state of FF output changes and also corresponding network output changes.
Input sequence x = 0011011101
State sequence = ACCABDABDAB
Output Sequence Z = 0101001011
Timing diagram for Moore Network
A – 00
B – 01
C – 10
D - 11

Logic Design 10CS33
Analysis of Synchronous Circuit
The given circuit in above figure is Mealy Network and the output is function of input variable and PS
of FF. The analysis of above circuit is as follows.
The Excitation and Output Function
By substituting the FF inputs in characteristic equation, the next state of FF is obtained in terms of PS
of FF and external input.
The characteristic equation of JK FF is
The Excitation Table
PS
Q2 Q1
(y2 y1)
Excitation input
J2 K2 J1 K1
x=0, 1 x=0, 1
Output Z
x=0, x=1
0 0 0 1 0 1 1 1
0 1 0 1 0 1 0 0
212122
1212
,,, yKyJxKxJ
yxyyyxZ


QKQJQ 
22222
211111
xQKQJQ
QQKQJQ




112
112222
221221
,1,0
,,
,
yzxWhenandyyzxWhen
yxyyyxZxKxJ
QyKQyJ




Logic Design 10CS33
1 0 0 1 1 0 1 1
1 1 0 1 1 0 2 0
State Table
PS NS O/p Z
x = 0 x = 1
Q2
(y2)
Q1
(y1)
state Q2+ Q1+ state Q2+ Q1+ state X=0 X=1
0 0 A 0 0 A 1 0 C 1 1
0 1 B 0 0 A 1 0 C 0 0
1 0 C 0 1 B 1 1 D 1 1
1 1 D 0 1 B 1 1 D 1 0
State Diagram of Mealy Network
A
D
C
B
0/1
0/0
0/1
1/0
1/1
0/1
1/1
1/0
Q1+ = Q2 = y2
Q2+ = x
1
12
,1
,0
yzxif
yyzxif


A, B, C, D are
Present states.

Logic Design 10CS33
Analysis of Moore Network
State Table / Transition Table
PS NS O/p Z
x = 0 x = 1
Q1 Q2 State Q1+ Q2+ State Q1+ Q2+ state
0 0 A 0 0 A 0 1 B 0
0 1 B 1 1 D 0 0 A 1
1 0 C 0 0 A 0 0 A 1
1 1 D 1 0 C 0 0 A 1
2121
12221
21
2112221
Q&0,1
Q&,0
,
QDDxif
QDQDxif
QQZ
QQxQQxDQxD




Q1+ = D1
Q2+ = D2
Z = Q1 + Q2
2121
12221
Q&0,1
Q&,0
QDDxif
QDQDxif



Logic Design 10CS33
State Diagram of Moore Network
Analysis of Sequential Network
State Table
PS NS O/p y
x = 0 x = 1
QA QB state QA+ QB+ state QA+ QB+ state x=0 x=1
0 0 S0 0 1 S1 0 0 S0 0 1
0 1 S1 1 0 S2 1 1 S3 1 0
1 0 S2 0 1 S1 1 0 S2 0 1
1 1 S3 1 0 S2 0 1 S1 1 0
D
1
0
B
1
C
1
A
0 1
0
0
0
01
1
A, B, C, D are Present
states.
AxKJ
BKBJBAxy
BB
AA

 ,,
][,1
][,0
])[(,
BAB
BAB
BABBA
QQQxif
QQQxif
QQxQQQ







Logic Design 10CS33
State Diagram of Mealy Network
S0
1/1
0/0
0/1
1/1
1/0
S3 S1
S2
0/0
0/1
1/0
S0, S1, S2, S3 are Present
states.

Logic Design 10CS33
Unit-8: D/A Conversion and A/D Conversion
Contents:
Variable
Resistor Networks
Binary Ladders
D/A Converters
D/A Accuracy and Resolution
A/D Converter- Simultaneous Conversion
A/D Converter-Counter Method, Continuous A/D
Conversion, A/D Techniques
Dual-slope A/D Conversion
A/D Accuracy and Resolution

Logic Design 10CS33
Basic Concept:
• Analog signals are continuous, with infinite values in a given range.
• Digital signals have discrete values such as on/off or 0/1.
• Limitations of analog signals
– Analog signals pick up noise as they are being amplified.
– Analog signals are difficult to store.
– Analog systems are more expensive in relation to digital systems.
• Advantages of digital systems (signals)
– Noise can be reduced by converting analog signals in 0s and 1s.
– Binary signals of 0s/1s can be easily stored in memory.
– Technology for fabricating digital systems has become so advanced that they can be
produced at low cost.
• The major limitation of a digital system is how accurately it represents the analog signals after
conversion.
• A typical system that converts signals from analog to digital and back to analog includes:
– A transducer that converts non-electrical signals into electrical signals
– An A/D converter that converts analog signals into digital signals
– A digital processor that processes digital data (signals)
– A D/A converter that converts digital signals into equivalent analog signals
– A transducer that converts electrical signals into real life non-electrical signals
(sound, pressure, and video)

Logic Design 10CS33
A/D Converter
• In order to change an analog signal to digital, the input analog signal is sampled at a high rate
of speed.
• The amplitude at each of those sampled moments is converted into a number equivalent – this
is called quantization.
• These numbers are simply the combinations of the 0s and 1s used in computer language – this
called encoding.
A/D Conversion – Pulse Code Modulation/Demodulation

Logic Design 10CS33
Analog-to-Digital
• A simple hypothetical A/D converter circuit with one analog input signal and three digital
output lines with eight possible binary combinations: 000 to 111
– Shows the graph of digital output for FS V analog input
• The following points can be summarized in the above process:
– Maximum value this quantization process reaches is 7/8 V for a 1 V analog signal;
includes 1/8 V an inherent error
– 1/8 V (an inherent error) is also equal to the value of the Least Significant Bit (LSB)
= 001.
– Resolution of a converter is defined in terms of the number of discrete values it can
produce; also expressed in the number of bits used for conversion or as 1/2n
where n
=number of bits
– The value of the most significant bit (MSB) -100- is equal to ½ the voltage of the
full-scale value of 1 V.
– The value of the largest digital number 111 is equal to full-scale value minus the
value of the LSB.
– The quantization error can be reduced or the resolution can be improved by
increasing the number of bits used for the conversion
Opamps
• Ideal opamps
– Infinite BW
– Infinite voltage gain
– Infinite input impedance
– Zero output impedance
• Practical opamps
– wide BW
– Very high voltage gain
– Very high input impedance

Logic Design 10CS33
– Very low output impedance
Closed Loop Frequency Response
• Non-inverting
– Source is connected to the non-inverting input
– Feedback is connected to the inverting input
– If Rf and Ri are zero, then unity feedback used for buffering
– Av=1+Rf/Ri
• Inverting
– Feedback and source are connected to the inverting input
Av=-Rf/Ri

Logic Design 10CS33
Comparators
• Determines which input is larger
• A small difference between inputs results maximum output voltage (high gain)
• Zero-level detection
• Non-zero-level detection

Logic Design 10CS33
A/D Conversion – Types
• Can be classified in four groups:
– Integrator:
• Charges a capacitor for a given amount of time using the analog signal.
• It discharges back to zero with a known voltage and the counter provides the
value of the unknown signal.
• Provides slow conversion but low noise.
• Often used in monitoring devices (e.g., voltmeters)
– Flash: uses multiple comparators in parallel.
• The known signal is connected to one side of the comparator and the analog
signal to be converted to the other side of the comparator.
• The output of the comparators provides the digital value.
• This is a high-speed, high cost converter.
A/D Conversion
Successive approximation: Includes a D/A (digital to analog) converter and a comparator. An
internal analog signal is generated by turning on successive bits in the D/A converter.
Counter: Similar to a successive approximation converter except that the internal analog signal is
generated by a counter starting at zero and feeding it to the D/A converter.

Logic Design 10CS33
Sample and Hold Circuit
• If the input voltage to an A/D converter is variable, the digital output is likely to be unreliable
and unstable. Therefore, the varying voltage source is connected to the ADC through a
sample and hold circuit.
• Basic Operation:
– When the switch is connected, it samples the input voltage.
– When the switch is open, it holds the sampled voltage by charging the capacitor.
– Acquisition time: time to charge the capacitor after the switch is open and settle the
output.
– Conversion time: total time needed from the start of a conversion (turning on the
MSB in the SAR) until the end of the conversion (turning on/off Bit0 in the SAR) -
TAD: conversion time per bit.

Cse iii-logic design [10 cs33]-notes

More Related Content

What's hot

Similar to Cse iii-logic design [10 cs33]-notes

Recently uploaded

Cse iii-logic design [10 cs33]-notes
