Algorithms 101 for Data Scientists (Part 2)

Algorithms 101 for Data Scientists (Part 2)

• 1.
  Algorithms 101 forData Scientists Presented by Chris Conlan and Janice McMahon Bethesda Data Science Meetup
• 2.
  Sources of Sub-optimalcode • Every line of code in a program consumes resources and therefore has a cost • Mathematical operations, or steps in the program • Memory operations, or data allocation and creation • The rules of the programming language determine how the resources are used • Inefficient use of resources is the greatest source of “hidden” complexity; i.e., operations that are not part of the mathematics of the algorithm, but affect its performance • The way to avoid accidentally writing sub-optimal code is to understand how an algorithm specified in a language results in a program that runs on a computer
• 3.
  Problem #1: UnnecessaryOperations • Mathematical operations in a Python program are not the same as mathematical operations in an equation • Python does not know how to “reduce” your equation A = 5 A = 5 B = 6 B = 6 C = A + B for i in range(10) : for i in range(10) : sum += A + B + i sum += C + i sum -= A + B – i sum += C - i These are redundant O(n) reduction in ops!
• 4.
  Problem #2: MemoryAllocation • Python is dynamically typed and uses a private heap for all data structures and objects • Example: string concatenation S = “” H = [“hello”,”hello”, … , “hello”] for i in range(10) : S = ’’.join(H) S += “hello” Each append operation causes a new string to be created, with the old string copied to the new string and the new text added Avoids extra memory copies and allocations – much faster for large strings
• 5.
  Interpreted vs. CompiledLanguages • Compiled languages solve these problems by translating a program as a unit instead of a statement at a time • Optimizes over the whole expression to produce efficient code • Data types are statically determined and stored efficiently
• 6.
  Common subexpression elimination •Redundant operations are found in the code via dataflow analysis • Example code in C programming language: int A = 5; int B = 6; for (int i = 0; i < 10; i++) { sum += A + B + i; sum -= A + B – i; } Compiler performs dataflow analysis and uses registers for intermediate values Data is given explicit “integer” type; statically allocated as number with no object overhead
• 7.
  Explicit memory allocation •Dynamic memory allocation is explicit in code, exposing use of heap • Example in C programming language: char *a = malloc(50 * sizeof(char)); for (int i = 0; i < 50; i+=5) strcpy(&a[i], “hello”); String literal is copied directly into pre-allocated space; no allocation inside the loop Memory is allocated once at the beginning; maximum size must be given in allocation
• 8.
  Compilation to theArchitecture • Underneath the hood, the program is using functional units and a memory hierarchy to implement the operations in the program • Memory and operations have different latencies and bandwidths, the mix of memory and computational operations determines the optimal schedule on a particular hardware architecture
• 9.
  Vectorization https://www.cs.utexas.edu/~pingali/CS380C/2016/lectures/david-vectorization.pdf
• 10.
  Example: Dot Product •Example code in C programming language: float dot = 0; for (int i = 0; i < 10; i++) dot += A[i] * B[i]; C compiler will vectorize this computation, organizing it into groups of parallel operations
• 11.
  Python version ofdot product: • Example code in classic Python: for i in range(len(a)) : dot += a[i] + b[i] • Example using numPy: dot = numpy.dot(a, b) Interpreter will execute one operation per loop iteration The numPy library performs the vectorization internally to the library Interpreted languages often get the performance improvements of compiled languages via libraries – wherever possible, use them!
• 12.
  Memory Hierarchy https://www.edn.com/memory-hierarchy-design-part-1-basics-of-memory-hierarchies/ • Memoryclosest to the processor is fastest but most expensive • Data moves through the hierarchy in blocks • Get better performance by re-using data closer to the processor • Copies of data at different levels must be consistent
• 13.
  Example: Matrix Multiplication •Naïve C code: for (i = 0; i < n; i++) for (j = 0; j < m; j++) for (k = 0; k < l; k++) C(i,j) = C(i,j) + A(i,k) * B(k,j) • Block Algorithm: for (i = 0; i < n; i++) for (j = 0; j < m; j++) { // read block C(i,j) into fast memory for (k = 0; k < l; k++) { // read block A(i,k) into fast memory // read block B(k,j) into fast memory C(i,j) = C(i,j) + A(i,k) * B(k,j) } // write block C(i,j) to slow memory • Python code: c = numpy.matmul(a, b) https://sites.cs.ucsb.edu/~tyang/class/240a17/slides/Cache3.pdf Each operation involves a memory access Data is read and written in blocks, taking advantage of cache reuse to improve performance numPy library optimizes algorithm implementation
• 14.
  Be your ownOptimizer • Count your operations – don’t do O(n2) when the mathematics is only O(n) • Look at your loops – don’t put operations inside the loop body that can be taken out • Use packages like NumPy that improve object representation for arrays and numerical objects • Use packages like Cython that include some level of source analysis • If desperate – use SWIG and call a C routine!!
