Introduction to Computer Networks and Data Communications
- 1. Lesson 01 Introduction toComputer Networks and Data Communications Data Communications and Computer Networks: A Business User's Approach Sixth Edition
- 2. After reading thischapter, you should be able to: • Define the basic terminology of computer networks • Recognize the individual components of the big picture of computer networks • Outline the basic network layouts • Define the term convergence and describe how it applies to computer networks • Cite the reasons for using a network architecture and explain how they apply to current network systems Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 2
- 3. After reading thischapter, you should be able to (continued): • List the layers of the TCP/IP protocol suite and describe the duties of each layer • List the layers of the OSI model and describe the duties of each layer • Compare the TCP/IP protocol suite and the OSI model and list their differences and similarities Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 3
- 4. Introduction • Who todayhas not used a computer network? • Mass transit, interstate highways, 24-hour bankers, grocery stores, cable television, cell phones, businesses and schools, and retail outlets support some form of computer network Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 4
- 5. The Language ofComputer Networks • Computer network – an interconnection of computers and computing equipment using either wires or radio waves over small or large geographic areas • Local area network – networks that are small in geographic size spanning a room, floor, building, or campus • Metropolitan area network – networks that serve an area of 1 to 30 miles, approximately the size of a typical city Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 5
- 6. The Language ofComputer Networks (continued) • Wide area network – a large network that encompasses parts of states, multiple states, countries, and the world • Personal area network – a network of a few meters, between wireless devices such as PDAs, laptops, and similar devices • Voice network – a network that transmits only telephone signals (almost extinct) • Data network – a network that transmits voice and computer data (replacing voice networks) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 6
- 7. The Language ofComputer Networks (continued) • Data communications – the transfer of digital or analog data using digital or analog signals • Telecommunications – the study of telephones and the systems that transmit telephone signals (becoming simply data communications) • Network management – the design, installation, and support of a network, including its hardware and software • Network cloud – a network (local or remote) that contains software, applications, and/or data Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 7
- 8. The Big Pictureof Networks • Networks are composed of many devices, including: – Workstations (computers, tablets, wireless phones, etc) – Servers – Network hubs and switches – Routers (LAN to WAN and WAN to WAN) – Telephone switching gear Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 8
- 9. The Big Pictureof Networks (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 9
- 10. Communications Networks –Basic Layouts • Microcomputer-to-local area network • Microcomputer-to-Internet • Local area network-to-local area network • Personal area network-to-workstation • Local area network-to-metropolitan area network Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 10
- 11. Communications Networks –Basic Layouts (continued) • Local area network-to-wide area network • Sensor-to-local area network • Satellite and microwave • Cell phones • Computer terminal / microcomputer-to- mainframe Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 11
- 12. Microcomputer-to-Local Area Network Layout • Highly common throughout business and academic environments, and now homes • Typically a medium- to high-speed connection • Computer (device) requires a NIC (network interface card) • NIC connects to a hub-like device (switch) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 12
- 13. Microcomputer-to-Local Area Network Layout (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 13
- 14. Microcomputer-to-Internet Layout • Popularwith home users and small businesses • For some, a dial-up modem is used to connect user s microcomputer to an Internet service provider • Technologies such as DSL and cable modems are replacing modems Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 14
- 15. Microcomputer-to-Internet Layout (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 15
- 16. Local Area Network-to-LocalArea Network Layout • Found in systems that have two or more LANs and a need for them to intercommunicate • A bridge-like device (such as a switch) is typically used to interconnect LANs • Switch can filter frames Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 16
- 17. Local Area Network-to-LocalArea Network Layout (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 17
- 18. Personal Area Network-to-Workstation Layout • Interconnects wireless devices such as PDAs, laptops and notebooks, and music playback devices • Used over short distances such as a few meters Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 18
- 19. Personal Area Network-to-Workstation Layout (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 19
- 20. Local Area Network-to-MetropolitanArea Network Layout • Used to interconnect companies (usually their local area networks) to networks that encompass a city • High-speed networks with redundant circuits • Metro Ethernet is latest form of metropolitan LAN Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 20
- 21. Local Area Network-to-MetropolitanArea Network Layout (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 21
- 22. Local Area Network-to-WideArea Network Layout • One of the most common ways to interconnect a user on a LAN workstation to the Internet (a wide area network) • A router is the typical device that performs LAN to WAN connections • Routers are more complex devices than switches Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 22
- 23. Local Area Network-to-WideArea Network Layout (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 23
- 24. Wide Area Network-to-WideArea Network Layout • High-speed routers and switches are used to connect one wide area network to another • Thousands of wide area networks across North America, many interconnected via these routers and switches Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 24
- 25. Sensor-to-Local Area NetworkLayout • Not all local area networks deal with microcomputer workstations • Often found in industrial and laboratory environments • Assembly lines and robotic controls depend heavily on sensor-based local area networks Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 25
- 26. Sensor-to-Local Area NetworkLayout (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 26
- 27. Satellite and MicrowaveLayout • Typically long distance wireless connections • Many types of applications including long distance telephone, television, radio, long-haul data transfers, and wireless data services • Typically expensive services but many companies offer competitive services and rates • Newer shorter-distance services such as Wi-Max Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 27
- 28. Satellite and MicrowaveLayout (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 28
- 29. Cell Phone Layout • Constantly expanding market across the U.S. and world • Third generation services available in many areas and under many types of plans with fourth generation services starting to appear • Latest generation includes higher speed data transfers (100s to 1000s of kilobits per second) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 29
- 30. Cell Phone Layout(continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 30
- 31. Terminal/Microcomputer-to-Mainframe Computer Layout • Predominant form in the 1960s and 1970s • Still used in many types of businesses for data entry and data retrieval • Few dumb terminals left today – most are microcomputers with terminal emulation card, a web browser and web interface, Telnet software, or a thin client Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 31
- 32. Terminal/Microcomputer-to-Mainframe Computer Layout (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 32
- 33. One More Layout • An Additional Basic layout – telephone-to- network – Telephone systems are ubiquitous and now carry more data than voice – Common configuration – telephone connected to POTS – Newer configuration (VoIP) – telephone-to-LAN via gateway or telephone to gateway via DSL/ cable Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 33
- 34. Network Architectures • Areference model that describes the layers of hardware and software necessary to transmit data between two points or for multiple devices / applications to interoperate • Reference models are necessary to increase likelihood that different components from different manufacturers will converse • Two models to learn: TCP/IP protocol suite and OSI model Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 34
- 35. The TCP/IP ProtocolSuite Note: Some authors show only four layers, combining the two bottom layers. Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 35
- 36. The TCP/IP ProtocolSuite (continued) • Application layer – Where the application using the network resides – Common network applications include web browsing, e-mail, file transfers, and remote logins • Transport layer – Performs a series of miscellaneous functions (at the end-points of the connection) necessary for presenting the data package properly to the sender or receiver Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 36
- 37. The TCP/IP ProtocolSuite (continued) • Network (Internet or internetwork or IP) layer – Responsible for creating, maintaining and ending network connections – Transfers data packet from node to node (e.g. router to router) within network • Network access (data link) layer – Responsible for taking the data and transforming it into a frame with header, control and address information, and error detection code, then transmitting it between the workstation and the network • Physical layer – Handles the transmission of bits over a communications channel – Includes voltage levels, connectors, media choice, modulation techniques Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 37
- 38. The TCP/IP ProtocolSuite (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 38
- 39. The Open SystemsInterconnection (OSI) Model Note: The fifth layer (Physical) is missing in this figure. Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 39
- 40. The Open SystemsInterconnection (OSI) Model (continued) • Application layer – Equivalent to TCP/IP’s application layer • Presentation layer – Responsible for “final presentation” of data (code conversions, compression, encryption) • Session layer – Responsible for establishing “sessions” between users Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 40
- 41. The Open SystemsInterconnection (OSI) Model (continued) • Transport layer – Equivalent to TCP/IP’s transport layer • Network layer – Equivalent to TCP/IP’s network layer • Data link layer – Responsible for taking the data and transforming it into a frame with header, control and address information, and error detection code Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 41
- 42. The Open SystemsInterconnection (OSI) Model (continued) • Physical layer – Handles the transmission of bits over a communications channel – Includes voltage levels, connectors, media choice, modulation techniques Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 42
- 43. Logical and PhysicalConnections • A logical connection is one that exists only in the software, while a physical connection is one that exists in the hardware • Note that in a network architecture, only the lowest layer contains the physical connection, while all higher layers contain logical connections Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 43
- 44. Logical and PhysicalConnections (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 44
- 45. Logical and PhysicalConnections (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 45
- 46. Network Layouts inAction Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 46
- 47. The TCP/IP ProtocolSuite in Action • Note the flow of data from user to Web browser and back • At each layer, information is either added or removed, depending on whether the data is leaving or arriving at a workstation • The adding of information over pre-existing information is termed encapsulation Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 47
- 48. The TCP/IP ProtocolSuite in Action (continued) Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 48
- 49. Summary • Many servicesand products that we use every day employ computer networks and data communications in some way • Field of data communications and computer networks includes data networks, voice networks, wireless networks, local area networks, metropolitan area networks, wide area networks, and personal area networks Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 49
- 50. Summary (continued) • Applicationareas can be understood in terms of general network layouts: – Microcomputer-to-local area network – Microcomputer-to-Internet – Local area network-to-local area network – Personal area network-to-workstation – Local area network-to-metropolitan area network – Local area network-to-wide area network – Wide area network-to-wide area network – Sensor-to-local area network – Satellite and microwave – Cell phone – Terminal/microcomputer-to-mainframe computer Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 50
- 51. Summary (continued) • Keyconcept in networking is convergence • A network architecture, or communications model, places network pieces in layers – Layers define model for functions or services that need to be performed • The TCP/IP protocol suite is also known as the Internet model and is composed of five layers (some show four): – Application layer – Transport layer – Network layer – Network access layer – Physical layer Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 51
- 52. Summary (continued) • TheInternational Organization for Standardization (ISO) created the Open Systems Interconnection (OSI) model – OSI model is based on seven layers: application layer, presentation layer, session layer, transport layer, network layer, data link layer, physical layer • A logical connection is a flow of ideas that occurs, without a direct physical connection, between the sender and receiver at a particular layer Data Communications and Computer Networks: A Business User's Approach, Sixth Edition 52
